Sony D-FJ405 Marketing Operating Instructions Manual

Sony D-FJ405 Marketing Operating Instructions Manual

Tv/wb/fm/am portable cd player
Hide thumbs Also See for D-FJ405 Marketing:
Table of Contents

Advertisement

Quick Links

TV/WB/FM/AM
Portable
CD Player

Operating Instructions

About the area code
The area code of the location in which you purchased the CD player
is shown on upper left of the bar code label on the package.
For accessories supplied with your CD player, check the area code
of your model and see "Accessories (supplied/optional)."
Owner's Record
The model number and the serial number are located at the rear of
the CD player. Record these numbers in the spaces provided below.
Refer to them whenever you call upon your Sony dealer regarding
this product.
Model No. ____________________________
Serial No. ____________________________
D-FJ401
D-FJ405
2002 Sony Corporation
3-240-299-71 (1)
"WALKMAN" is a trademark of
Sony Corporation.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the D-FJ405 Marketing and is the answer not in the manual?

Questions and answers

Related Manuals for Sony D-FJ405 Marketing

Summary of Contents for Sony D-FJ405 Marketing

  • Page 1: Operating Instructions

    The model number and the serial number are located at the rear of the CD player. Record these numbers in the spaces provided below. Refer to them whenever you call upon your Sony dealer regarding this product. Model No. ____________________________ Serial No.

  • Page 2: Product Registration

    Product registration For the customers in the USA Please register this product on line at www.sony.com/ productregistration. <http://www.sony.com/productregistration> Proper registration will enable us to send you periodic mailings about new products, services, and other important announcements.

  • Page 3: Table Of Contents

    Table of Contents Getting started Locating the controls ... 4 Playing a CD 1. Connect your CD player..6 2. Insert a CD..6 3. Play a CD..6 Playback options Playing tracks repeatedly (Repeat play) ... 10 Playing a single track (Single play) ...

  • Page 4: Getting Started

    Getting started Locating the controls For details, see pages in parentheses. CD player (front) 1 DC IN 4.5 V (external power input) jack (pages 6, 21) 2 1 - 3 buttons (page 14) 3 Display (pages 7, 10 - 14, 17, 18) 4 PLAY MODE•...

  • Page 5: Remote Control

    CD player (inside) wd STEP switch (page 16) wf G-PROTECTION switch (page 17) Remote control (D-FJ405 only) wj VOL (volume) control (page 6) wk .(AMS/ search)•PRESET – button (pages 7, 11, 15) wl x (stop)•RADIO ON/ BAND•RADIO OFF*** button (pages 7, 12) *** To turn off the radio, hold down until the frequency indication disappears from the display.

  • Page 6: Playing A Cd

    Playing a CD You can also use rechargeable batteries or dry batteries as a power source. . Connect your CD player. 1 Connect the AC power adaptor. 2 Connect the headphones. For models supplied with the remote control • Connect the plug of the headphones to the remote control.
  • Page 7 Play (from the point you stopped) Play (from the first track) Pause/resume play after pause (for the CD player only) X Stop Find the beginning of the current track (AMS* Find the beginning of the previous tracks (AMS) Find the beginning of the next track (AMS) Find the beginning of the succeeding tracks (AMS) Go backwards quickly Go forward quickly...

  • Page 8: Removing The Cd

    About CD-Rs/CD-RWs This CD player can play CD-Rs/CD-RWs recorded in the CD-DA format*, but playback capability may vary depending on the quality of the disc and the condition of the recording device. * CD-DA is the abbreviation for Compact Disc Digital Audio. It is a recording standard used for the Audio CDs.

  • Page 9: Playback Options

    Playback options You can enjoy various ways of playback using PLAY MODE and REPEAT/ENTER. PLAY MODE button Each time you press the button, you can change the playback mode. “No indication” (Normal play) “1” (Play a single track) “SHUF” (Play tracks in random order) “PGM”...

  • Page 10: Playing Tracks Repeatedly (Repeat Play)

    Playing tracks repeatedly (Repeat play) You can play tracks repeatedly in normal, single, shuffle and PGM play modes. During playback, press REPEAT/ENTER. Playing a single track (Single play) During playback, press PLAY MODE repeatedly until “1” appears. Playing tracks in random order (Shuffle play) During playback, press PLAY MODE repeatedly until “SHUF”...

  • Page 11: Playing Tracks In Your Favorite Order (Pgm Play)

    Playing tracks in your favorite order You can program the CD player to play up to 64 tracks in your favorite order. During playback, press PLAY MODE repeatedly until “PGM” appears. Press . or N/> to select a track. Press REPEAT/ENTER to enter the selected track.

  • Page 12: Using The Radio

    Using the radio Once you’ve stored your favorite stations, you can easily tune in the station with any band and frequency setting by pressing one of the 1 - 3 buttons. Listening to the radio You can enjoy TV, WB (weather band), FM and AM programs. Press TV, WB, FM or AM to select the band (direct power-on).
  • Page 13 To improve broadcast reception For TV/WB/FM, extend the headphones cord. Headphones For AM, reorient the CD player itself. Note Keep the headphones connected to the i jack of the CD player even when listening to the TV/WB/FM program through the speakers connected to the LINE OUT jack of the CD player. The headphones cord works as the TV/WB/FM antenna.

  • Page 14: Presetting Your Favorite Radio Stations

    Presetting your favorite radio stations You can store your favorite radio stations into the CD player’s memory. You can store up to 3 stations with any band and frequency setting. Tune in the station you want. Hold down one of the 1 - 3 buttons that you want to store the new station on for 2 seconds or more.

  • Page 15: Presetting Radio Stations

    Presetting radio stations You can preset up to 51 stations: 7 for TV, 4 for WB, 30 for FM and 10 for AM. Press TV, WB, FM or AM to select the band (direct power-on). Press MEMORY for 2 seconds or more. Preset number 1 will flash in the display.

  • Page 16: Changing The Tuning Interval

    Changing the tuning interval When using the CD player abroad, change the AM tuning interval, if necessary. Set the STEP switch (inside the lid) to “9 kHz” or “10 kHz” using a pointed material. 9 kHz area: Asia and Europe 10 kHz area: the U.S.

  • Page 17: Available Features

    B Available features G-PROTECTION function The G-PROTECTION function has been developed to provide excellent protection against sound skipping during many active uses. This function provides a higher level of shock protection than the traditional one. Set G-PROTECTION (under the lid) to “ON.”...

  • Page 18: Protecting Your Hearing (Avls)

    Protecting your hearing (AVLS) The AVLS (Automatic Volume Limiter System) function keeps down the maximum volume to protect your hearing. Hold down SOUND until “AVLS” appears in the display. Displayed when AVLS function is activated. To turn off the AVLS function Hold down SOUND until “AVLS”...

  • Page 19: Turning Off The Operation Beep Sound

    Turning off the operation beep sound You can turn off the beep sound that is heard from your headphones/earphones when you operate your CD player. Remove the power source (AC power adaptor, rechargeable batteries or dry batteries) from the CD player. Connect the power source while pressing x/CHG on the CD player or x on the remote control for...

  • Page 20: Connecting Your Cd Player

    B Connecting your CD player Connecting a stereo system You can listen to CDs through a stereo system and record CDs on a cassette tape. For details, see the instruction manual that comes with the connected device. Be sure to turn off all connected devices before making connections.

  • Page 21: Connecting To A Power Source

    B Connecting to a power source You can use the following power sources: • Rechargeable batteries • AC power adaptor (see “Playing a CD”) • LR6 (size AA) alkaline batteries For the battery life and charging time of the rechargeable batteries, see “Specifications.” Using the rechargeable batteries Charge the rechargeable batteries before...
  • Page 22 Using the rechargeable batteries To remove the rechargeable batteries Remove the batteries as illustrated below. When to charge the rechargeable batteries You can check the remaining power of the batteries in the display. Battery power is full. Battery power is getting low. Battery power is low.

  • Page 23: Using The Dry Batteries

    Using the dry batteries Use only the following dry battery type for your CD player: • LR6 (size AA) alkaline batteries Note Be sure to remove the AC power adaptor when using the dry batteries. Open the battery compartment lid. Insert two LR6 (size AA) batteries by matching the 3 to the diagram in the battery compartment.

  • Page 24: Additional Information

    B Additional information Precautions On safety • Should any solid objects or liquid fall into the CD player, unplug it and have it checked by qualified personnel before operating it any further. • Do not put any foreign objects in the DC IN 4.5 V (external power input) jack.

  • Page 25: Troubleshooting

    Troubleshooting Should any problem persist after you have checked these symptoms, consult your nearest Sony dealer. CD player Symptom The volume does not increase even if the VOLUME control is adjusted to the maximum level. Cannot adjust the volume. No sound, or noise is heard.
  • Page 26 Troubleshooting CD player Symptom “Hold” appears in the display when you press a button, and the CD does not play. Cannot adjust the volume with the VOLUME control on the CD player. The CD player does not start charging. Playback starts from the point you stopped.

  • Page 27: Specifications

    Power requirements For the area code of the model you purchased, check the upper left side of the bar code on the package. • Two Sony NC-WMAA rechargeable batteries: 2.4 V DC • Sony NH-WM2AA rechargeable batteries: 2.4 V DC •...
  • Page 28 Two NC-WMAA (charged for about 3 hours**) NH-WM2AA (charged for about 4 hours**) Two Sony alkaline 47 batteries LR6 (SG) (produced in Japan) * Measured value by the standard of JEITA (Japan Electronics and Information Technology Industries Association). ** Charging time varies depending on how the rechargeable battery is used.

  • Page 29: Optional Accessories

    Should the AC power adaptor cease to function in its intended manner, during the warranty period, the adaptor should be returned to your nearest Sony Service Center or Sony Authorized Repair Center for replacement, or after warranty period, it should be discarded.
  • Page 32 This warranty is valid only in the United States. Sony Corporation Printed in China...
