Creative Sound Blaster X-Fi Surround 5.1 Pro v3 User's Guide
Notes:
•
Mic In will override Line In if both are connected simultaneously

1.3.1.1 Using Display Indicators and Control Dials

Your USB audio device has the following indicators and control dials to adjust
and monitor operational status.
Feature
1 Volume Control
Dial
2 Infrared Receiver
3 Power LED
1.3.1.2 Adjusting Volume
Besides using the Volume control dial, you can also adjust or mute volume
using:
•
Your remote control
•
Creative Entertainment Console or Volume Panel
Notes:
•
If you mute the volume in the software applications, you will not hear any
sound output even if the Volume control dial is set to the maximum
Creative Sound Blaster X-Fi Surround 5.1 Pro v3 User's Guide
Description
Turn clockwise or counterclockwise to increase or
decrease the volume. Press down to mute
Receives infrared commands from the remote control
Lights up in blue when USB power is detected. Blinks
intermittently when audio is muted
6
