Brooks Electronics EIB603CX User Manual

For residential panels
Hide thumbs Also See for Electronics EIB603CX:
Table of Contents

Advertisement

Quick Links

Download this manual
Heat Alarm
for Residential Panels
EIB603CX
Read and retain carefully for as long as the product is being used. It contains vital information on the operation
and installation of your Smoke Alarm. The lea et should be regarded as part of the product.
If you are just installing the unit, the lea et must be given to the householder. The lea et is to be given to any
subsequent user.

Advertisement

Table of Contents
loading

Related Manuals for Brooks Electronics EIB603CX

Summary of Contents for Brooks Electronics EIB603CX

  • Page 1 Heat Alarm for Residential Panels EIB603CX Read and retain carefully for as long as the product is being used. It contains vital information on the operation and installation of your Smoke Alarm. The lea et should be regarded as part of the product. If you are just installing the unit, the lea et must be given to the householder.

  • Page 3: Table Of Contents

    CONTENTS Page QUICK START GUIDE LOCATION & POSITIONING INSTALLATION INTERCONNECTION - HARD WIRED TESTING, MAINTENANCE & POWER SUPPLY MONITORING FIRE SAFETY ADVICE ALARM LIMITATIONS GETTING YOUR ALARM SERVICED FIVE YEAR GUARANTEE TROUBLESHOOTING CONTACT US...

  • Page 4: Quick Start Guide

    1. Quick Start Guide LOCATE CORRECT SITING POINT FIX BASEPLATE TO CEILING ALARM SHOULD BE CEILING MOUNTED AT LEAST 300MM FROM WALLS & OBSTRUCTIONS, IDEALLY CENTRALLY IN ROOM/AREA PLACE ALARM & TWIST ON TO BASE Quick Start Guide...
  • Page 5 Quick Start Guide TEST ALARM PRESS THE TEST BUTTON TEST ALARM AT LEAST WEEKLY...

  • Page 6: Location & Positioning

    The EIB603CX can be used only with an RFAP, it cannot be used as standalone Heat Alarm or connected to any other systems. As Brooks are continually developing new products always check compatibility with the respective RFAP.
  • Page 7 Heat Alarms EIB603CX are supplementary to Smoke Alarms and must be interconnected to the Smoke Alarms EIB650iWX to ensure that the early warning will be heard, particularly by somebody sleeping. A properly designed early warning fire system ensures the alarm is given before the escape routes become blocked with smoke.
  • Page 8 Locate Heat Alarms in rooms adjoining escape routes - kitchens, garages, boiler houses etc. where Smoke Alarms are unsuitable. Install within 5.3m of potential sources of fire. Single Storey Dwelling If the premises is one storey you should put your first Smoke Alarm in a corridor or hallway between the sleeping and living areas.
  • Page 9 Figure 1 For minimum protection - Smoke Alarm on each storey - in each sleeping area Kitchen Bedroom - every 7.5 metres of hallways and Bathroom Living Room rooms - within 3 metres of all bedroom doors - all units interconnected Dining Room Bedroom For recommended protection...
  • Page 10 Checking Alarms Can Be Heard With the Alarms sounding in their intended locations check that the alarm can be heard in each bedroom with the door closed, above the sound of any TV/audio systems. The TV/audio systems should be set to a reasonably loud conversation level.
  • Page 11 IDEAL IN CENTRE OF CEILING Dead air space Suitable smoke alarm location DEAD AIR SURFACES NEVER WITHIN 0.3M OF ANY CORNER Figure 3 Figure 4 Locations to avoid DON’T place Smoke Alarms in any of the following areas: • Bathrooms, kitchens, shower rooms, garages or other rooms where the smoke alarm may be triggered by steam, condensation, normal smoke or fumes.
  • Page 12 DON’T place Heat Alarms in any of the following areas: • Bathrooms, shower rooms or other rooms where the unit may be triggered by steam or condensation. DON’T place Smoke or Heat Alarms in any of the following areas: • Places where the normal temperature can exceed 40°C or be below -10°C (e.g. attics, furnace rooms, directly above ovens or kettles etc.) as the heat/steam could cause nuisance alarms.

  • Page 13: Installation

    3. Installation Installation Procedure 1. Select a location complying with the advice in Section 2. 2. The mounting plate (base) is supplied with an interface board to supply power to the Alarm and communicate with other Alarms and the residential panel. (see Figure 5).
  • Page 14 8. Press the Test button on each Alarm to ensure that it sounds (see Figure 6). When all the alarms are connected to the panel and the panel is powered, install all the other Alarms similarly. Tamperproofing the Alarms The Alarm can be made tamperproof to prevent unauthorised removal of the Alarm.
  • Page 15 PUSH UP CATCH & TWIST BREAK OFF ALARM ANTI-CLOCKWISE SMALL PILLAR TO REMOVE How to Tamperproof How to Remove Figure 7a Figure 7b Line up the screw (not SELF TAPPING SCREW supplied) “U” shaped recessed area shown in figure 7c and screw firmly home.

  • Page 16: Interconnection - Hard Wired

    4. Interconnection - Hard Wired The combined maximum of interconnected Smoke Alarms and/or Heat Alarms is given in the specific system design manual. For example, 12 per zone in RFP6 and 15 in RFS1 can be interconnected together such that when one Alarm senses fire all Alarms sound a warning.

  • Page 17: Testing, Maintenance & Power Supply

    but the interconnected Alarms and RFAP will BREAK OUT SIDE WALLS continue to sound for a further 3 seconds. This allows one person to check the Alarms are interconnected) Check all the other Alarms similarly. Note: These Alarms will be interconnected REAR OF MOUNTING within the confines of a single family living...
  • Page 18 - Release the Test button, the Alarm, RFAP and all connected Alarms should stop sounding. - Repeat this procedure within 30 seconds for all other Alarms in the system. WARNING: Do not test with flame. This can set fire to the Alarm and damage the house. We do not recommend testing with smoke or heat as the results can be misleading unless special apparatus is used.
  • Page 19 The latest design, materials and manufacturing techniques have been used in the construction of Brooks Alarms to minimise the effects of contamination. However, it is impossible to completely eliminate the effect of dust and insect contamination, and therefore, to prolong the life of the Alarm you must ensure that it is kept clean so that excess dust does not build up.

  • Page 20: Fire Safety Advice

    In certain circumstances even with regular cleaning, contamination can build up in the smoke sensing chamber causing the alarm to sound. Contamination is beyond our control, it is totally unpredictable and is considered normal wear and tear. For this reason, contamination is not covered by the guarantee and a charge is made for all such servicing work.
  • Page 21 floor plan that will show each member at least 2 escape routes from each room in the house. Children tend to hide when they don’t know what to do. Teach children how to escape, open windows, and use roll up fire ladders and stools without adult help.
  • Page 22 Replace worn or damaged sockets, switches, home wiring and cracked or frayed electrical cords and plugs. Do not overload electrical circuits. Keep matches away from children. Never smoke in bed. In rooms where you do smoke, always check under cushions for smouldering cigarettes and ashes.
  • Page 23 Planning Your Escape Route For When The Alarms Sound 1. Check room doors for heat or smoke. Do not open a hot door. Use an alternate escape route. Close doors behind you as you leave. 2. If smoke is heavy, crawl out, staying close to floor. Take short breaths, if possible, through a wet cloth or hold your breath.

  • Page 24: Alarm Limitations

    7. Alarm Limitations Limitations of Smoke/Heat Alarms Smoke/Heat Alarms have significantly helped to reduce the number of fire fatalities in countries where they are widely installed. However independent authorities have stated that they may be ineffective in some circumstances. There are a number of reasons for this: •...

  • Page 25: Getting Your Alarm Serviced

    9. Five Year Guarantee Brooks guarantees this Alarm for five years from date of purchase against any defects that are due to faulty materials or workmanship. This guarantee only applies to normal conditions of use and service, and does not include damage resulting from accident, neglect, misuse, unauthorised dismantling, or contamination howsoever caused.

  • Page 26: Troubleshooting

    10. Troubleshooting Alarms sound for no apparent reason • Check for fumes, steam, etc. from the kitchen or bathroom. Paint and other fumes can cause nuisance alarms. • Check for any sign of contamination such as cobwebs or dust. Clean the alarm as described in Section 5 if necessary.
  • Page 27 Conforms to AS1603.3:2018...

  • Page 30: Contact Us

    P.O. Box 511 Archerfield QLD 4108 2/49 Boyland Ave Coopers Plains, QLD 4108 Ph: 07 3373 8222 P.O. Box 2114, Midland DC W.A. 6936 6/91 Leach Highway, Kewdale WA 6105 Ph: 08 6262 8095 © Brooks 2019 P/N B19367 Rev1...
