- Page 1 AXIS P5635-E Mk II PTZ Dome Network Camera User Manual...
-
Page 2: Table Of Contents
Connectors ........... . AXIS Multicable C I/O Audio Power ....... . . -
Page 3: Product Overview
AXIS P5635-E Mk II PTZ Dome Network Camera Product overview Product overview NOTICE TICE TICE Make sure the dome is attached in operation mode, otherwise focus may be affected. Ground screw Mounting screws (3) Network connector (PoE+) Multi-connector with cover (Do not remove the cover unless an I/O-cable is connected) -
Page 4: Find The Device On The Network
Find the device on the network Find the device on the network To find Axis devices on the network and assign them IP addresses in Windows®, use AXIS IP Utility or AXIS Device Manager. Both applications are free and can be downloaded from axis.com/support For more information about how to find and assign IP addresses, see the document How to assign an IP address and access your device on the device page at axis.com... -
Page 5: Setup
AXIS P5635-E Mk II PTZ Dome Network Camera Setup Setup Need more help? You can access the built-in help from the device’s webpage. The help provides more detailed information on the device’s features and their settings. Image quality How to focus faster using focus recall areas To save the focus settings at a specific pan/tilt range, add a focus recall area. - Page 6 Image with WDR. Note WDR may cause artifacts in the image. Find out more about WDR and how to use it at axis.com/web-articles/wdr Hide parts of the image with privacy masks What is a privacy mask? A privacy mask is a user-defined area that prevents users from viewing a part of the monitored area. In the video stream, privacy masks appear as blocks of solid color or blurred image elements.
-
Page 7: Streaming And Storage
H.264 or MPEG-4 Part 10/AVC Note H.264 is a licensed technology. The Axis product includes one H.264 viewing client license. Installing additional unlicensed copies of the client is prohibited. To purchase additional licenses, contact your Axis reseller. H.264 can, without compromising image quality, reduce the size of a digital video file by more than 80% compared to the Motion JPEG format and by as much as 50% compared to the MPEG-4 standard. -
Page 8: Overlays
AXIS P5635-E Mk II PTZ Dome Network Camera Setup Overlays About overlays Overlays are superimposed over the video stream. They are used to provide extra information during recordings, such as a timestamp, or during product installation and configuration. Display the pan or tilt position as a text overlay It may be useful to retrieve, for instance from a recorded video, the pan or tilt position in degrees in which an event has taken place. -
Page 9: Events
1. Remove the plug from the camera’s multi-connector and connect the multicable. 2. Connect the wires from the PIR detector to the input pin, see AXIS Multicable C I/O Audio Power on page 18. 3. Connect the wires from the switch to the output pin, see AXIS Multicable C I/O Audio Power on page 18. - Page 10 AXIS P5635-E Mk II PTZ Dome Network Camera Setup Set the PIR detector to an input port 1. Go to System > I/O ports. 2. Select Input in the Port 1 drop-down list. 3. Give the input module a descriptive name, for example “PIR detector”.
- Page 11 AXIS P5635-E Mk II PTZ Dome Network Camera Setup 7. Under Actions, select Output port from the Type drop-down menu. 8. In the Port drop-down menu, select “Gate switch”. 9. Click Ok. 10. Create another action rule with the name “Direct the camera to the gate"...
-
Page 12: Applications
Applications Applications AXIS Camera Application Platform (ACAP) is an open platform that enables third parties to develop analytics and other applications for Axis products. To find out more about available applications, downloads, trials and licenses, go to axis.com/applications To find the user manuals for Axis applications, go to axis.com Note •... -
Page 13: Troubleshooting
AXIS P5635-E Mk II PTZ Dome Network Camera Troubleshooting Troubleshooting If you can’t find what you’re looking for here, try the troubleshooting section at axis.com/support Reset to factory default settings Important Reset to factory default should be used with caution. A reset to factory default resets all settings, including the IP address, to the factory default values. -
Page 14: Technical Issues, Clues And Solutions
Axis device. Check all cabling and reinstall the device. Possible IP address conflict The static IP address in the Axis device is used before the DHCP server sets a dynamic address. with another device on the... -
Page 15: Performance Considerations
To access the device externally, we recommend using one of the following applications for Windows • AXIS Companion: free of charge, ideal for small systems with basic surveillance needs. • AXIS Camera Station: 30-day trial version free of charge, ideal for small to mid-size systems. For instructions and download, go to axis.com/products/axis-companion Problems with streaming Multicast H.264 only... - Page 16 AXIS P5635-E Mk II PTZ Dome Network Camera Troubleshooting • Running multiple AXIS Camera Application Platform (ACAP) applications simultaneously may affect the frame rate and the general performance.
-
Page 17: Specifications
AXIS P5635-E Mk II PTZ Dome Network Camera Specifications Specifications To find the latest version of the product’s datasheet, go to the product page at axis.com and locate Support & Documentation. LED indicators Status LED Indication Unlit Connection and normal operation. -
Page 18: Axis Multicable C I/O Audio Power
Specifications AXIS Multicable C I/O Audio Power When connecting external equipment to the product, a separetely sold AXIS Multicable C I/O Audio Power 1 m/ 5 m is required in order to maintain the product’s IP rating. Connect the multicable to the product’s multi-connector. To locate the multi-connector, see Product overview on page 3 . -
Page 19: Axis 10-Pin Push-Pull System Connector (Sold Separately)
I/O configured as output Axis 10-pin push-pull system connector (sold separately) When connecting external equipment to the Axis product, an Axis 10-pin Push-Pull System Connector (sold separately) is required in order to maintain the product’s IP rating. Mounting the wires requires a crimp tool. To get detailed mounting instructions of the wires, go to axis.com/support Connect the 10-pin push-pull system connector to the product’s multi-connector. - Page 20 AXIS P5635-E Mk II PTZ Dome Network Camera Specifications Function Notes Specifications 9, 10 The input is polarity independent. Use a Safety Extra Low AC/DC Power 24 V AC/DC Voltage (SELV) compliant limited power source (LPS) with input either a rated output power limited to ≤100 W or a rated output current limited to ≤5 A.
- Page 21 User Manual Ver. M9.2 AXIS P5635-E Mk II PTZ Dome Network Camera Date: April 2019 © Axis Communications AB, 2016 - 2019 Part No. T10042850...
