Summary of Contents for Star 404A
- Page 1 Star Manufacturing Installation International Inc. Operating 10 Sunnen Drive Instructions St. Louis, MO 63143 Phone: (314) 781-2777 Fax: (314) 781-3636 2M-Z1444 Rev. D 2/17/04 STAR-MAX COUNTER GAS FRYERS MODELS 404A, 615FA, and 630FA 615FA 630FA...
-
Page 2: Safety Symbol
Contact your local authorized service agent for service or required maintenance. Refer to the authorized service center listing provided with the unit. The Star Service Help Desk (1-800-807-9054) is available during normal business hours to answer any questions that may arise. Please have your model number and serial number for... -
Page 3: General Installation Data
GENERAL INSTALLATION DATA FRYER SHOULD BE RESTRAINED TO PREVENT TIPPING WHEN INSTALLED TO AVOID CAUTION SPLASHING OF HOT LIQUID. USE ADEQUATE TIES WHEN INSTALLING THE FRYER. This equipment is designed and sold for commercial FOR YOUR SAFETY use only by personnel trained and experienced in its DO NOT STORE OR USE GASOLINE OR operation and is not sold for consumer use in and OTHER FLAMMABLE VAPORS AND LIQUIDS... -
Page 4: Gas Piping
GAS PIPING GAS PRESSURE REGULATOR Gas piping shall be new, clean and of such size and so The regulator is factory set as specified on the rating installed as to provide a supply of gas sufficient to meet plate. If it should be necessary to check the manifold the full gas input of the appliance. -
Page 5: High Limit Thermostat
30°F (17°C). the "ON" position. c. Replace knob. Model 404A - Keep level of fat 2" (5cm) above 4. Repeat steps 1, 2 and 3 until correct. tubes. Kettle holds approximately 18 lb. (8.2kg) of fat. If solid fat is used, melt the solid fat before filling HIGH LIMIT THERMOSTAT the fryer. -
Page 6: General Maintenance Tips
7. Turn the thermostat knob to the desired frying 13. TO DRAIN KETTLE - Turn thermostat dial to the temperature. DO NOT FRY MORE FOOD PER "OFF" position. Remove baskets. Drain fat from BATCH THAN YOU CAN FRY EFFICIENTLY - kettle only when fat is warm and liquid. -
Page 7: Repairs And Service
PROPER CLEANING OF KETTLE REPAIRS AND SERVICE This appliance should only be repaired or serviced by CAUTION the factory or factory authorized personnel. CAUTION DO NOT ALLOW WATER TO GET IN HOT FAT. IT CAN EXPLODE. Moving this fryer with hot liquid is extremely 1. - Page 8 CAUTIONS FOR ALL DEEP FAT FRYERS NEVER LEAVE AN OPERATING FRYER UNATTENDED RESPECT IT! REMEMBER HOT OIL IS DANGEROUS – WARNING – MAINTENANCE WARNING – INSTALLATION • Have your equipment checked regularly to • Locate your fryer in a protected place so insure its safe and properly functioning.
- Page 9 CARE OF FAT In three to six months you may spend as much for fat A number of commercial devices and materials are as you paid for your kettle. So fat is an item you want available to aid in eliminating fat impurities. There are to know all about;...
- Page 10 HANDY FRYING CHART TIME IN FOOD COATING PROCEDURE TEMP MINUTES POTATOES Standard French Fries Cut in uniform pieces 1/2” 350° Blanch Only square the long way 350° 3-1/2 Brown Only 350° 3-1/2 Long Branch Cut in uniform pieces 3/4” square the long way 350°...
- Page 12 SOME ITEMS ARE INCLUDED FOR ILLUSTRATIVE PURPOSES ONLY AND IN CERTAIN INSTANCES MAY NOT BE AVAILABLE MODEL 404D STAR MANUFACTURING INTERNATIONAL, INC. FRYER NAT/PROP SK1396 REV. E 07-20-05...
- Page 13 Parts List May 10, 2011 Model: 404A Countertop Gas Fryer Fig NO Part No Description Application 2J-Z0601 VALVE-7000 NATURAL GAS 2J-Y9268 VALVE-7000 PROPANE 2T-Y9265 THERMOSTAT 2R-Y9086 KNOB E4-404033 DRAIN FITTING E4-Z0112 TUBE PILOT 2T-Y9266 SAFETY THERMOSTAT 2J-Y9270 THERMOPILE 2A-Y5470 ORIFICE #51 NATURAL GAS...
-
Page 14: Combustion Chamber
BODY ASSY COMBUSTION CHAMBER SOME ITEMS ARE INCLUDED FOR ILLUSTRATIVE PURPOSES ONLY AND IN CERTAIN INSTANCES MAY NOT BE AVAILABLE MODELS: STAR MANUFACTURING INTERNATIONAL, INC. SK1376 REV. B 11-06-96 615F/630F... - Page 15 Parts List May 10, 2011 Model: 615F/630F Countertop Gas Fryer Fig No Part No Description Application 2J-Z0607 VALVE-7000 NATURAL GAS 615F 2J-Y9268 VALVE-7000 PROPANE 615F 2J-Z6452 VALVE 71-502 NATURAL GAS 630F E6-Z0602 VALVE-7000 PROPANE 630F E6-Y9752 SUPPORT MANIFOLD E6-Y9802 615F SUPPORT BURNER E6-Y9803 630F...
- Page 16 Parts List May 10, 2011 Model: 615F/630F Countertop Gas Fryer (continued) Fig No Part No Description Application E6-Y9732 615F FLUE-COVER REAR E6-Y9875 630F E6-Y9729 615F FLUE-FRONT E6-Y9872 630F E6-Y9618 615F BACK COMBUSTION E6-Y9820 630F E6-Y9924 INLET PIPE SUPPORT 2K-Y9975 PIPE 3/8 NPT 21" 615F 2K-Y9976 PIPE 1/2 NPT 21"...
