- Page 1 Release 1.0 Service Repair Documentation Level 3 (basic) S80/82/SFG75 Release Date Department Notes to change R 1.0 22.12.2005 BenQ CC S CES New document 10/2005 Technical Documentation TD_Repair_L2.5L_S80_R1.0.pdf Page 1 of 18 Company Confidential 2005©BenQ...
-
Page 2: Table Of Contents
....................3 ERMS AND BBREVIATIONS List of available level 3 basic parts..................4 Hardware requirements ......................4 S80 Board layout ........................5 SIM Card Problems ........................7 IO Connector Problems ......................8 B to B connector (upper slider part) problems..............10 Main keypad illumination problems..................11 Connector Battery ........................12 10 Connector RF Internal Antenna .....................13... -
Page 3: Introduction
This document describes the performance description for Siemens service partners. 1.1 Purpose This Service Repair Documentation is intended to carry out repairs on BenQ Mobile repair level 3 basic. The described failures shall be repaired in Siemens authorized local workshops only, The level 3(former Level 2.5e) partners are obliged to repair level 2 classified boards, up to their... -
Page 4: List Of Available Level 3 Basic Parts
Hardware requirements (According to General soldering information V1.3 - check C-market for updates) Jigs, Tools and working materials for all described repairs: hot air blower soldering gun tweezers flux solder 10/2005 Technical Documentation TD_Repair_L2.5L_S80_R1.0.pdf Page 4 of 18 Company Confidential 2005©BenQ... -
Page 5: S80 Board Layout
Release 1.0 S80 Board layout U852: J201 Bluetooth Switch Antenna volume Keys Connector Upper board side Contact J300: Vibra Contact J350: Mini SD Connect J251: Microphone U800: Antenna Lower board side Contact U801: J250: Antenna IO Connector Switch J301: Battery... - Page 6 Release 1.0 MMI Board Disdiode 10/2005 Technical Documentation TD_Repair_L2.5L_S80_R1.0.pdf Page 6 of 18 Company Confidential 2005©BenQ...
-
Page 7: Sim Card Problems
Use soldering iron to remove defective component. Avoid excessive heat! Watch surrounding components! Resolder new component afterwards. E-commerce order number: L50634-Z97-C406 E-commerce order name: CONNECTOR SIM CARD READER R65 (B) Soldering temperature: ~ 360°C TIP Temp. 10/2005 Technical Documentation TD_Repair_L2.5L_S80_R1.0.pdf Page 7 of 18 Company Confidential 2005©BenQ... -
Page 8: Io Connector Problems
E-commerce order name: CONN I/O 10P ACT/916-2941 BQ2K.N0083.001 Soldering temperature: ~ 360°C TIP Temp. IRIS Diagnose Code: 46100 Interface/Charging Connector/Mechanical Damage 47300 Interface/Data Interface/Mechanical Damage 4B100 Interface/Headset Connector/Mechanical Damage 10/2005 Technical Documentation TD_Repair_L2.5L_S80_R1.0.pdf Page 8 of 18 Company Confidential 2005©BenQ... - Page 9 Solder the new connecter by using soldering iron under consideration of the max. allowed temperature range. Samples of critical area: Lock mechanism damaged Lock mechanism OK Lock mechanism damaged Lock mechanism OK 10/2005 Technical Documentation TD_Repair_L2.5L_S80_R1.0.pdf Page 9 of 18 Company Confidential 2005©BenQ...
-
Page 10: B To B Connector (Upper Slider Part) Problems
CONN BTB D1.5 18P BQ21.N1003.011 Soldering temperature: ~ 360°C TIP Temp. IRIS Diagnose Code: 32100 Keys / Main / No Function 32200 Keys / Main / Reduced Functionality 36000 Keys / Illumination 10/2005 Technical Documentation TD_Repair_L2.5L_S80_R1.0.pdf Page 10 of 18 Company Confidential 2005©BenQ... -
Page 11: Main Keypad Illumination Problems
Attention: Remove Metal Dome Sheet before!!! E-commerce order number: L50840-L2133-D670 E-commerce order name: DISDIODE LED BL-HB536G BQ83.00536.071 Soldering temperature: ~ 360°C TIP Temp. IRIS Diagnose Code: 36000 Keys / Illumination 10/2005 Technical Documentation TD_Repair_L2.5L_S80_R1.0.pdf Page 11 of 18 Company Confidential 2005©BenQ... -
Page 12: Connector Battery
Use hot air blower to remove defective component. Avoid excessive heat! Watch surrounding components! Resolder new component afterwards. L50334-Z97-C524 E-commerce order number: E-commerce order name: CON BATT3P CBE-4517-2904H BQ21.N0036.011 Soldering temperature: 240 - 255°C IRIS Diagnose Code: 13000 Battery/Mechanical Damage 10/2005 Technical Documentation TD_Repair_L2.5L_S80_R1.0.pdf Page 12 of 18 Company Confidential 2005©BenQ... -
Page 13: Connector Rf Internal Antenna
83100 Radio / Dropped Calls / Int. Antenna 83200 Radio / Dropped Calls / Ext. Antenna 84100 Radios / Call Setup / Int. Antenna 84200 Radio / Call Setup / Ext. Antenna 10/2005 Technical Documentation TD_Repair_L2.5L_S80_R1.0.pdf Page 13 of 18 Company Confidential 2005©BenQ... -
Page 14: Connector Mini Sd
~ 360°C TIP Temp. IRIS Diagnose Code: 4E000 Interfaces/ Memory Card Reader Attention: Avoid excessive heat in order not to damage the plastic material of the connector (see problem SLIM-Lumberg connector) 10/2005 Technical Documentation TD_Repair_L2.5L_S80_R1.0.pdf Page 14 of 18 Company Confidential 2005©BenQ... -
Page 15: Connector Vibra
Watch surrounding components! Resolder new component afterwards. L50334-Z97-C525 E-commerce order number: CONN SPRING SBS23-2K30F00 BQ21.N0045.011 E-commerce order name: 240 - 255°C Soldering temperature: 75100: Acoustics / Vibra /No Function IRIS Diagnose Code: 10/2005 Technical Documentation TD_Repair_L2.5L_S80_R1.0.pdf Page 15 of 18 Company Confidential 2005©BenQ... -
Page 16: Fuse
L50145-A820-Y23 E-commerce order number: FUSE 1A 24V F0603 1608FF BQ69.41004.001 E-commerce order name: 240 - 255°C Soldering temperature: 11000 Battery / No charging / deep discharge IRIS Diagnose Code: 10/2005 Technical Documentation TD_Repair_L2.5L_S80_R1.0.pdf Page 16 of 18 Company Confidential 2005©BenQ... -
Page 17: Connector Sidekeys
Watch surrounding components! Resolder new component afterwards. L50315-Z77-C261 E-commerce order number: SWI VOLUME KEY 5P BQ21.P0004.005 E-commerce order name: 240 - 255°C Soldering temperature: 34100 Keys / Side IRIS Diagnose Code: 10/2005 Technical Documentation TD_Repair_L2.5L_S80_R1.0.pdf Page 17 of 18 Company Confidential 2005©BenQ... -
Page 18: Connector Mmi
Watch surrounding components! Resolder new component afterwards. L50315-Z77-C261 E-commerce order number: SWI VOLUME KEY 5P BQ21.P0004.005 E-commerce order name: 240 - 255°C Soldering temperature: 34100 Keys / Side IRIS Diagnose Code: 10/2005 Technical Documentation TD_Repair_L2.5L_S80_R1.0.pdf Page 18 of 18 Company Confidential 2005©BenQ...
