Brooks EIB605C Photoelectric Quick Start Manual

9V Battery Powered
Communication Capability
Model EIB605C Photoelectric
Interconnect up to 12 battery powered alarms
x
Optional upgrade to
x
Early detection to all standard domestic fires types
x
Built-in high audibility warning sounder
x
Large Easy to use Test/Hush button
x
Hush Feature allows nuisance alarm control
x
Easy to install twist-on base design
x
Aesthetically pleasing, compact design
x
Innovative and robust optical chamber design
x
Low battery warning
x
Manufactured in Ireland to ISO 9001:2000
x
Certified to AS3786
x
rd
EN 14604:2005 3 party approved
x
5 year Guarantee
x
Product Description
The EIB605C is an Photoelectric (Optical) Smoke Alarm
using the light scatter principle, giving a quick response
to all standard fires. It's powered by a 9V replaceable
alkaline battery (supplied with the alarm)
The EIB605C is designed for simple installation,
commissioning and maintenance
The EIB605C has a large, easy to use, combined
Test/Hush button enables full testing of the alarm and
the ability to silence nuisance alarms.
The EIB605C has an innovative high performance optical
chamber with integral fixed insect screen reducing the
possibility of nuisance alarms.
The EIB605C maybe hardwire interconnected to twelve
battery powered alarms enabling all alarms to sound if
just one of the interconnected alarms should be
triggered.
The EIB605C modular design allows it to be upgraded
for functionality with the addition of the
EIB605MRF Radio frequency module.
E & OE As our policy is one of continuous product development, we reserve the right to alter product details without prior
Sydney - Melbourne
interconnect
- Adelaide - Brisbane
Operation
The smoke detector will activate the built in sounder
x
upon sensing smoke particles. It will automatically
reset and silence the alarm when the smoke
particles are no longer present in the chamber.
The red indicating LED will flash once every 40
x
seconds to show that the alarm is powered and it
has performed an automatic self-test.
The built in sounder will provide a minimum sound
x
output of 85dB at 3m.
Pressing and holding the "Test/Hush" button will
x
perform a self test and sound the horn – checking
the chamber, electronics and horn.
Momentarily pressing the "Test/Hush" button when
x
an alarm is sounding will set the alarm into "HUSH"
mode. This reduces the sensitivity for a period of 10
minutes, after which the alarm automatically resets –
providing control over nuisance alarms.
The smoke detector will emit a beep every 40
x
seconds to indicate that the battery is near depletion
and needs replacing.
