Summary of Contents for Only Climatization
- Page 1 Climatization User Manual...
-
Page 2: Table Of Contents
Automatic operation ..............................11 INTEGRATION WITH DOMOTICS ......................... 12 Association with Scenarios ............................12 Association with ON or OFF ............................ 12 Association of outputs to climatization........................12 FACTORY DEFAULT .............................. 13 ENANCER Electrónica S.A. Page 2 of 13 Rua Max Grundig 9 4705-820 Braga Portugal info@only-smartbuildings.com... -
Page 3: Introduction
The temperature control in each dependency is not only more comfortable but more economical because it connects only when necessary. For example, it makes no sense to heat a bedroom at 18:00 if we are only going to bed at 23:00 hrs. The ONLY engineers designed a climatization system that ensures maximum comfort with minimal human intervention and with seamless integration with the automation system. -
Page 4: Configuration Via The Otc-Clima
1. Setting the date and time The ONLY climate control units have illuminated touch sensors that function as 1234567 buttons. They allow the following functions: 1-DATE To set the date and time press within the option 1-DATE. -
Page 5: Setting The Cycle
You can now select the day of the week you wish to edit with the keys. 1234567 Going to the right, you can select all days of the week, only Monday to Friday or only the Weekend. In this case of multiple days of the week you cannot edit the DAYS... -
Page 6: Summer Programme
You can now select the day of the week you wish to edit with the keys. Going to the right, you can select all days of the week, only Monday to Friday or only 1234567 the Weekend. In this case of multiple days of the week you cannot edit the... -
Page 7: Installation Of Otc-Termo
1234567 afterwards stored in the respective unit. 5-INSTAL Note: If a name was assigned to the OTC-TERMO (only possible with a computer) 1234567 this name will appear instead of T01. 09:58 23º... -
Page 8: Ideal Temperatures - Otc-Clima
23º This can happen for example when you return home earlier than usual. In this case you wish to turn on climatization without having to change the programme. To do this, simply switch it on with the key and the ideal temperature is automatically selected as target temperature. -
Page 9: Ideal Winter Temperature
6 seconds: you will hear a beep to indicate that the mode was selected. Summer ENANCER Electrónica S.A. Page 9 of 13 Rua Max Grundig 9 4705-820 Braga Portugal info@only-smartbuildings.com Tel: +351 253 221 484 www.only-smartbuildings.com... -
Page 10: Operation
23º not the case, the unit can only function in manual mode. If the display shows only the temperature, this means that there is no date and time adjusted. In this case, when you switch on the unit with the key, it automatically goes to manual mode. -
Page 11: Otc-Termo
Since the OTC-TERMO does not have its own clock (there is no display for it) you can receive the time signal from other units in the system. The ONLY units that send time signals are the D-BUSDRV and the CENTRALSEC.. -
Page 12: Integration With Domotics
It may for instance be an advantage in an office to associate the opening of a blind or switching on a light to switching on climatization. In this way the user configures the office with the use of just one button. When switching on the light or opening a blind, climatization is switched on. -
Page 13: Factory Default
FACTORY DEFAULT VERY IMPORTANT: The ONLY climatization units have to be configured according to the installation in which they are used. This configuration should be done by the installer because it depends on the installation architecture and the physical connections made.
