LLC Pulsar-Telecom
195009, Russia, Saint-Petersburg, Bobruiskaya str.,7
Tel.: (812) 703-77-65, 542-04-80
Fax: (812) 542-11-85
105122, Russia, Moscow, Schelkovskoye Highway, 2, office 225
Tel./fax: (495) 580-37-61, 78-77-066
www.ironlogic.ru
Certificate GOST R No POCC RU.ME83.B00374
4. DELIVERY SET
Controller "Z-5R Net" 1pc. (supplied in installation box case)
Instructions- 1 pc.
Connection element-2 pcs.
Battery (CR 2032)- 1pc.
Bag- 1pc.
5. WARRANTY
Warranty period is 18 months from the date of sale but not exceeding 24 months from date of
manufacture.
Reasons for warranty termination:
- violation of these Instructions and maintenance requirements;
- mechanical damages;
- use of aggressive agents;
- unauthorized intervention into the controller scheme.
During the warranty period the Manufacturer repairs reader failures free of charge which appeared due to
the fault of Manufacturer or replaces faulty components and blocks. Repair is performed in the
Manufacturer
workshop.
TECHNICAL CHARACTERISTICS:
Connection element of lock type (electromagnetic/electromechanical)
Light and sound indication of operating and programming modes
Setup of lock release duration: from 0 to 220 sec (factory default - 3 sec)
Output: MIS-transistor
Operating voltage: 12V DC
Useful current (standby mode) 30mA
Communication current up to 5А
Protection from misconnection +
Ambient temperature: from -30С to +50С
Relative air humidity: not exceeding 90%
Operation instructions
Network controller
Advertisement
Related Manuals for ironLogic Z-5R NET
Summary of Contents for ironLogic Z-5R NET
- Page 1 Certificate GOST R No POCC RU.ME83.B00374 Network controller 4. DELIVERY SET TECHNICAL CHARACTERISTICS: Controller "Z-5R Net" 1pc. (supplied in installation box case) Connection element of lock type (electromagnetic/electromechanical) Instructions- 1 pc. Light and sound indication of operating and programming modes Connection element-2 pcs.
-
Page 2: Connection Diagram
1-st reader MATRIX-II – at input 2-тв reader MATRIX-II – at output Output of ТМ1 reader MATRIX-II is connected to contact ТМ of controller Z-5R Net. Output of ТМ2 reader MATRIX-II connected to contact EXIT of controller Z-5R Net. внешний зуммер = external buzzer, блок питания = Fig.1 Connection diagram of Z-5R Net. - Page 3 This mode blocks all simple keys. Use of simple keys does not open the door and induces a series of short 3. Adding of master keys ( 1 к М, 1 дМ) signals. Exit from locking mode to general mode is performed using locking key (up to the series of short Swipe the master key to the controller for a short period of time (short swipe).
- Page 4 GENERAL CHARACTERISTICS OF PROGRAMMING MODE Use of socket straps No 1. To enter into required programming mode use short (less than 1 sec) and long (about 6 sec) swipes with Controller is complete with one socket used for programming and setting master key.
- Page 5 Controller can operate both in standalone mode and using the network. Connection and operation in standalone mode of controller Z-5R Net are the same as for controller Z-5R. Connection to network by RS 485 (double-wire connection) Date of sale: "_____"...
