Operating instructions
Induction with single slider
Glass ceramic hob

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GK37TIMS and is the answer not in the manual?

Questions and answers

Related Manuals for V-ZUG GK37TIMS

Summary of Contents for V-ZUG GK37TIMS

  • Page 1 All manuals and user guides at all-guides.com Operating instructions Induction with single slider Glass ceramic hob...
  • Page 2 These operating instructions apply to: Type Product family GK37TIMS/C/F 31041 GK47TIMS/C/F/U 31040 GK47TIMXSC/F 31039 GK36TIS/C/F/.1F 008, 31013 GK46TIS/C/F/U/.1F 027, 31016 GK46TIXS/C/F/.1F 009, 31015 Variations depending on the model are noted in the text. © V-ZUG Ltd, CH-6301 Zug, 2016...

  • Page 3: Table Of Contents

    All manuals and user guides at all-guides.com Contents 1 Safety precautions  5 Symbols used ..................... 5 General safety precautions .............. 6 Appliance-specific safety precautions............ 7 Instructions for use .................. 8 2 Disposal  10 3 Using for the first time  11 4 Your appliance  12 Appliance overview.................
  • Page 4 All manuals and user guides at all-guides.com 8 Technical data  38 Product fiche ....................  38 9 Index  40 10 Notes  42 11 Service & Support  43...

  • Page 5: Safety Precautions

    All manuals and user guides at all-guides.com Safety precautions Symbols used Denotes important safety precautions. Failure to observe said precautions can result in injury or in dam- age to the appliance or fittings! Information and precautions that should be observed. Information on disposal Information about the operating instructions ▸...

  • Page 6: General Safety Precautions

    All manuals and user guides at all-guides.com 1 Safety precautions General safety precautions ▪ Read the operating instructions before using the appliance for the first time! ▪ This appliance can be used by children aged 8 and above and by persons with reduced physical, sensory or mental cap- abilities, or lack of experience and/or knowledge, provided they are supervised or have been instructed on the safe use of the appliance and have understood the hazards involved.

  • Page 7: Appliance-Specific Safety Precautions

    All manuals and user guides at all-guides.com 1 Safety precautions Appliance-specific safety precautions ▪ WARNING: If the surface is cracked or there is damage to the material thickness, the appliance must be switched off and disconnected from the electricity supply in order to avoid a possible electric shock.

  • Page 8: Instructions For Use

    All manuals and user guides at all-guides.com 1 Safety precautions Instructions for use Before using for the first time ▪ The appliance must be installed and connected to the electricity supply in accordance with the separate installation instructions. Have a qualified fitter/ electrician carry out the necessary work.
  • Page 9 All manuals and user guides at all-guides.com 1 Safety precautions Caution: Risk to life! ▪ Packaging materials, e.g. plastic film and polystyrene, can be dangerous for children. Danger of suffocation! Keep packaging material away from chil- dren. How to avoid damaging the appliance ▪...

  • Page 10: Disposal

    All manuals and user guides at all-guides.com Disposal Packaging ▪ All packaging materials (cardboard, plastic film (PE) and polystyrene (EPS)) are marked and should, if possible, be collected for recycling and disposed of in an environmentally friendly way. Disconnection ▪ Disconnect the appliance from the mains. With a fixed appliance, this is to be carried out by a qualified electrician! Safety ▪...

  • Page 11: Using For The First Time

    All manuals and user guides at all-guides.com Using for the first time The appliance must be installed and connected to the electricity supply in accordance with the separate installation instructions. Have a qualified fitter/electrician carry out the necessary work. During the first few hours of use, a cooking zone can give off an un- pleasant smell.

  • Page 12: Your Appliance

    All manuals and user guides at all-guides.com Your appliance Appliance overview GK37TIMS, GK37TIMSC, GK37TIMSF ▪ 2 cooking zones Ø 210 mm (back) ▪ 1 cooking zone Ø 180 mm (front) GK47TIMS, GK47TIMSC, GK47TIMSU, GK47TIMSF GK47TIMXSC, GK47TIMXSF ▪ 2 cooking zones Ø 210 mm (back)
  • Page 13 All manuals and user guides at all-guides.com 4 Your appliance GK36TIS, GK36TISC, GK36TISF ▪ 1 cooking zone Ø 250 mm ▪ 1 cooking zone Ø 210 mm ▪ 1 cooking zone Ø 145 mm GK46TIS, GK46TISC, GK46TISF, GK46TISU, GK46TIS.1F GK46TIXS, GK46TIXSC, GK46TIXSF, GK46TIXS.1F ▪...

  • Page 14: Operating And Display Elements

    All manuals and user guides at all-guides.com 4 Your appliance Operating and display elements Buttons Device ON/OFF Slider (to set the power level) PowerPlus Pause cooking ON/OFF and restore function Wipe protection ON/OFF Select the cooking zone Operating time/timer Displays Power level of the cooking zone Selection point: cooking zone selected Operating time activated...

  • Page 15: How Induction Hobs Function

    All manuals and user guides at all-guides.com 4 Your appliance How induction hobs function Induction hobs work very differently from conventional hobs or hot plates. The induction coils under the glass ceramic plate produce a rapidly changing mag- netic field which directly heats up the magnetic base of the cookware. The glass ceramic plate is only warmed by the hot cookware.

  • Page 16: Cookware

    All manuals and user guides at all-guides.com 4 Your appliance Cookware Suitable cookware Only cookware with a full magnetic base is suitable for use with the induction hob. This can be checked in the follow ways: ▪ A magnet sticks anywhere on the base of the cookware. ▪...

  • Page 17: Flexible Cooking

    All manuals and user guides at all-guides.com 4 Your appliance Flexible cooking Only applicable for GK37TIMS, GK47TIMS and GK47TIMXS. For flexible cooking, there are no marked cooking zones. Pots of different sizes can be placed on every zone. However, for pan detec- tion, must be covered.

  • Page 18: Operating The Appliance

    All manuals and user guides at all-guides.com Operating the appliance Switching the appliance on and off All the appliances are operated in the same way. ▸ To switch the appliance on: Depress the button for 1 second. – flashes in all the power level displays. –...

  • Page 19: Overview Of Power Levels

    All manuals and user guides at all-guides.com 5 Operating the appliance Overview of power levels Power level Cooking method Keeping warm Sauces, keeps food ready for serving at around 65 °C Melting, gentle Butter, chocolate, gelatine, sauces warming Swelling Rice Continued cooking, Vegetables, potatoes, sauces, fruit, reducing, stewing...

  • Page 20: Switching A Cooking Zone Off

    All manuals and user guides at all-guides.com 5 Operating the appliance Switching a cooking zone off ▸ Press the button of the required cooking zone. – The selection point of this cooking zone is illuminated. ▸ Touch power level «0» on the slider. –...

  • Page 21: Simmer Function

    All manuals and user guides at all-guides.com 5 Operating the appliance Simmer function With the simmer function, sausages, dumplings and stuffed pasta, for instance, can be cooked below boiling point at about 94 °C. Switching the simmer function on ▸ Press the level on the slider for 4 seconds.
  • Page 22 All manuals and user guides at all-guides.com 5 Operating the appliance Power management GK37TIMS, GK37TIMSC, GK37TIMSF PowerPlus cannot be used in cooking zones 1 and 2 at the same time. If PowerPlus is activated for both cooking zones, the power of the cooking zone that was initially set reduces.
  • Page 23 All manuals and user guides at all-guides.com 5 Operating the appliance GK47TIMS, GK47TIMSC, GK47TIMSF, GK47TIMSU GK47TIMXSC, GK47TIMXSF PowerPlus cannot be used for both cooking zones of a group (A or B) at the same time. If PowerPlus is activated for both cooking zones of a group, the power of the cooking zone that was initially set reduces.
  • Page 24 All manuals and user guides at all-guides.com 5 Operating the appliance GK36TIS, GK36TISC, GK36TISF, GK36TIS.1F PowerPlus cannot be used in cooking zones 1 and 2 at the same time. If PowerPlus is activated for both cooking zones, the power of the cooking zone that was initially set reduces.
  • Page 25 All manuals and user guides at all-guides.com 5 Operating the appliance GK46TIS, GK46TISC, GK46TISF, GK46TISU, GK46TIS.1F GK46TIXS, GK46TIXSC, GK46TIXSF, GK46TIXS.1F PowerPlus cannot be used for both cooking zones of a group (A or B) at the same time. If PowerPlus is activated for both cooking zones of a group, the power of the cooking zone that was initially set reduces.

  • Page 26: Automatic Boost

    All manuals and user guides at all-guides.com 5 Operating the appliance 5.10 Automatic boost Do not leave the hob unattended when using the automatic boost. Risk of boiling over, burning on and igniting! All the cooking zones are equipped with a selectable automatic boost. With this function, a cooking zone works at power level for a certain length of time (see table).

  • Page 27: Operating Time

    All manuals and user guides at all-guides.com 5 Operating the appliance 5.11 Operating time Do not leave the hob unattended during use. Risk of boiling over, burning on and igniting! With the operating time function, a Cooking zone switches off automatically after a set time 1–99 min..
  • Page 28 All manuals and user guides at all-guides.com 5 Operating the appliance Switching the operating time off before time ▸ Press the button of the required cooking zone. ▸ Press the button. ▸ Set the second digit of the operating time to using the slider.

  • Page 29: Timer

    All manuals and user guides at all-guides.com 5 Operating the appliance 5.12 Timer The timer functions like an egg timer (1–99 min.). It can only be set when a cooking zone is in operation. A cooking zone can be put into operation when the timer is running. However, no operating time can be set.

  • Page 30: Childproof Lock

    All manuals and user guides at all-guides.com 5 Operating the appliance 5.13 Childproof lock The childproof lock is to prevent the appliance from being accidentally switched on. Switching the childproof lock on ▸ Switch the appliance on. Ensure all cooking zones are switched off. ▸...

  • Page 31: Restore Function

    All manuals and user guides at all-guides.com 5 Operating the appliance 5.14 Restore function If the appliance was switched off accidentally with the button, the settings can be restored within 6 seconds. ▸ Switch on the appliance. – The illuminated point for the button flashes.

  • Page 32: Wipe Protection

    All manuals and user guides at all-guides.com 5 Operating the appliance 5.16 Wipe protection This function prevents the power level from being changed accidentally, for in- stance when wiping the control panel with a cloth. ▸ Press the button. – The indicator light for the button illuminates.

  • Page 33: Care And Maintenance

    All manuals and user guides at all-guides.com Care and maintenance Preferably, do not clean the appliance until it is cold. Burns hazard! Clean the hob after every use in order to prevent food residues from burning on. Cleaning dried-on and burnt-on dirt requires more effort. If the appliance is not cleaned correctly, the appearance and surface could be damaged.

  • Page 34: Trouble-Shooting

    All manuals and user guides at all-guides.com Trouble-shooting What to do if … … the appliance is not working and the displays are not illuminated? Possible cause Solution ▪ The fuse or circuit breaker for ▸ Change the fuse. electrical installations in the ▸...
  • Page 35 All manuals and user guides at all-guides.com 7 Trouble-shooting ... A continuous acoustic signal is emitted, flashes in a display and the appli- ance switches off? Possible cause Solution ▪ A button or a slider was ▸ Remove object or food that has boiled touched for longer than over.
  • Page 36 All manuals and user guides at all-guides.com 7 Trouble-shooting flashes in the display? Possible cause Solution ▪ The excess temperature pro- ▸ Allow the cooking zone to cool down. tection of a cooking zone ▸ Continue cooking on a different cooking was triggered.
  • Page 37 All manuals and user guides at all-guides.com 7 Trouble-shooting … and a number illuminate in the display? Possible cause Solution ▪ Internal error occurred. ▸ Note down the error number. ▸ Note down the serial number (FN) of the appliance. See the identification plate for this.

  • Page 38: Technical Data

    All manuals and user guides at all-guides.com Technical data Product fiche In accordance with EU Regulation No. 66/2014 Model number GK 31039 Type designation GK G47TIMXSC/F Number of cooking zones Heating technology Induction cooking zone Diameter of round cooking zones Energy consumption per Wh/kg 184.9...
  • Page 39 All manuals and user guides at all-guides.com 8 Technical data Model number GK 31041 Type designation GK GK37TIMS/C/F Number of cooking zones Heating technology Induction cooking zone Diameter of round cooking zones Energy consumption per Wh/kg 178.1 198.6 cooking zone...
  • Page 40 All manuals and user guides at all-guides.com Index Operating time.......... 27 Cancelling before time .....  28 Appliance Changing .......... 27 Switching on and off ...... 18 Elapsed .......... 28 Appliance overview ......... 12 Setting .......... 27 Appliance-specific safety precautions Several operating times .... 28 ..............
  • Page 41 All manuals and user guides at all-guides.com 9 Index Changing .......... 29 Setting .......... 29 Trouble-shooting ........34 Type............... 2 Using for the first time......11 Validity............2 Where is the identification plate?..11 Wipe protection ........32...
  • Page 42 All manuals and user guides at all-guides.com Notes...

  • Page 43: Service And Support

    Your repair order Call the free service number 0800 850 850 to contact your nearest V-ZUG service centre. You can arrange an onsite visit by us by phone if you wish. General queries, accessories and service agreement V-ZUG will be happy to help you with any general administrative or technical queries, to accept your orders for accessories and spare parts and to inform you about our progress- ive service agreements.

  • Page 44: Quick Instructions

    ▸ Touch on the slider. Switching the appliance off ▸ Press the button. J008013-R07 V-ZUG Ltd, Industriestrasse 66, CH-6301 Zug Tel. +41 58 767 67 67, Fax +41 58 767 61 61 info@vzug.com, www.vzug.com Service Centre: Tel. 0800 850 850...
