85017_2.book Page 10 Monday, July 16, 2001 3:05 PM
10
Rudder limit
Rudder limit restricts autopilot rudder movement to just less than the
steering systems mechanical stops. This avoids putting the steering
system under unnecessary load.
The range available is as follows:
•
Range = 15° to 40°
•
Default:
•
•
Default cruise speed
Default speed should be set to the boat's normal cruising speed and is
used in track mode. The range available is as follows:
•
Range = 4 to 20 knots
•
Default = 6 knots
Off course limit
Off course limit warns you if the autopilot is unable to maintain its set
course and has subsequently strayed more than the set limit for more
than 20 seconds.
The off course alarm settings available are as follows:
•
Range = 15° to 40°
•
Default = 20°
AutoTrim level
AutoTrim level sets the level for automatic trim which applies
additional rudder to correct for unbalanced propeller torque on twin
engine installations, or weather helm – a high trim level provides
faster trim correction.The Trim level settings available are as follows:
•
High Speed:
•
•
•
Low Speed:
•
•
High Speed = 30°
Low Speed = 30°
Range = 0 to 4
Default = 2
Range = 0 (Off) or 1 (On at high speed level)
Default = 1
RayPilot 650 Professional System
