Creative Sound Blaster X-Fi Surround 5.1 Pro v3 User's Guide

1.6.2 Connecting Home Theatre Systems

Your audio device comes with an Optical S/PDIF Out connector which allows
you to connect your home theater system. For more information on your A/V
receiver's speaker connections, consult its documentation.
1
2
3 Optical S/PDIF In Connector of Digital Speaker System
Connecting Your A/V Receiver Using Line Level Inputs
If your A/V receiver supports multichannel line-level inputs, you can connect
them directly to your audio device's Line Out jacks instead of the Optical
S/PDIF Out connector as shown below.
Creative Sound Blaster X-Fi Surround 5.1 Pro v3 User's Guide
Jack, Connector or Cable
Optical S/PDIF Out Connector
Optical Cable (Available Separately)
20
