SERVICE MANUAL
Ver 1.0 2000. 06
本资料由OKXIA视听皮带资源库www.okxia.cn提供
CD player
System
Compact disc digital audio system
Laser diode properties
Material: GaAlAs
Wavelength: λ = 780 nm
Emission duration: Continuous
Laser output: Less than 44.6 µW
(This output is the value measured at a distance
of 200 mm from the objective lens surface on
the optical pick-up block with 7 mm aperture.)
D-A conversion
1-bit quartz time-axis control
Frequency response
+1
20 - 20 000 Hz
dB (measured by EIAJ CP-307)
–2
Output (at 4.5 V input level)
Line output (stereo minijack)
Output level 0.7 V rms at 47 kΩ
Recommended load impedance over 10 kΩ
Headphones (stereo minijack)
Approx.5 mW + Approx. 5 mW at 16 Ω
(Approx. 1 mW + Approx. 1 mW at 16 Ω)*
*For the customers in France
Optical digital output (optical output connector)
Output level: –21 - –15 dBm
Wavelength: 630 - 690 nm at peak level
Radio (LCD remote control
with built in digital tuner)
Frequency range (STEP)
Tuner type "U"
FM: 87.5 - 108.0 MHz (100 kHz STEP)
AM: 530 - 1 710 kHz (10 kHz STEP)
Tuner type "E"
FM: 87.5 - 108.0 MHz (50 kHz STEP)
AM: 531 - 1 602 kHz (9 kHz STEP)
Tuner type "J"
FM: 76 - 90 MHz (100 kHz STEP)
AM: 531 - 1 710 kHz (9 kHz STEP)
Model Name Using Similar Mechanism
CD Mechanism Type
Optical Pick-up Name
SPECIFICATIONS
Antenna
FM: Headphones/earphones cord antenna
AM: Built-in ferrite bar antenna
General
Power requirements
For the area code of the model you
purchased, check the upper left side of the
bar code on the package.
• Two Sony NC-WMAA rechargeable
batteries: 2.4 V DC
• Sony NH-WM2AA rechargeable batteries:
2.4 V DC
• Two LR6 (size AA) batteries: 3 V DC
• AC power adaptor (DC IN 4.5 V jack):
US model: 120 V, 60 Hz
AEP, E13, EE, FR model:
220 - 230 V, 50/60 Hz
UK model : 230 - 240V, 50 Hz
E33 model : 100 - 240V, 50/60 Hz ,
HK model : 220V, 50/60 Hz
CH model : 220V, 50 Hz
• Sony DCC-E345 car battery cord for use on
car battery: 4.5 V DC
• Abbreviation
CH : Chinese model
EE : East European model
FR : French model
HK : Hong Kong model
E13 : AC220-230V area model
E33 : AC100-240V area model
FM/AM PORTABLE CD PLAYER
D-FJ75TR
Battery life* (approx. hours)
(When you use the CD player on a flat and stable
surface.)
Playing time varies depending on how the CD
player is used.
When using
Two NC-WMAA
(charged for
about 3 hours**)
NH-WM2AA
(charged for
about 4 hours**)
Two Sony alkaline 32
batteries LR6SG
* Measured value by the standard of EIAJ
(Electronic Industries Association of Japan).
** Charging time varies depending on how the
rechargeable battery is used.
Operating temperature
5°C - 35°C (41°F - 95°F)
Dimensions (w/h/d) (excluding
projecting parts and controls)
Approx. 131.6 × 25.0 × 141.4 mm
× 1 × 5
1
5
(5
in.)
4
8
Mass (excluding accessories)
Approx. 185 g (6.6 oz.)
— Continued on next page —
US Model
AEP Model
UK Model
E Model
D-E770/EJ711/EJ715
CDM-3123EBA
DAX-23E
G-PROTECTION
RADIO
on
off
on
8
7
14
18
15
30
28
50

Advertisement

Table of Contents
loading

Summary of Contents for Sony D-FJ75TR

  • Page 1 CH model : 220V, 50 Hz Operating temperature Headphones (stereo minijack) • Sony DCC-E345 car battery cord for use on 5°C - 35°C (41°F - 95°F) Approx.5 mW + Approx. 5 mW at 16 Ω car battery: 4.5 V DC (Approx.
  • Page 2: Table Of Contents

    5-4. Printed Wiring Board ························································· 12 nearest Sony Service Center or Sony Authorized 5-5. Schematic Diagram ···························································· 15 Repair Center for replacement, or after warranty period, it should be discarded.
  • Page 3: Servicing Notes

    SECTION 1 SERVICING NOTES Precautions for Checking Emission of Laser Diode NOTES ON HANDLING THE OPTICAL PICK-UP Laser light of the equipment is focused by the object lens in the BLOCK OR BASE UNIT optical pick-up so that the light focuses on the reflection surface of the disc.
  • Page 4: General

    SECTION 2 This section is extracted from instruction manual. GENERAL Getting started Locating the Controls For details, see pages in parentheses. CD player (front) 8 SOUND button 1 Display (page 18) (pages 8, 10, 11, 18, 19) 9 u (play/pause) 2 REPEAT/ENTER button button (pages 9 - 11)
  • Page 5: Disassembly

    SECTION 3 DISASSEMBLY Note : Follow the disassembly procedure in the numerical order given. 3-1. CABINET (UPPER) Main board (CN801) Five screws Three claws × 4 Flat cable 3 Cabinet (upper) (There are 7 claws.) Claw 2 Open the lid, battery case. Three claws 3-2.
  • Page 6: Electrical Adjustments

    SECTION 4 ELECTRICAL ADJUSTMENTS The CD section adjustments are done automatically in this set. Focus bias Check In case of operation check, confirm that focus bias. Condition: • Hold the set in horizontal state. Precautions for Check 1. Perform check in the order given. Connection: oscilloscope 2.
  • Page 7: Diagrams

    SECTION 5 DIAGRAMS 5-1. IC PIN FUNCTION DESCRIPTION • IC801 TMP88CM22F-TR1 (MICRO COMPUTER) Pin No. Pin Name Description — Digital GND — FOK_1 FOK input AGC PWM control (f=7.8kHz) AGCPWM_O XWRE monitor (for debug purpose on) XQOK monitor (for debug purpose on) AMUTE_O Analog mute on VCC2ON_O...
  • Page 8 Pin No. Pin Name Description — Charge pump C — Charge pump C — 0.5Vcpu input — Charge pump C — Charge pump C STOP STOP mode release signal input TEST 68kHz pull-down SCSY_0 External BB control XBACKLIGHT_O LCD backlight control RESET_I MCU reset input Crystal input from CXD3027R...
  • Page 9: Ic Block Diagrams

    D-FJ75TR 5-2. IC BLOCK DIAGRAMS 5-3. BLOCK DIAGRAM IC351 TA2120FN OPTICAL PICK-UP BLOCK DIGITAL SERVO (DAX-23E) DIGITAL SIGNAL PROC. Q501 +B SW BIAS BEEP D/A CONV. AVDD Q601 IC601 OPTICAL BIAS IN B IN A AVDD DIGITAL RFAC D OUT...
  • Page 10: Printed Wiring Board

    D-FJ75TR 5-4. PRINTED WIRING BOARD • Semiconductor Ref. No. Location CH,E,FR,HK MODEL D401 D403 IC404 D404 D803 D406 C455 D409 D410 D461 C-10 D601 CH,E,FR CH,E,FR,HK VDR801 D602 MODEL HK MODEL D801 D802 C814 C812 D803 C454 CH,E, IC301 HK MODEL...
  • Page 11: Schematic Diagram

    D-FJ75TR 5-5. SCHEMATIC DIAGRAM • Refer to page 9 for IC Block Diagrams. • Refer to page 7 for IC Pin Function Description. • Waveforms 1 TP629 (RF) (PLAY MODE) 100 mV/DIV, 200 ns/DIV 350 – 650 mVp-p 2 IC601 od (XTAI) 500 mV/DIV, 20 ns/DIV 2.1 Vp-p...
  • Page 12: Exploded Views

    SECTION 6 EXPLODED VIEWS NOTE: 6-2. MAIN SECTION 6-3. MECHANISM SECTION • -XX, -X mean standardized parts, so they may • Accessories and packing materials are given in • Abbreviation (CDM-3123EB A) CDM-3123EBA have some differences from the original one. the last of this parts list.
  • Page 13: Electrical Parts List

    SECTION 7 MAIN ELECTRICAL PARTS LIST NOTE: • Due to standardization, replacements in the • RESISTORS The components identified by mark 0 or parts list may be different from the parts All resistors are in ohms. dotted line with mark 0 are critical for safety. specified in the diagrams or the components METAL: metal-film resistor Replace only with part number specified.
  • Page 14 MAIN Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks C609 1-162-967-11 CERAMIC CHIP 0.0033uF 10% D803 8-719-069-54 DIODE UDZS-TE17-5.1B (CH,E,FR,HK) C611 1-162-917-11 CERAMIC CHIP 15PF C612 1-162-962-11 CERAMIC CHIP 470PF < FERRITE BEAD > C613 1-162-962-11 CERAMIC CHIP 470PF C614 1-162-962-11 CERAMIC CHIP...
  • Page 15 MAIN Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks Q404 8-729-425-41 TRANSISTOR 2SK1374 R301 1-216-851-11 METAL CHIP 330K 1/16W Q405 8-729-047-36 TRANSISTOR CPH3303-TL (US,AEP,UK,EE) Q406 8-729-904-86 TRANSISTOR 2SB1197K-Q R301 1-216-849-11 METAL CHIP 220K 1/16W Q407 8-729-029-14 TRANSISTOR DTC144EUA-T106 (CH,E,FR,HK) Q409...
  • Page 16 MAIN Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks R446 1-216-821-11 METAL CHIP 1/16W R639 1-216-864-11 METAL CHIP 1/16W R447 1-216-304-11 METAL CHIP 1/10W (CH,E,HK) R448 1-216-298-00 METAL CHIP 1/10W R641 1-216-864-11 METAL CHIP 1/16W R449 1-216-298-00 METAL CHIP 1/10W (CH,E,HK)
  • Page 17 MAIN Ref. No. Ref. No. Part No. Part No. Description Description Remarks Remarks Ref. No. Part No. Description Remarks < SWITCH > 1-569-007-11 ADAPTOR, CONVERSION 2P(E33) 1-756-035-11 BATTERY PACK (NC-WMAA) (CH,E13,E33,HK) S801 1-692-366-31 SWITCH, PUSH (1 KEY)(OPEN) 1-756-035-21 BATTERY PACK (NC-WMAA) (AEP,UK,FR,EE) S802 1-762-078-11 SWITCH, SLIDE (AVLS) 1-756-035-31 BATTERY PACK (NC-WMAA) (US)
  • Page 18 D-FJ57TR Sony Corporation 2000F1673-1 Audio Entertainment Group 9-927-922-11 Printed in Japan ©2000.6 — 26 — Published by PE General Engineering Dept.
