NeuraLabel 300x Quick Start User Manual

Toolbox
Hide thumbs Also See for 300x:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
NeuraLabel 300x Toolbox
Quick Start User Guide
Revised 2/2017

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 300x and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for NeuraLabel 300x

Summary of Contents for NeuraLabel 300x

  • Page 1 NeuraLabel 300x Toolbox Quick Start User Guide Revised 2/2017...
  • Page 3 NeuraLabel 300x Toolbox Quick Start User Guide Tools for achieving the best quality prints on the NeuraLabel 300x continuous form printer. Neuralog LP Copyright 2017...

  • Page 5: Table Of Contents

    Table of Contents Introduction to PageWide Technology ..................... 1 Print Quality Reports ........................... 2 Built-in PageWide Quality Tools ......................3 Toolbox Application and Quality Issues ....................4 Wide Bands or Die Level ........................5 Narrow Bands or Die Overlap/Alignment ..................... 6 Nozzle Out Flush with Print Head Cleaning...................
  • Page 6 Figure 1. NeuraLabel 300x Printhead ....................... 1 Figure 2. NeuraLabel 300x Printhead Spit Pattern ................... 1 Figure 3. NeuraLabel 300x Default Print Quality Report ................2 Figure 4. NeuraLabel 300x Custom Print Quality Report ................3 Figure 5. Toolbox Application ......................... 4 Figure 6.

  • Page 7: Introduction To Pagewide Technology

    PageWide Technology. The printhead for the NeuraLabel 300x printer is shown in Figure 1 below. There are ten printhead dies with a slight overlap between each pair. These printhead dies are numbered 0 through 9. Figure 2 shows a segment of the “spit pattern”...

  • Page 8: Print Quality Reports

    The Print Quality Report shows some, but not all, of the quality problems that might arise. The 300x Toolbox contains a customizable print quality report that allows one to easily isolate any quality problems so these issues can be readily addressed. A set of problem- specific tools is provided to correct each type of quality issue that might arise.

  • Page 9: Built-In Pagewide Quality Tools

    Figure 4. NeuraLabel 300x Custom Print Quality Report Built-in PageWide Quality Tools The NeuraLabel 300x does contain a set of automatic routines that correct many quality issues. These routines are built in to the three levels of printhead cleaning, accessible through the printer’s operator panel.

  • Page 10: Toolbox Application And Quality Issues

    Toolbox Application and Quality Issues When the 300x Toolbox Application is launched, a screen like that shown in Figure 5 will appear. The Printer: list will contain any installed 300x printers available through network or USB. A printer must be selected from the list before using the application.

  • Page 11: Wide Bands Or Die Level

    Wide Bands or Die Level Uneven wide color bands indicate a need for Die Level Adjustment. These bands will be slightly less than one inch wide. The examples below shows Die 7 Magenta darker and lighter, respectively. Note that the die level problem also shows up in the custom color because Magenta is a significant component of this color.

  • Page 12: Narrow Bands Or Die Overlap/Alignment

    Narrow Bands or Die Overlap/Alignment Dark lines that occur at a die seam (indicated on quality report) indicate a need for Die Overlap Adjustment. These bands will be seen as narrow dark lines in the image. In this case the dies need to be moved apart.

  • Page 13: Nozzle Out Flush With Print Head Cleaning

    Nozzle Out Flush with Print Head Cleaning A thin white line that does not appear at a die seam indicates a nozzle out. Nozzle outs are normally temporary, as the printer automatically compensates for them. However, the Print Head Cleaning accessed from the printer operator panel can be used to manually correct a nozzle out.

  • Page 14: Image Adjustment

    Image Adjustment Image Adjustment is used to position the image artwork on your diecut media. X Shift moves the image up or down in the non-continuous direction. The example below shows shifting the image using the X value to center it on the label. Y Shift would move the image in the continuous direction. Figure 9.

  • Page 15: Toolbox Preferences And Tools

    Select a 300x Printer from the list to use the Toolbox on that printer. Configure with Page Setup. Configure to your continuous form custom label size or try cut sheet from Tray 2.

  • Page 16: Using Toolbox For Print Quality Control

    Using Toolbox for Print Quality Control Print Quality Issues for the 300x can be separated into the categories just discussed: die color, alignment between dies, nozzle outs, and the placement of the image on the media. For any bands in the print, it can be difficult to determine exactly “how dark”...
  • Page 17 NOTE: The samples and the Quick Print are configured through Preferences->Quick Print. In this panel you can add a custom color and change the bar size. Adding a custom color from your label can make isolating a quality issue easier. If your label is small (page size) is small, you may need to reduce the bar height.

  • Page 18: Die Level Adjust For Wide Bands

    Die Level Adjust for Wide Bands Each of the printer’s ten print dies has a “color level” calibration for each of the 4 colors. You may notice lighter or darker bands of a color in your printed image or in the Print Quality Report. These bands will be a little less than one inch in width.

  • Page 19: Figure 14. Step 1 Of Die Level Adjustment

    Locate the Problem: Select your 300x Printer from the list. Configure with Page Setup. Select the Quick Print. Locate the Wide Band on the Quick Print. Get Started: STEP 1: Select the box(es) on the grid that correspond to the problem shown on the Quick Print.

  • Page 20: Figure 15. Printing The Samples

    STEP 2: Select Make Lighter or Make Darker, depending on the problem. It is possible, but not recommended to correct multiple wide bands at the same time. You cannot select to make both lighter and darker samples at the same time. STEP 3: Print a set of samples.

  • Page 21: Figure 16. Sample Print For Die Level Adjustment

    STEP 4: Inspect the printed samples. Unless you changed the defaults, there will be 5 sets. The first will represent NO CHANGE, using a value of 0. Find the sample that best corrects the issue and note the printed correction value. The value used is printed at the top of each sample page. Enter this value in the grid interface at the corresponding location and click Submit.

  • Page 22: Die Overlap Adjust For Narrow Bands

    Die Overlap Adjust for Narrow Bands Each of the printer’s 10 dies overlaps its neighboring dies so that a seamless image transition can occur. At times you may notice a dark line at the die seams indicating there is too much of an overlap between the two dies.

  • Page 23: Figure 18. Step 1 Of Die Overlap Adjustment

    Locate the Problem: Select your 300x Printer from the list. Configure with Page Setup. Select the Quick Print. Locate the Narrow Band on the Quick Print. Get Started: STEP 1: Select the gray bar(s) on the grid that correspond to the problem shown on the Quick Print. This represents the seam between two dies.

  • Page 24: Figure 19. Printing The Samples

    STEP 2: Select Make Lighter or Make Darker, depending on the problem. It is possible, but not recommended to correct multiple narrow bands at the same time. You cannot select to make both lighter and darker samples at the same time. STEP 3: Print a set of samples.

  • Page 25: Figure 20. Sample Print For Die Overlap/Alignment Adjustment

    STEP 4: Inspect the printed samples. Unless you changed the defaults, there will be 5 sets. The first will represent NO CHANGE, using a value of 0. Find the sample that best corrects the issue and note the printed correction value. The value used is printed at the top of each sample page.

  • Page 26: And Y Image Adjustment And X Image Stretch

    X and Y Image Adjustment and X Image Stretch At times the printed image may need to be shifted on the label for best positioning. This can be easily accomplished with X and Y Image Adjustment. In addition, you may wish to stretch the image in the continuous direction to allow for a slight amount of overspray.
  • Page 27 Shift the Image in the Y (continuous) direction. Shift the image in the continuous direction by entering a value in the Y keyin or clicking the Y- (Left) or Y+ (Right) arrow.  To shift the image towards the marked end of the media, click/enter a positive Y value. The units are mm.

  • Page 28: Figure 22. Web Interface For X Y Image Shift

    Figure 22. Web Interface for X Y Image Shift Stretch the Image in the Continuous Direction. Stretch the image in the continuous direction by entering a value in the Image Stretch keyin or clicking the Left or Right arrow. Stretching the image can allow for some overspray to ensure proper coverage in full bleed printing.

  • Page 29: Figure 23. Image Stretch In Web Server

    Figure 23. Image Stretch in Web Server...

  • Page 30: Toolbox Preferences

    Figure 24. Range Preferences Page Setup Selecting Preferences->Page Setup will bring up the standard NeuraLabel 300x printer driver panel. Page Setup can also be accessed through the button at the top of the application. Use this panel to configure the printer to print the test patterns on your media. Configure it exactly the same way as you do when printing labels on your media.

  • Page 31: Print Quality Reports

    Print button. Settable options are as follows: Print Quality Report: Custom or Default – Allows you to select the Default NeuraLabel 300x Print Quality Report, the same report accessible through the operator panel. Or, allows you to select the Custom Print Quality Report.

  • Page 32: Figure 26. Print Quality Report Preferences Panel

    Figure 26. Print Quality Report Preferences Panel Figure 27. Toolbox Custom Color Selection...

  • Page 33: Toolbox Tools

    Drop Detect Report (909) – This report provides numeric information about the 44,000 nozzles that make up the 10 dies. 909 is the report number in the 300x system. The details of this report are confidential; however, NeuraLabel support can assist in using this report if needed.

  • Page 34: Debug Window

    This is an ongoing log; it persists even after the application is exited. It can be used if NeuraLabel support needs to see the details of the printer commands. To activate the Debug Log use the key sequence Control-Shift-D.
