JL Audio Stealthbox SB-J-JL4DDRV/10TW1-2 Installation Manual page 2

I N C L U D E D H A R D WA R E
1
2
3
4
BOM ID Qty SKU Description
1 5 153998 5/16 - 18 Hex Nut
5/16" Split Lock Washer
2 5 150929
3 5 153997 5/16" Oversized Flat Washer
4 2 153991 5/16" Rubber Sealing Washer
5 3 153994 5/16 - 18 x 1" Hex Head Bolt
6 3 153995 5/16" Flat Washer
7 4 153996 M6 x 45mm Socket Flanged Button Screw
8 2 153992 5/16" Retaining Washer
9 1 153776 1/4" Aluminum Spacer
10 1 153976 Mounting Bracket
11 2 153990 5/16 - 18 x 1-1/4" Square Neck Carriage Bolt
- 8 154000 Fender Shield Retainer Clip (not shown)
- 8 153999 1/4" x 2-3/16" Nylon Expansion Rivet (not shown)
Page 2 • JL Audio, Inc., 2018
SB-J-JL4DDRV/10TW1 & SB-J-JL4DPAS/10TW1 INSTR_SKU# 011510
5
7 8
5 6 10 11
6 3 2 1
9
3
2
1
Continued on Next Page
