1. IMPORTANT! In the event the GX is:
• Modified or altered by any party other than Corning; or
• Subjected to misuse or improper handling or installation;
Corning's product warranty will be void and no longer valid. This includes replacing or removing connectors in
the field during installation.
2. In both indoor and outdoor applications, the GX unit should be mounted vertically with the connectors facing
upwards/downwards.
IMPORTANT! If the GX is mounted horizontally in an indoor application, sufficient cooling must be ensured
(i.e., air conditioning) and a sufficient tethering harness is required.
3. IMPORTANT! OptiTap® adapter pullout force ranges from a few lb to 50+ lb with the dust cap or connector installed.
This prevents damages caused to the DAS unit.
4. For deployments with the Corning® optical network evolution (ONE™) solution, the following additional elements
are required (ordered separately):
• Optical central hub (OCH-4-WDM/OCH-8-WDM) – performs the RF-to-optical conversion of the service signal
• ERFCv2-OCH cable – extender cable interfacing to the HEU RIX module and the OCH
• SC-450 unit – system controller required for GX management
5. For GX models supporting the CELL band – an external filter is required (ordered separately) if GX remote is deployed
along with 800 MHz band MA1000/MA2000 units. Filter to be installed before GX mounting.
6. Two people are required for mounting – unit weight: 154 lb (70 kg)
7. Wooden pole mount option accessory kit (AK-GX-QUAD-BRKT-WDPOLE) is available (ordered separately). Instructions
are provided with the kit.
8. Two additional options are available (ordered separately) for performing the GX RF antenna connections:
• Via the GX 4 x 1 External Multiplexer (P/N: AK-GX-ECPL-COMB) – RF antenna connections are performed via the
service specific GX external multiplexer
• Via GX couplers (P/N: AK-3COUPLER-DM-DF) – ensures that users/field engineers can measure and read signals
without interrupting service due to service cable disconnections
This document describes the GX quad-band installation procedure. Note that a detailed description of the GX couplers and
multiplexer are provided with the respective accessory kits.
Corning Optical Communications
GX Higher Power 40 W
Quad-Band DAS Remote
Quick Installation Sheet
CMA-581-AEN
GENERAL INFORMATION
Quick Installation Sheet | CMA-581-AEN | Page 1

Advertisement

loading
Need help?

Need help?

Do you have a question about the ONE GX and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for CORNING ONE GX

  • Page 1 • Modified or altered by any party other than Corning; or • Subjected to misuse or improper handling or installation; Corning’s product warranty will be void and no longer valid. This includes replacing or removing connectors in the field during installation.
  • Page 2: Verify Package Contents

    VERIFY PACKAGE CONTENTS Check your package contents to verify that the items in the packing list are included and that there are no signs of external damage. If there is any damage, call your Corning service representative. Items included in GX Kit...
  • Page 3 VERIFY PACKAGE CONTENTS (CONTINUED) Additional Required Items (ordered separately) for Image Installations with Corning® Optical Network Evolution (ONE™) Solution ERFCv2-OCH – RF Cables used for interfacing between HEU extender module and the OCH unit OCH-4-WDM (top) – four-port optical central hub supporting up to four SISO remotes;...
  • Page 4 GX accessory kit (ordered separately): AK-GX-QUAD-BRKT-WDPOLE REQUIRED HEADEND CONNECTIONS FOR DEPLOYMENTS WITH CORNING® OPTICAL NETWORK EVOLUTION (ONE™) SOLUTION IMPORTANT! Each HEU supports up to eight GX remotes. The following additional elements are required (ordered separately): •...
  • Page 5 REQUIRED HEADEND CONNECTIONS FOR DEPLOYMENTS WITH CORNING® OPTICAL NETWORK EVOLUTION (ONE™) SOLUTION (CONTINUED) Step 1: Refer to Figure 2 and connect the HEU to the OCH using the ERFCv2-OCH cable as follows: • Connect the 9-pin connector side of the ERFCv2- OCH cable to an available HEU RIX port and secure the connector in place.
  • Page 6 Figure 4. RF Signal Paths for GX Supporting S800 and GX with CELL 850 Deployed with HEU Figure 5. RF Signal Paths for GX Supporting 800 MHz and GX with CELL 850 Deployed RIU-12 Corning Optical Communications Quick Installation Sheet | CMA-581-AEN | Page 6...
  • Page 7 For instructions on how to install the external filter, refer to the quick installation sheet provided with the external filter or download from Corning partner portal (CMA-378-AEN). SELECT GX MOUNTING LOCATION Select the mounting location (wall/pole): • General surroundings Figure 6.
  • Page 8: Additional Installation Options

    (AK-GX-QUAD-BRKT-WDPOLE) for the pole mount installation instructions. • Indoor Concrete Wall Mount: Refer to the quick installation sheet provided with the indoor concrete wall-mount accessory kit (AK-GX-QUAD-BRKT-INDOOR). Corning Optical Communications Quick Installation Sheet | CMA-581-AEN | Page 8...
  • Page 9 Figure 9. Tightening M8 Nuts – Underside mounting bracket (see indicated arrows in Figure 10) and secure to pole by tightening clamp. Figure 10. External Combiner Mounting Options and Grounding Lug Corning Optical Communications Quick Installation Sheet | CMA-581-AEN | Page 9...
  • Page 10: Ground The Unit

    For installations with GX external combiner – connect the grounding wire supplied with the external combiner to the earth ground and to the combiners’ grounding lug (see Figure 10). Figure 11. GX Grounding Connection Corning Optical Communications Quick Installation Sheet | CMA-581-AEN | Page 10...
  • Page 11 Terminate any unused GX and multiplexer RF ports. Step 5: Connect external combiner RF output connector to broadband antenna. Refer to Figure 13. Figure 13. GX Connections to External Combiner Corning Optical Communications Quick Installation Sheet | CMA-581-AEN | Page 11...
  • Page 12 Step 2: Connect the supplied power cable to the power supply port: (VAC 100-240/47-63 Hz, 20A max). Maximum power consumption: 1450 W Figure 15. GX AC Model Power Connector Corning Optical Communications Quick Installation Sheet | CMA-581-AEN | Page 12...
  • Page 13 It is strongly recommended to secure the power Figure 18. Tightening Lug to Terminal cords to the enclosure. Additional holes are provided for this purpose. See Figure 19. Figure 19. Securing Power Cable Corning Optical Communications Quick Installation Sheet | CMA-581-AEN | Page 13...
  • Page 14 800-743-2675 • FAX: 828-325-5060 • International: +1-828-901-5000 • www.corning.com/opcomm Corning Optical Communications reserves the right to improve, enhance, and modify the features and specifications of Corning Optical Communications products without prior notification. A complete listing of the trademarks of Corning Optical Communications is available at www.corning.com/opcomm/trademarks. All other trademarks are the properties of their respective owners. Corning Optical Communications is ISO 9001 certified.
