- Page 1 Zoom Mini TTL Flash for Fujifilm Mirrorless with integrated R2 Radio Transceiver FPLFSMMINIFU...
- Page 2 Thank You for Choosing Flashpoint! The Flashpoint Zoom Mini TIL Speedlight for Fujifilm with Integrated R2 Radio Transceiver is a hotshoe speedlight which is fully compatible with the Fujifilm system. These compact and lightweight units as well as their integrated functions and features make them the first choice of professional photographers with smaller mirrorless cameras.
-
Page 3: For Your Safety
For Your Safety • Always keep this product dry. Do not use in rain or in damp conditions. • This product contains high-voltage electronic parts. Touching the high-voltage circuit inside it may result in electric shock. Do not disas- semble. Should repairs become necessary, this product must be sent to an authorized maintenance center. -
Page 4: Product Layout
Product Layout Body 01. Retractable Bounce Card 06. Hotshoe 02. Retractable Wide Angle Diffuser 07. LCD Panel 03. Flash Head 08. Lock Ring 04. Optical Slave Sensor 09. Battery Compartment 05. Focus Assist Beam 10. USB Port for Firmware Upgrades MODE ZOOM SYNC... -
Page 5: Lcd Panel
LCD Panel TTL Autoflash... -
Page 6: Included Accessories
Included Accessories 1. Flash unit 2. Mini stand 3. Protection case 4. Instruction manual Available Accessories Attaching to a Camera Attach the Camera Flash. • Slip the camera flash’s mount- ing foot into the camera’s hotshoe all the way. Secure the Camera Flash. •... -
Page 7: Power Management
Power Management Power Switch to power the flash unit on (Long press the button for one second) or off. Turn off if it will not be used for an extended period of time. Setting as a master flash, it will turn the power off auto- matically after a certain period (approx. -
Page 8: Fec: Flash Exposure Compensation
FEC: Flash Exposure Compensation With FEC function, this flash can adjust from -3 to +3 in 1/3rd stops. It is useful in situations where minor adjusting of the TTL system is needed based on the environment. Setting FEC: Press the SET Button and the flash exposure compensation MODE ZOOM... -
Page 9: Second-Curtain Sync
Second-Curtain Sync With a slow shutter speed, you can create a light train following the subject. The flash fires right before the shutter closes. • Setting the Second-Curtain Sync function on the camera menu, Use the Flash Setting > Flash Light Function Setting on the camera’s shooting menu to adjust settings of the flash light. -
Page 10: Multi: Stroboscopic Flash
Multi: Stroboscopic Flash With stroboscopic flash, a rapid series of flashes is fired. It can be used to capture a multiple images of a moving subject in a single photograph. You can set the firing frequency (number of flashes per sec. expressed as Hz), the number of flashes, and the flash output. -
Page 11: Wireless Flash Shooting: Radio (2.4G) Transmission
Flashpoint Zoom Mini is perfectly compatible with all R2 2.4G wireless family. As a master unit, a Zoom Mini can control any R2 family flash As a slave unit, Zoom Mini can be controlled by any R2 family flash Note: Please check for the latest firmware version •... - Page 12 4. TTL: Fully Automatic Wireless Flash Shooting Autoflash Shooting with One Slave Unit Master Unit Setting • Attach a Zoom Mini TTL flash on the camera and set it as the master unit. • M/A/B/C can be set as TTL mode independently.
-
Page 13: M: Wireless Flash Shooting With Manual Flash
In case of interference from other 2.4G devices on the same frequency band causing unwanted flashes, please adjust the Zoom Mini’s channel or turn off the offending devices. 5. M: Wireless Flash Shooting with Manual Flash This describes wireless (multiple shooting) using manual flash. You can shoot with a different flash output setting for each slave unit (firing group). - Page 14 • If you set the flash coverage manually, make sure it covers the lens focal length so that the picture will not have a dark periphery. • When the low battery indicator is displayed, the ZOOM can not be adjusted, it will constantly be 24mm. •...
- Page 15 Button to exit. Note: When attaching to the camera, the auto focus assist beam of the Zoom Mini can only be triggered by setting its focus mode (M/C/S) to S mode. The other two modes cannot light up the auto focus assist beam.
- Page 16 Please send this product for maintenance The voltage of the flash tube is too high. Please send this product for maintenance Errors occurred during the upgading process. Please using the firmware upgrade method.
- Page 17 FPLFSMMINIFU Fujifilm Mirrorless Cameras 118 (ft) 36 (m) ISO 100 98 ft / 30m 2 - 13ft / 0.6-4m 2-8.2ft / 0.6-2.5m 5.5x2.5x1.5in / 140x62x38mm 7oz /200g...
- Page 18 • Shut down the device immediately if abnormal operation are detected. • The product should be kept free of dust. • It is normal for the flash tube to be warm when in use. Avoid continuous flashes if unnecessary. • If the product had failures, error messages or was exposed to moisture, do not use it until it is repaired by professionals.
-
Page 19: Compatible Camera Models
Flashpoint’s option, to repair or replace the hardware, provided that the hardware is returned to the point of purchase or such other place as Flashpoint may direct with a copy of the sales receipt or dated itemized receipt. Flashpoint may, at...
