- Page 1 SWIMMING POOL HEAT PUMP UNIT Installation & Instruction Manual Models HP50CL Hayward Pool Products Canada, Inc. 2880 Plymouth Dr., Oakville, ON L6H 5R4 Haywardpool.ca / 1.888.238.7665...
-
Page 3: Table Of Contents
CONTENTS 1. Preface 2. Specifications 2.1 Performance Data of Swimming Pool Heat Pump Unit 2.2 Dimensions for Swimming Pool Heat Pump Unit 3. Installation and Connection 3.1 Installation of System 3.2 Swimming Pool Heat Pumps Location 3.3 How Close to Your Pool? 3.4 Swimming Pool Heat Pumps Plumbing 3.5 Swimming Pool Heat Pumps Electrical Wiring 3.6 Initial Start-up of the Unit... -
Page 4: Preface
1. PREFACE In order to provide our customers with quality, reliability and versatility, this product has been made to strict production standards. This manual includes all the necessary information about installa- tion, debugging, discharging and maintenance. Please read this manual carefully before you open or maintain the unit. -
Page 5: Specifications
2.SPECIFICATION 2.1 Performance data of Swimming Pool Heat Pump Unit REFRIGERANT : R410A Unit Model HP50CL Heating Capacity 14.7 B TU/ h 50000 Heating Power Input 2.68 Running Current Power Supply 208-230V～/60Hz Compressor Quantity Compressor rotary Fan Quantity Fan Power Input... -
Page 6: Dimensions For Swimming Pool Heat Pump Unit
2.SPECIFICATION 2.2 The dimensions for Swimming Pool Heat Pump Unit r Outlet 48.3 1049 Water Inlet 48.3 1002... -
Page 7: Installation And Connection
3.INSTALLATION AND CONNECTION 3.1 Installation illustration Valve Chlorinator cell Water outlet Water supply Pool Water inlet Sand filter Water pump (or other type filter) Installation items: The factory only provides the main unit and the water unit; the other items in the illustration are necessary spare parts for the water system ,that provided by users or the installer. -
Page 8: Swimming Pool Heat Pumps Location
3.INSTALLATION AND CONNECTION 3.2 Swimming Pool Heat Pumps Location The unit will perform well in any outdoor location provided that the following three factors are presented: 1. Fresh Air - 2. Electricity - 3. Pool filter piping The unit may be installed virtually anywhere outdoors. For indoor pools please consult the supplier. Unlike a gas heater, it has no draft or pilot light problem in a windy area. -
Page 9: Swimming Pool Heat Pumps Plumbing
3.INSTALLATION AND CONNECTION 3.INSTALLATION AND CONNECTION 3.4 Swimming Pool Heat Pumps Plumbing The Swimming Pool Heat Pumps exclusive rated flow titanium heat exchanger requires no special plumbing arrangements except bypass(please set the flow rate according to the nameplate). The water pressure drop is less than 10kPa at max. -
Page 10: Swimming Pool Heat Pumps Electrical Wiring
3.INSTALLATION AND CONNECTION 3.5 Swimming Pool Heat Pumps Electrical Wiring NOTE: Although the unit heat exchanger is electrically isolated from the rest of the unit, it simply prevents the flow of electricity to or from the pool water. Grounding the unit is still required to protect you against short circuits inside the unit. -
Page 11: Usage And Operation
4. USAGE 4.1. Function of wire controller LED display Timer off Timer on indicator indicator Key name Key function ON/OFF Press this key to turn on/off the unit Press this key to select the upward option or increase the parameter value. Press this key to select the downward Down option or decrease the parameter value. -
Page 12: Usage Of The Controller
4. USAGE 4.2. Usage of wire controller 4.2.1 Turn ON/OFF the unit When the unit is off, press the key“ ”0.5s to turned on the unit; When the unit is on, press the key“ ”0.5s to show down the unit. Press“... - Page 13 4. USAGE 4.2.3 Mode switch In the main interface,press “ ” and “ ” for 0.5s can set the mode,press “ ” or “ ” to change the current mode,you can switch different modes of colling, heating and auto mode. If there is no operation for 5s system will save the current mode and back to the main interface,press “...
-
Page 14: Parameter Table
4. USAGE 4.2.5 Malfunction display There will be malfunction code showing on the controller screen when relative malfunction occurs. If there are more than one malfuctions occurs at the same time, you can check the current error codes list by pressing “ ”... -
Page 15: Mulfunction Table
4. USAGE Malfunction Table The common failure cause and solution. -
Page 16: Maintenance And Inspection
5. MAINTENANCE AND INSPECTION Check the water supply device and the release often. You should avoid the condition of no water or air entering into system, as this will influence unit's performance and reliability. You should clear the pool/spa filter regularly to avoid damage to the unit as a result of the dirty of clogged filter. The area around the unit should be dry, clean and well ventilated. -
Page 17: Appendix
6.APPENDIX 6.1 Connection of PCB illustration OUT1 OUT2 CN19 AI06 AI05 OUT3 PC1001 AI04 OUT4 AI03 OUT5 AI02 AC-N AI01 CN 16 CN1 CN2 Connections explanation： Symbol Meaning OUT1 Compressor of system1（220-230VAC） OUT2 Water pump（220-230VAC） 4way valve （220-230VAC） OUT3 OUT4 High speed of fan motor（220-230VAC）... -
Page 18: Wiring Diagram
FM Fan motor FS Flow switch HP11 High pressure protection(4.0MP) HP12 High pressure protection(4.4MP) IT Inlet water temperature LP Low pressure protection KM1 Contactor compressor HP11 OT Outlet water temperature Controller TC Transformer 4 way valve REMOTE IN CODE 20180925-0001 HP50CL... -
Page 19: Exploded View And Spare Parts List
6.APPENDIX Exploded View (1) Complete machine structure explosion diagram (2) Electrical control structure explosion diagram... - Page 20 6.APPENDIX Spare Parts List Specifications Code Name 80900197 Front frame 95005-310456 LED301 20000-430126+35005-310416 20000-220188 Plastic fan net $%6 *) 3500-2701 Fan blade î $6 *) 20000-330124 Motor YDK45-6(YY060-1206P01-004) UL 32008-210069 Before the fixed plate Galvanized sheet 32012-210737 Support plate Galvanized sheet 32012-120165 Finned heat exchanger...
- Page 21 6.APPENDIX Caution & Warning 1. The unit can only be repaired by qualified installer centre personnel or an authorised dealer.（for Europe market） 2. This appliance is not intended for use by persons (including children) with reduced physical sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervi- sion or instruction concerning use of the appliance by a person responsible for their safety.
- Page 22 6.APPENDIX Cable specification 1. Single phase unit Nameplate maximum Phase line Earth line Creepage protector Signal line current No more than 10A î PP 1,5 mm 20 A 30mA less than 0.1 sec 10~16 A î PP 2,5 mm 32 A 30mA less than 0.1 sec 16~25 A î PP...
- Page 23 THERMOPOMPE POUR PISCINE Guide d’installation et d’utilisation Modèles HP50CL Hayward Pool Products Canada, Inc. 2880 Plymouth Dr., Oakville, ON L6H 5R4 Haywardpool.ca / 1.888.238.7665...
- Page 25 TABLE DES MATIÈRES 1. Préface 2. Spécifications 2.1 Données sur le rendement de la thermopompe piscine 2.2 Dimensions de la thermopompe de piscine 3. Installation et raccordement 3.1 Diagramme d’installation 3.2 Emplacement de la thermopompe de piscine 3.3 À quelle distance de votre piscine? 3.4 Tuyauterie pour la thermopompe de piscine 3.5 Câblage électrique pour la thermopompe de piscine 3.6 Démarrage initial de l’appareil...
- Page 26 1. PRÉFACE Afin d’offrir qualité, fiabilité et polyvalence à nos clients, ce produit a été fabriqué selon des normes de fabrication rigoureuses. Ce guide comprend toute l’information nécessaire à l’installation, au dépannage, à la vidange et à l’entretien. Veuillez lire attentivement ce guide avant d’ouvrir et de procéder à...
