ironLogic Z-5R NET User Manual page 4

Z-5R NET
Table 1. Programming Modes
Programming using Master keys
1. Add Normal Keys
2. Add Blocking Keys
3. Add Master Keys
4. Erase Single Keys
5. Erase All Memory
6. Set Door Opening Time
7. Blocking Mode
8. Accept Mode
Programming using Pins on Socket #1
1.Using Electromechanical Lock
2. Memory Erase
3. Add Normal Keys without a Master key
4. Normal - operation not affected
4. Erasing simple keys using a master key (2 m, 1 M)
Briefly touch the contactor's master key twice (short touches).
At the time of the first contact, the controller will issue a short signal confirming the identification of
the master key. At the moment of the second touch, the controller will issue two short signals
indicating the second touch with the master key in programming mode, and no more than 6 seconds
later, touch and hold the master key at the contactor (long touch). At the moment of the third touch,
the controller will generate three short signals, and after 6 seconds, one signal indicating that the
key has been erased. After that, the master key should be removed.
Take away the Master Key from the probe, and start touching it with the condemned keys one after
another, with no longer than 16 s in between, to erase them one at a time.
The controller acknowledges each erase with a short beep. If the condemned key was not
present in memory, two beeps will sound.
Leave this mode either automatically when 16 s have elapsed since last touch, or by a short
Master Key touch. Exit is acknowledged by four short beeps in a row.
5. Erase All Memory by Using a Master Key (3m, 1M)
Touch the probe shortly three times with a Master key. The controller emits a short beep
acknowledging the Master key, then on second touch, two short beeps, acknowledging second
Master Key touch and entering programming mode. On the third touch, the Controller emits
three short beeps, denoting third Master Key touch. Within 6 s after that, touch and hold the
probe with the Master key (long touch). On the fourth touch, the controller emits four short
beeps, and in 6 s, a series of short beeps, acknowledging that controller has erased its key
memory entirely and left the programming mode.
Take away the Master key from the probe.
During the next power-up, the controller will enter programming mode automatically because the
keys database is now empty.
Note: When erasing the entire keys database, the existing programmed Lock Opening Time
setting is not reset.
6. Programming Door Opening Time (4m)
Touch the probe shortly four times with a Master key. The controller emits short beeps
acknowledging the Master key touches, the number of beeps each time is equal to the number of
Master Key touch.
Modes
www.ironlogic.me
Mode
Activation
1 М
1 М
1 m, 1 М
2 m, 1 М
3 m, 1 М
4 m
1 B
5 m
Position 1
Position 2
Position 3
Position 4
Legend
1...5 - number of
touches.
Letters denote Key
type:
N/n Normal Key
B/b Blocking Key
M/m Master Key
Lowercase letter short
touch (Key held <1 s)
Uppercase letter long
touch (Key held ~6 s)
Page 4
