1. The RAU5x must always be mounted parallel to the ceiling (horizontal) or wall (vertical) with a 1-in clearance
from the surface on the back and front to allow for proper cooling airflow and for heat dissipation.
Le RAU5x doit toujours être montée parallèlement au plafond (horizontal) ou au mur (verticale). Assurez-vous
qu'il y a un espace de un pouce à l'avant et à l'arrière afin de permettre un flux d'air de refroidissement et
dissipation de chaleur adéquat.
2. Required ambient temperature:
• Wall-mountable installations (vertical): 45˚C [113˚F]
• Ceiling-mountable installations (horizontal): 50˚C [122˚F]
3. The RAU5x unit is provided with a mounting bracket used for mounting on the wall or concrete ceilings
(including above acoustic ceiling mounts). Additional mounting accessory kits are available (ordered separately):
• BR-RAU5US-TOP: RAU5x bracket for floating ceilings tile, mid-mount installation
• BR-RAU5US-Wall: RAU5x remote bracket for wall-mountable installation; Supports up to two RAU5x units back-to-back
4. Add-on modules (i.e., RxU2325/GEM) are ordered separately and should be plugged into the RAU5x before
mounting the unit
5. A broadband antenna is required for RAU5x models ordered without a preassembled connected antenna.
6. External cavity filters are required for installations in which RAU5x modules supporting the corresponding CELL
and LTE bands are deployed alongside units supporting the Public Safety service. Installation instructions are
provided with each separately ordered filter (AK-CVT700; AK-CVT800).
This document provides instructions on how to mount the Corning
unit and perform the required connections. The scope of this document includes connections to the RF expansion unit
(RxU2325) and Gigabit Ethernet module (GEM) (for installations including the plug-in add-on modules).
Corning Optical Communications
Five-Band Remote
Access Unit (RAU5x)
Quick Installation Sheet
CMA-485-AEN
GENERAL INFORMATION
optical network evolution (ONE™) solutions RAU5x
®
Quick Installation Sheet | CMA-485-AEN | Page 1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for CORNING ONE RAU5x
Summary of Contents for CORNING ONE RAU5x
- Page 1 LTE bands are deployed alongside units supporting the Public Safety service. Installation instructions are provided with each separately ordered filter (AK-CVT700; AK-CVT800). This document provides instructions on how to mount the Corning optical network evolution (ONE™) solutions RAU5x ®...
-
Page 2: Package Contents
PACKAGE CONTENTS Check your package contents to verify that the items in the packing list are included. If any of the listed items are missing, contact your Corning representative. Item Description Quantity Image Five-Band Remote Access Unit (RAU5x): • RAU5XUS •... - Page 3 RAU5x only (no external antenna or plug-in modules): 10 lbs (4.5 kg) RAU5x and GEM: 11.1 lbs (5.03 kg) External Antenna: 3.7 lbs (1.7 kg) RxU2325: 3.08 lbs (1.4 kg) Corning Optical Communications Quick Installation Sheet | CMA-485-AEN | Page 3...
- Page 4 RAU5x ground connection. Step 3: Connect fiber optic pair to RAU5x module LC APC optic connector. See Figure 4. Figure 4. RAU5x Only —GND, F/O, and RF Cable Connections Corning Optical Communications Quick Installation Sheet | CMA-485-AEN | Page 4...
-
Page 5: Main Power Connections
Connections to corresponding cavity filters. Note: Refer to quick installation sheet (CMA-366-AEN) provided with 700/800 cavity filter or download from Corning Resource Center (Product resources) site. MAIN POWER CONNECTIONS RAU5x MAIN POWER (for RAU5x/RAU5x+RxU2325) DC input power connections (see Figure 6) – connect DC wire pair to the terminal block connector: •... - Page 6 Connect the A and B Ethernet ports to the PoE clients using Ethernet cables. Note: A and B Ethernet ports – 10/100/1000BASE-T with 802.3 at compliant Power-over-Ethernet (PoE+) PSE port. Corning Optical Communications Quick Installation Sheet | CMA-485-AEN | Page 6...
- Page 7 Steady Yellow – Fault Off – No link (PortA/B) PoE Steady Green – PoE enabled Steady Yellow – PoE fault Off – PoE off Table 2. Normal Operation LED Status Descriptions Corning Optical Communications Quick Installation Sheet | CMA-485-AEN | Page 7...
- Page 8 Corning Optical Communications reserves the right to improve, enhance, and modify the features and specifications of Corning Optical Communications products without prior notification. A complete listing of the trademarks of Corning Optical Communications is available at www.corning.com/opcomm/trademarks. All other trademarks are the properties of their respective owners.
