- Page 1 Zoom Flash Manual Power FPLFSMZ...
- Page 2 Thank you for choosing Flashpoint! The new Flashpoint Zoom Speedlight with Integrated R2 Radio Transceiver is a hotshoe speedlight for on or o camera use. The incredible amount of power contained in these compact and lightweight units as well as their integrated functions and features make them the rst choice of professional photographers.
-
Page 3: For Your Safety
In certain circumstances, these materials may be sensitive to the strong light emitting from this ash unit and re may result. A whole new meaning to “Flashpoint”. • Do not leave or store the ash unit if the ambient temperature reads over 50°C (e.g. - Page 4 Product Layout Body 01. Retractable Catchlight Panel 06. R1 Wireless Control Port 02. Wide Angle Panel 07. Sync Port 03. Flash Head 08. Hotshoe 04. Optical Control Sensor 09. Lock Ring 05. Focus Assist Beam 10. Battery Compartment Control Panel Mode Selection Button / Set Button Wireless Mode Selection...
- Page 5 LCD Panel 19. < M > Manual Flash Mode 26. < > Sleep Status 20. < S1 > S1 Slave Flash Triggering 27. < > Overtemperature Indicator 21. < S2 > S2 Slave Flash Triggering 28. < > Wireless Signal 22.
- Page 6 Included Accessories 1. Flash Unit 2. Mini Stand 3. Protective Case 4. Instruction Manual Accessories Flashpoint Blast R2 Radios R1 Radios Power Pack BP-960 with Canon Cord FPPPBP960CA Flashpoint Grid Flashpoint Flash Hexapop/Parapop Flashpoint for Speelight Di user FAFD60 rapid deployment...
- Page 7 1.Power Management Use ON/OFF Power Switch to power the ash unit on or o . Turn the ash o if it will not be used for an extended period of time. This ash unit has Sleep Function and will enter into sleep status when there is no operation.
-
Page 8: Using The Flash
Using the Flash 4. M Mode: Manual Mode Press MODE Selection Button to enter M mode. In this mode, you can set the ash unit onto your camera hot shoe or use the sync port or a trigger hot shoe for ring. Before shooting, adjust the ash power output. - Page 9 Maximum Stroboscopic Flashes: Flash Output 1/16 1/32 1/64 1/128 Flash 12-14 15-19 20-50 60-199 Output 1/16 1/32 1/64 1/128 To avoid overheating and deteriorating the ash head during stroboscopic ash, do not use stroboscopic ash more than 10 times in succession. 6.
- Page 10 Hi-speed sync triggering mode is e ective only when the ash unit is used together with the following ash triggers. Flashpoint R1 HSS transceiver for Canon / Nikon with receiver. Flashpoint R2 TTL wireless ash triggers. Hi-speed sync triggering mode is not available when this ash is mounted onto the camera.
- Page 11 GR button allows the master unit to change the settings on the o camera R2 units. The Flashpoint Zoom M features an integrated R2 radio, and is compatible with the full Flashpoint R2 system. The Flashpoint Zoom M R2 radio does not require line-of-sight, and has an operating range of over 100 meters.
- Page 12 Recycle Beep, as well as trigger the ash. To control the ash wirelessly, you need a Flashpoint R1 series remote control set (Transmitter and Receiver). Insert its receiver into the Wireless Control Port (6) on the ash and insert the Transmitter onto the camera hot shoe.
- Page 13 Idle Time Meaning Sleep Function is turned o . The ash unit will not automatically enter sleep mode. Idle time before entering Sleep Mode is set to 3 minutes. Idle time before entering Sleep Mode is set to 10 minutes. Idle time before entering Sleep Mode is set to 30 minutes.
- Page 14 Protection Functions 1. Over-Heat Protection To avoid overheating and deteriorating the ash head, do not re more than 20 continuous ashes in fast succession at 1/1 full power. After 20 continuous ashes, allow a rest time of at least 10 minutes. If you re more than 20 continuous ashes and then re more ashes in short intervals, the inner over-temperature protection function may be activated and make the...
- Page 15 2. Other Protections The system provides real-time protection to secure the device and your safety. The following lists prompts for your reference: Prompts on LCD Panel Meaning A failure occurred in the temperature sensor. Please send the unit to a maintenance center. A failure occurred in the recycling system so that the ash cannot re.
- Page 16 Other Features Creating a Catchlight With the catchlight panel, you can create a catchlight in the subject’s eyes to add life to the facial expression. Point the ash head upward to 90°. Pull out the wide angle di usion panel. The catchlight panel will come out at the same time.
-
Page 17: Technical Data
Full power ashes Auto power o after 3, 10, 30, or 60 minutes, or disabled. Power saving 10 minutes by default Flashpoint Blast Power Pack BP-960 External power with Canon Cord FPPPBP960CA • Sync Triggering Mode Hotshoe, 3.5mm sync line, R1 Wireless control port •... - Page 19 For assistance, you can always email Brands@Adorama.com...
