5. Specifications

Model
Power supply
Cooling*(1) Capacity
Input
Cooling*(2) Capacity
Input
Heating*(3) Capacity
Input
Heating*(4) Capacity
Input
EER*(1)
EER*(2)
Max.input consumption
Max.input current
Model
Type
Brand
Capacity
Input
Compressor
Rated load current
Locked rotor Amp
Thermal protector
Refrigerant oil type
Refrigerant oil charge
Model
Type
Outdoor fan motor Brand
Input
Speed
Type
Input (H/M/L)
Water pump
Pumping head
Outdoor air flow
Throttle
Outdoor noise level (sound power)*(3)
Flow rate of water
The water pressure drop of heat-exchanger
The Max. and Min. water inlet pressure
Net dimension (W×H×D)
Outdoor unit Packing dimension(W×H×D)
Net/ Gross weight
Type
Refrigerant
Charged volume
Connection wiring Power wire
Pipe diameter Water inlet/outlet
Controller (optional)
Ambient temperature range
Leaving water temperature range
Note: Specifications are based on the following conditions:
1. Cooling: (*1) Entering/leaving water temperature: 12/7°C,outdoor ambient temperature 35°C DB.
(*2) Entering/leaving water temperature: 23/18°C,outdoor ambient temperature 35°C DB.
2.Heating: (*3) Entering/leaving water temperature: 40/45°C,outdoor ambient temperature 7°C DB/6°C WB .
(*4) Entering/leaving water temperature: 30/35°C,outdoor ambient temperature 7°C DB/6°C WB .
3. It is tested in a semi-anechoic room (sound power).
4. The above data may be changed without notice for future improvement on quality and performance.
V-Ph-Hz
kW
kW
kW
kW
kW
kW
kW
kW
kW/kW
kW/kW
kW
A
kW
kW
A
A
ml
kW
r/min
W
m
m³/h
dB(A)
m³/h
kPa
kPa
mm
mm
kg
kg
mm2
inch
Cooling:10~46; Heating: -20~35
(Antifreeze must be added below 5)
Cooling: 5~20; Heating: 20~55
6
AU082FYCRA(HW)
1PH, 220-240V~,50/60Hz
5.50
2.34
7.00
2.06
7.50
2.34
7.80
1.77
2.35
3.40
4.90
21.3
SVB200FKMMC
ROTARY
Mitsubishi Electric
6.45
2.15
7.90
24
Inner
FW68S
400
SIC-88FWJ-F1180-1
DC Motor
NIDEC SHIBAURA
180
160-850
Para 25/8-75/SC-WILO
75/57/35
8
4200
EXV
60.9
1.38
45
500/150
950×965×395
1010×990×458
87/90
R32
1.15
3×10.0
1-1/4''
Wired controller
