19.4 Week and clock function settings

Note: This function is not available when the dial code is simple.
Enter the week and clock setting by pressing and holding the
icon and the current value in
the week value. By pressing the
change the parameter by the UP and DOWN keys. Then press the key to switch to the minute setting, the minute
value flashes, you can change the minute value by using the UP and DOWN keys and press the
the change.If there is no operation for 10 seconds, the function will be exited and the last changed parameter will
not be saved.

19.5 Dip switch

SW1 Definition content
1
2 Whether to display the outlet water temperature
3 Whether it is the demo version
4 Single cooling
5 Single heating
6
7
8

19.6 Wired Controller Wiring Instruction

1. First, put communication wire through the hole in the backplane.
key to switch to the hour setting, the hour value flashes at this time, you can
Reserved
Simple
Reserved
Reserved
key for 10 seconds. After you enter this function,
flashes, pressing UP and DOWN keys to change
Specific definition
Reserved
ON -- do not display
OFF -- display
ON -- demo version
OFF -- Non-demo version
ON -- Single cooling
OFF -- normal
ON -- Single heating
OFF -- normal
ON -- simple
OFF -- normal
Reserved
Reserved
71
key to confirm
