IBM 4610 SureMark Fiscal Printer
Turkey - Models GR3/GR5/GB3/GB5
Programming Guide Supplement
Version 21 01
Document Number (FTU90N21-PDF)
Owner: Alejandra Cartamil
Copy Printed: January 7, 2005 at 12:24 p.m.
CURRENCY STATEMENT
This version of the document was printed from an on-line system and must only be used for reference
purposes. The official copy of this document is the on-line version. Please preserve the integrity of the
documentation by destroying any obsolete versions and by not removing any pages from this printed
copy. A comment form is provided at the end of the document for your suggestions on the document
content and format.
— Page 1 of 183
