Error Messages; Error Codes - Webasto Coolant General Operations Manual

Status
Heating mode
Ventilation mode
Switched off heater - control element is activated
Error - no heating mode
Preprogrammed heating mode - control element in stand-by mode
Preprogrammed ventilation mode - control element in stand-by
mode
NOTE: If a user does not make any inputs with the control unit within 60 seconds and the heater is switched off, the
control uni will go into stand-by mode (display and LED are switched off).
Switching the heater ON using the quick-start button
The Quick Start button enables heating or ventilation with the push of one button
adjusted to your personal preferences. Refer to the MultiControl operation manual on www.techwebasto.com.
Heating:
Ventilation:

Error Messages

Error messages regarding the heater will be displayed with the "F" or "H" designation displayed before the numerical
error code. Explanations of these error codes can be found in the appropriate heater service manual. Error messages
regarding the control element are displayed by means of "T" symbol. These error codes can be found in the operation
manual for the MultiControl.

Error Codes

If error messages appear on the display, please contact Webasto technical support at 800-860-7866.
Quick start button is programmed for heating
Heater starts. The display screen shows the symbol
for "Heating" as well as the run-time remaining.
The quick start button shows a green light.
Quick start button is programmed for ventilation
Ventilation fan turns on. The fan speed and oper-
ating time are shown on the display. The quick
start button shows a blue light.
LED Backlight Color and State
GREEN
BLUE
WHITE
RED
GREEN
BLUE
. The operating mode can be
*Not available in
North America
ON
ON
ON
FLASHING
FLASHING
FLASHING
