Example Example Example Example
Use G82 command to program. The screw's pitch is 1.5, and the number of thread head is 2.
%3324
N1 G54 G00 X35 Z104
N2 M03 S300
N3 G82 X29.2 Z18.5 C2 P180 F3
N4 X28.6 Z18.5 C2 P180 F3
N5 X28.2 Z18.5 C2 P180 F3
N6 X28.04 Z18.5 C2 P180 F3
N7 M30
Figure 9.11 Thread Cutting Cycle - Example
9. Functions to Simplify Programming
