Side Tray Type M3
Machine Code: D725
Field Service Manual
July, 2014
Subject to change

Advertisement

Table of Contents
loading

Related Manuals for Ricoh M3

Summary of Contents for Ricoh M3

  • Page 1 Side Tray Type M3 Machine Code: D725 Field Service Manual July, 2014 Subject to change...

  • Page 3: Revision Lists

    Revision Lists Version Section Details Initial release of this document. 1.00 Created this manual for D146 series. Revised all sections according to the release of D197 series. Read This First > Safety and Symbols Modified some icons. Replacement and Adjustment > Modified items need to be removed in Step Drive Motor Unit 2, 3, and 6.

  • Page 4: Safety And Symbols

    Safety and Symbols This manual uses several symbols and abbreviations. The meaning of those symbols and abbreviations are as follows: Clip ring Screw Connector Clamp Short Edge Feed Long Edge Feed [A] Short Edge Feed (SEF) [B] Long Edge Feed (LEF) Trademarks ®...

  • Page 5: Table Of Contents

    TABLE OF CONTENTS Revision Lists................................1 Safety and Symbols............................2 Trademarks..............................2 1. Replacement and Adjustment Drive Motor Unit..............................5 Upper Paper Exit Sensor............................9 Left Paper Exit Sensor............................13 Upper Paper Exit Tray Set Switch........................14 Paper Exit Switching Unit Set Switch......................15...

  • Page 7: Replacement And Adjustment

    1. Replacement and Adjustment Drive Motor Unit Upper extension tray [A], Left extension tray [B]. Fixing plate [A] ( ×1).
  • Page 8 1. Replacement and Adjustment Side tray [A] ( ×1).
  • Page 9 Drive Motor Unit Drive motor unit cover [A] ( ×2). Side tray rear cover [A] ( ×1).
  • Page 10 1. Replacement and Adjustment Drive motor unit [A] ( ×3, ×2).

  • Page 11: Upper Paper Exit Sensor

    Upper Paper Exit Sensor Upper Paper Exit Sensor Side tray (page Upper paper exit tray [A]. Drive motor unit cover (page Side tray rear cover (page Left paper exit cover [A] ( ×1).
  • Page 12 1. Replacement and Adjustment Paper exit switching unit [A] ( ×1, ×1, ×1). Paper exit switching unit cover [A] ( ×4).
  • Page 13 Upper Paper Exit Sensor Guide plate [A]. Guide plate [A] ( ×1).
  • Page 14 1. Replacement and Adjustment Upper paper exit sensor [A] ( ×1).

  • Page 15: Left Paper Exit Sensor

    Left Paper Exit Sensor Left Paper Exit Sensor Upper paper exit tray (page Turn it upside down. Left paper exit sensor [A] ( ×1).

  • Page 16: Upper Paper Exit Tray Set Switch

    1. Replacement and Adjustment Upper Paper Exit Tray Set Switch Upper paper exit tray (page Upper paper exit tray set switch cover [A]. Upper paper exit tray set switch [A] ( ×1).

  • Page 17: Paper Exit Switching Unit Set Switch

    Paper Exit Switching Unit Set Switch Paper Exit Switching Unit Set Switch Open the Paper exit switching unit [A]. Paper exit switching unit set switch cover [A].
  • Page 18 1. Replacement and Adjustment Paper exit switching unit set switch [A] ( ×1).
