- Page 1 User Manual PCE-HDM 5 Digital Multimeter User manuals in various languages (français, italiano, español, português, nederlands, türk, polski, русский, 中文) can be found by using our product search on: www.pce-instruments.com Last change: 19 November 2018 v1.0 © PCE Instruments...
-
Page 2: Table Of Contents
MAX/MIN recording ................7 10 Select measurement range ..............7 11 Bluetooth and flashlight ............... 8 12 Auto Power Off ..................8 13 Batteries ....................8 14 Fuse replacement.................. 8 15 Warranty ....................9 16 Disposal ....................9 © PCE Instruments... -
Page 3: Safety Notes
We expressly point to our general guarantee terms which can be found in our general terms of business. If you have any questions please contact PCE Instruments. The contact details can be found at the end of this manual. © PCE Instruments... -
Page 4: Safety Symbols
Equipment is protected by double or reinforced insulation. Introduction The digital multimeter PCE-HDM 5 is a universal meter for lots of applications. Users can easily measure current, voltage, capacitance, frequency and resistance. Additionally, the meter can measure the duty cycle, make diode tests and continuity tests. -
Page 5: Specifications
-4.0 … 1400.0 °F (without sensor) ± (3% + 9 °F) The accuracies are given at an environmental temperature of 23 °C ±5°C and an ambient humidity of max. 80 % RH. For the waveforms, sine waves have been measured. © PCE Instruments... -
Page 6: Further Specifications
Operating altitude max. 2000 m Power supply 2 x 1.5 V AAA battery Auto Power Off >15 minutes Safety IEC1010-1(2001), EN61010-1(2001) CAT III 600 V Pollution degree 2 Weight 200 g Dimensions 125 x 68 x 48 mm © PCE Instruments... -
Page 7: Device Description
Direct current / alternating current Battery level indicator mV / V Voltage Ω Resistance Current Capacitance Frequency Duty cycle °C / °F Temperature N, m, µ, M, Unit of size Continuity test Diode test Bluetooth is deactivated © PCE Instruments... -
Page 8: On / Off
Now connect your test object to “COM“ and „V, Ω, HZ, %, mA, …“. The reading will be displayed directly. NOTE: To determine the capacitance of a capacitor, you must make sure it is discharged before making the measurement. The capacitor will be charged during the measurement. © PCE Instruments... -
Page 9: Temperature Measurement
To select the measurement range, press and hold the “MAX/MIN/Range” key for three seconds to deactivate Auto Range. Press the “MAX/MIN/Range“ again several times until you have reached your desired measurement range. To re-activate Auto Range, press and hold the “MAX/MIN/Range” key again for three seconds. © PCE Instruments... -
Page 10: Bluetooth And Flashlight
Pull out the fuse and replace it by a new one. Only use the following fuses: F10 A/600 V and F600 mA/600 V. Follow the instructions in the fuse compartment for the correct arrangement of the fuses. NOTE: Disconnect all test leads and turn off the meter before replacing the fuses. © PCE Instruments... -
Page 11: Warranty
For countries outside the EU, batteries and devices should be disposed of in accordance with your local waste regulations. If you have any questions, please contact PCE Instruments. © PCE Instruments... - Page 12 PCE Instruments contact information Germany France Spain PCE Deutschland GmbH PCE Instruments France EURL PCE Ibérica S.L. Im Langel 4 23, rue de Strasbourg Calle Mayor, 53 D-59872 Meschede 67250 Soultz-Sous-Forets 02500 Tobarra (Albacete) Deutschland France España Tel.: +49 (0) 2903 976 99 0 Téléphone: +33 (0) 972 3537 17...
