FlashPoint FPLFSMZM Manual

Zoom flash r2 manual power with integrated r2 radio transceiver
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Zoom Flash
Manual Power
with integrated
R2 Radio Transceiver
FPLFSMZM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FPLFSMZM and is the answer not in the manual?

Questions and answers

Related Manuals for FlashPoint FPLFSMZM

Summary of Contents for FlashPoint FPLFSMZM

  • Page 1 Zoom Flash Manual Power with integrated R2 Radio Transceiver FPLFSMZM...
  • Page 2 • Stable color temperature at 5600º ±200K over the entire power range • Backlit LCD • Perfect for On and Off Camera Use • Faster Recycle with the Flashpoint Blast Pack BP-960 with Canon cord • AF Assist Lamp for faster focus • 1 Year Warranty...

  • Page 3: For Your Safety

    For Your Safety • Always keep this product dry. Do not use in rain or in damp conditions. • This product contains high-voltage electronic parts. Touching the high-voltage circuit inside it may result in electric shock. Do not disassemble. Should repairs become necessary, this product must be sent to an authorized maintenance center.

  • Page 4: Control Panel

    Body 1. Retractable Catchlight Panel 2. Wide Angle Panel 3. Flash Head 4. Optical Control Sensor 5. Focus Assist Beam 6. R1 Wireless Control Port 7. Sync Port 8. Hotshoe 9. Lock Ring 10. Battery Compartment ZOOM Control Panel 11. < >...

  • Page 5: Lcd Panel

    26 29 Multi Zoom 25 24 LCD Panel 19. < M > Manual Flash Mode 20. < S1 > S1 Slave Flash Triggering 21. < S2 > S2 Slave Flash Triggering 22. < Multi > Multi Stroboscopic Flash Mode 23. < >...

  • Page 6: Included Accessories

    Included Accessories 1. Flash Unit 2. Mini Stand 3. Protective Case 4. Instruction Manual Accessories Flashpoint Blast R2 Radios R1 Radios Power Pack BP-960 with Canon Cord FPPPBP960CA Hexapop/ Flashpoint Flashpoint Parapop Rapid Speedlight Flash Diffuser Deployment Reflector FAFD60 Softboxes...

  • Page 7: Power Management

    1. Power Management Use ON/OFF Power Switch to power the flash unit on or off. Turn the flash off if it will not be used for an extended period of time. This flash unit has Sleep Function and will enter into sleep status when there is no operation.

  • Page 8: Multi Mode: Stroboscopic Flash

    Using the Flash 4. M Mode: Manual Mode Press MODE Selection Button < > to enter M mode. In this mode, you can set the flash unit onto your camera hot shoe or use the sync port or a trigger hot shoe for firing. Before shooting, adjust the flash power output.

  • Page 9: Maximum Stroboscopic Flashes

    Maximum Stroboscopic Flashes: Output 1/16 1/32 1/64 1/128 12-14 15-19 20-50 60-199 Output 1/16 1/32 1/64 1/128 To avoid overheating and deteriorating the flash head during stroboscopic flash, do not use strobo- scopic flash more than 10 times in succession. 6.
  • Page 10 Hi-speed sync triggering mode is effective only when the flash unit is used together with the following flash triggers: • Flashpoint R1 HSS transceiver for Canon /Nikon with receiver. • Flashpoint R2TTL wireless flash triggers. Hi-speed sync triggering mode is not available when this...
  • Page 11 (the Master). Changing the displayed group using the GR button allows the master unit to change the settings on the off camera R2 units. • The Flashpoint Zoom M features an integrated R2 radio, and is compatible with the full Flashpoint R2 system.

  • Page 12: Sync Triggering

    Recycle Beep, as well as trigger the flash. • To control the flash wirelessly, you need a Flashpoint 131 series remote control set (Transmitter and Receiver). Insert its receiver into the Wireless Control Port (6) on the flash and insert the Transmitter onto the camera hot shoe.

  • Page 13: C.fn Setting Custom Functions

    • When the flash enters sleep mode, the LCD panel displays a < > icon • To wake up the flash unit, press any button on the flash unit, press the camera release button, or press the trigger TEST button Setting a shorter Idle Time will ensure longer battery life in the event the flash is not in constant use or is mistakenly left on.

  • Page 14: Protection Functions

    Protection Functions 1. Over-Heat Protection • To avoid overheating and deteriorating the flash head, do not fire more than 20 continuous flashes in fast succession at 1/1 full power. After 20 continuous flashes, allow a rest time of at least 10 minutes. •...

  • Page 15: Other Features

    2. Other Protections The system provides real-time protection to secure the device and your safety. The following lists prompts for your reference: Prompts on LCD Meaning Panel A failure occurred in the temperature sensor. Please send the unit to a maintenance center. A failure occurred in the recycling system so that the flash cannot fire.
  • Page 16 Other Features Creating a Catchlight With the catchlight panel, you can create a catchlight in the subject’s eyes to add life to the facial expression. 1. Point the flash head upward to 90°. 2. Pull out the wide angle diffusion panel.

  • Page 17: Technical Data

    Approx 650 Power saving Auto power off after 3, 10, 30, or 60 minutes, or disabled. 10 minutes by default External power Flashpoint Blast Power Pack BP-960 with Canon Cord FPPPBP960CA Sync Connection Hotshoe, 3.5mm sync line, R1 Wireless control port...
