Using The Switch - Webasto Coolant General Operations Manual

Control Element

Using the Switch

Switching ON:
When the switch is used, the operation indicator (toggle) lights up. Shortly thereafter, the
heater begins operation and delivers heated coolant to the engine or heat exchanger.
Switching OFF:
When heating is no longer required, switch the toggle switch OFF. The indicator light
A separate switch (optional) allows the user to choose between heating and ventilation mode. In ventilation mode the fan
turns off, combustion extinguishes, followed by an after-run cycle.
speed depends on the position of the control element knob.
SmarTemp Control
ON/OFF Button
LCD Screen
*Micro USB
Service Port
* The micro USB service port is not used for heater diagnostic purposes on
SmarTemp Control fc 2.0
Rotary Knob
a
Screw Cap
Selection Button
