- Page 1 Operating instructions GK22 | GK32 | GK42 | GK43 Quicklight hob...
- Page 2 GK43/O, GK43F/O, 527/31092 GK43/O, GK43F/O, GK43U/O GK43U/O GK43.3/F/U GK43.3/F/U GK43AB/F 31043 GK43AB/F GK43AU 534/31069 GK43AU GK43BL/U GK43BL/U GK43BR/U GK43BR/U GK43V/F GK43V/F GK43X/F 31006 GK43X/F Variations depending on the model are noted in the text. © V-ZUG Ltd, CH-6302 Zug, 2019...
-
Page 3: Table Of Contents
Contents Safety precautions 4 Symbols used............ 4 General safety precautions........ 4 Appliance-specific safety precautions .... 4 Instructions for use.......... 5 Using for the first time 7 Your appliance 7 Appliance overview .......... 7 Operating and display elements...... 9 Cookware .............. 10 OptiGlass............... 10 Operating the appliance 10... -
Page 4: Safety Precautions
Safety precautions Symbols used Cleaning and user mainten- ance shall not be undertaken Denotes important safety precau- tions. by children without supervi- Failure to observe said precautions sion. can result in injury or in damage to ▪ If an appliance is not the appliance or fittings! equipped with a mains cable Information and precautions that... -
Page 5: Instructions For Use
1 Safety precautions ▪ WARNING: The appliance Instructions for use and its accessible parts get Before using for the first time hot during use. Be careful not ▪ The appliance must be installed and to touch the heating ele- connected to the electricity supply in ments. - Page 6 1 Safety precautions ▪ Pots with pure copper or aluminium Note on use bases should not be used for cooking ▪ Tests have shown that under normal cir- as they can leave behind traces that cumstances there is no risk to cardiac can be difficult to clean.
-
Page 7: Using For The First Time
Using for the first time The appliance must be installed and connected to the electricity supply in accord- ance with the separate installation instructions. Have a qualified fitter/electrician carry out the necessary work. During the first few hours of use, a cooking zone can give off an unpleasant smell. This is normal for brand new appliances. - Page 8 3 Your appliance GK43.1, GK43.1U, GK43.1F ▪ 1 cooking zone ø210 mm ▪ 1 cooking zone ø180 mm ▪ 2 cooking zones ø140 mm GK43.3, GK43.3F, GK43.3U ▪ 1 dual ring cooking zone ø140/210 mm ▪ 1 cooking zone ø180 mm ▪ 2 cooking zones ø140 mm GK42H, GK42HU, GK42HF, GK43/O, GK43U/O, GK43F/O, GK43AU, GK43X, GK43XF ▪...
-
Page 9: Operating And Display Elements
3 Your appliance GK43BR, GK43BL, GK43BRU, GK43BLU ▪ 1 dual ring cooking zone ø140/210 mm ▪ 2 cooking zones ø180 mm with additional heating element form medium or large frying zone ▪ 1 cooking zone ø140 mm ▪ 1 oval warming surface (on right or left side) ▪... -
Page 10: Cookware
4 Operating the appliance Touch buttons for the warming surface Valid for GK43BR/U and GK43BL/U Buttons and displays Warming zone OFF Warming zone ON with indicator light Lock ON/OFF with indicator light Cookware Suitable cookware Cookware should have a stable bottom. When heated, the base of the cookware must lie flat on the surface of the cooking zone. -
Page 11: Overview Of Power Levels
4 Operating the appliance For normal cooking zones, the dial can be turned past the «0» power level in both directions. For dual ring cooking / frying zones, the dial has an end stop. It can only be turned in a clockwise direction and then back again. Overview of power levels Power level Cooking method... -
Page 12: Switching The Warming Surface On And Off
5 Care and maintenance Switching the outer cooking ring / additional heating element on ▸ Turn the dial for the required dual ring cooking / frying zone as far as it will go. – A click can be heard. ▸ Turn the dial to the required power level. For the large frying zone combination, the cooking zone E must be switched on as normal in addition to the active medium frying zone. -
Page 13: Optiglass
5 Care and maintenance ▸ Foods with a high sugar content, e.g. marmalade, that boil over should be removed while still hot using a glass ceramic hob scraper. The surface of the glass ceramic hob could otherwise become damaged. ▸ Remove melted plastic while still warm using a glass ceramic hob scraper. The sur- face of the glass ceramic hob could otherwise become damaged. -
Page 14: Trouble-Shooting
6 Trouble-shooting Trouble-shooting What to do if … Message Possible cause Solution The appliance is not ▪ Fuse or automatic circuit ▸ Set all the dials to «0». working and all the dis- breaker for electrical install- ▸ Change the fuse. plays are dark ations in the home is defect- ▸... - Page 15 7 Technical data Model number GK 306/31067 31043 Type designation GK GK42H1 GK43.2/F/U GK43AB/F Number of cooking zones Heating technology Radiant cooking zone Diameter of round cooking zones Energy consumption per cooking zone Wh/kg 186.5 183.9 191.1 179.5 Energy consumption of the entire hob EC Wh/kg 185.3 Model number GK 306 (230 V)/31066...
-
Page 16: Disposal
8 Disposal Model number GK Type designation GK GK43.3/F/U Number of cooking zones Heating technology Radiant cooking zone Diameter of round cooking zones 14/21 Energy consumption per cooking zone Wh/kg 186.5 179.5 190.6 187.6 Energy consumption of the entire hob EC Wh/kg 186.1 Disposal... -
Page 17: Index
Index Service agreement........... 19 Switching cooking zone off......11 Appliance disposal .......... 16 Switching the dual ring cooking / frying zone Appliance overview ..........7 on and off ........... 11 Appliance-specific safety precautions Switching the outer cooking ring / additional ................ -
Page 18: Notes
Notes... -
Page 19: Service & Support
Your repair order Call the free service number 0800 850 850 to contact your nearest V-ZUG service centre. You can arrange an on-site visit by us by phone if you wish. General queries, accessories and service agreement V-ZUG will be happy to help you with any general administrative or technical queries, to accept your orders for accessories and spare parts and to inform you about our pro- gressive service agreements. - Page 20 Switching a cooking zone off ▸ Set the dial for the active cooking zone to power level «0». J30614-R14 V-ZUG Ltd, Industriestrasse 66, CH-6302 Zug Tel. +41 58 767 67 67, Fax +41 58 767 61 61 info@vzug.com, www.vzug.com Service Centre: Tel. 0800 850 850...
