USING THE PROJECTOR
These options are only available if the 3D mode function is disabled, the Wall Color setting is not set
to Blackboard, and the Display Mode setting is not set to DICOM SIM. or HDR SIM..
In 3D mode, user can only select 3D for Gamma setting.
If the Wall Color setting is set to Blackboard, user can only select Blackboard for Gamma setting.
If the Display Mode setting is set to DICOM SIM., user can only select DICOM SIM. for Gamma
setting.
If the Display Mode setting is set to HDR SIM., user can only select HDR SIM. for Gamma setting.
Color Settings
Configure the color settings.
BrilliantColor
enable higher brightness while providing true, more vibrant colors in picture.
Color Temperature: Select a color temperature from Warm, Standard, Cool, or Cold.
Color Matching: Select the following options:
±
Color: Adjust the red, green, black, cyan, yellow, magenta, and white level of the image.
±
Hue / R(red)*: Adjust the color balance of red and green.
±
Saturation / G(green)*: Adjust a video image from black and white to fully saturated color.
±
Gain / B(blue)*: Adjust the image brightness.
±
Reset: Return the factory default settings for color matching.
±
Exit: Exit the "Color Matching" menu.
RGB Gain/Bias: This settings allows to configure the brightness (gain) and contrast (bias) of an
image.
±
Reset: Return the factory default settings for RGB gain/bias.
±
Exit: Exit the "RGB Gain/Bias" menu.
Color Space (non-HDMI input only): Select an appropriate color matrix type from the following:
AUTO, RGB, or YUV.
Color Space (HDMI input only): select an appropriate color matrix type from the following: Auto,
RGB(0-255), RGB(16-235), and YUV.
Signal
Adjust the signal options.
Automatic: Configure automatically the signal (the frequency and phase items are grayed out). If
automatic is disabled, the frequency and phase items will appear for tuning and saving the settings.
Frequency: Change the display data frequency to match the frequency of your computer's graphic
card. Use this function only if the image appears to flicker vertically.
Phase: Synchronize the signal timing of the display with the graphic card. If the image appears to be
unstable or flickers, use this function to correct it.
H. Position: Adjust the horizontal positioning of the image.
V. Position: Adjust the vertical positioning of the image.
otee:
This menu is only available if the input source is RGB/Component.
32
English
: This adjustable item utilizes a new color-processing algorithm and enhancements to
TM
otee:
*If the Color setting is set to White, you can adjust the red color setting.
otee:
*If the Color setting is set to White, you can adjust the green color setting.
otee:
*If the Color setting is set to White, you can adjust the blue color setting.
