Installation,
Operation, and
Maintenance Instructions
Electric Clamshell®
Model:
CSE12-208VCD
CSE12A-1-208V
CSE12A-2-208V
CSE12A-1G thru CSE12A-6G
10 Sunnen Drive
Ph: 800-438-5264 Fax: 314-781-2714
www.langworld.com
(Glass Surface)
St. Louis, MO.63143-3800
June 15, 2011
Advertisement
Table of Contents
Related Manuals for Lang Electric Clamshell CSE12-208VCD
Summary of Contents for Lang Electric Clamshell CSE12-208VCD
- Page 1 Installation, Operation, and Maintenance Instructions Electric Clamshell® Model: CSE12-208VCD CSE12A-1-208V CSE12A-2-208V CSE12A-1G thru CSE12A-6G (Glass Surface) Star Manufacturing International 10 Sunnen Drive St. Louis, MO.63143-3800 Part Number: 2M-W363 Ph: 800-438-5264 Fax: 314-781-2714 Rev. C www.langworld.com June 15, 2011...
-
Page 2: Safety
Safety Safety THE INFORMATION IN THIS MANUAL IS CRUCIAL AND MUST BE RETAINED FOR FUTURE REFERENCE. READ, UNDERSTAND AND FOLLOW THE INSTRUCTIONS AND WARNINGS CONTAINED IN THIS MANUAL. DANGER POTENTIALLY HAZARDOUS SITUATION, WHICH, IF NOT AVOIDED, COULD RESULT IN DEATH. WARNING POTENTIALLY HAZARDOUS SITUATION, WHICH, IF NOT AVOIDED, COULD RESULT IN DEATH OR SERIOUS INJURY. - Page 3 SAFETY THE UNIT IS EXTREMELY HEAVY. FOR SAFE HANDLING, INSTALLER SHOULD OBTAIN HELP AS NEEDED OR EMPLOY APPROPRIATE MATERIALS-HANDLING EQUIPMENT (SUCH AS A FORKLIFT, DOLLY OR PALLET JACK) TO REMOVE THE UNIT FROM THE SKID AND MOVE IT TO CAUTION THE PLACE OF INSTALLATION.
- Page 4 DAMAGE TO THE EQUIPMENT AND WILL VOID ALL WARRANTIES. Safety Precautions Lang manufacturer, hereby disclaims any and all responsibility for injury, damage, loss or other claim that may occur to person or property from improper alteration, modification, addition, operation, maintenance or service, whether it be mechanical, electrical, or otherwise, which may occur from such improper alteration, modification, addition, operation, maintenance or service to this piece of equipment.
-
Page 5: Table Of Contents
Table of Contents Chapter Page Safety ................................2 General Information............................6 Installation..............................7 Initial Start Up ............................... 8 Cleaning................................. 9 Hood Stop Adjustment..........................10 Parts List ..............................11-12 CSE12A-1G thru CSE12A-6G Exploded View & Parts List..............13-14 Wiring Diagram ............................ETL File 68964 Rev.A2007... -
Page 6: General Information
General Information General Information Lockout Procedure Announce lockout to other personnel. Turn power off at main panel. Test lockout by turning power switch on and observing if elements come on. Check heater circuit with voltmeter. Perform necessary repairs or tests. Clear the unit of personnel before starting the griddle. -
Page 7: Installation
Installation Installation THIS APPLIANCE MUST BE GROUNDED AT THE TERMINAL PROVIDED. FAILURE TO GROUND THE DANGER APPLIANCE COULD RESULT IN ELECTROCUTION AND DEATH. INSTALLATION OF THE UNIT MUST BE DONE BY PERSONNEL QUALIFIED TO WORK WITH ELECTRICITY AND PLUMBING. IMPROPER WARNING INSTALLATION CAN CAUSE INJURY TO PERSONNEL AND/OR DAMAGE TO EQUIPMENT. -
Page 8: Initial Start Up
Initial Start Up Initial Start Up During the first few hours of operation, you may notice a small amount of NOTICE smoke and a faint odor from the smoke. This is normal for a new unit and will disappear after the first few hours of use. Each unit is preheated, tested and calibrated at the factory prior to shipment. -
Page 9: Cleaning
Cleaning KEEP WATER AND SOLUTIONS OUT OF CONTROLS. NEVER WARNING SPRAY OR HOSE CONTROL CONSOLE, ELECTRICAL CONNECTIONS, ETC. MOST CLEANERS ARE HARMFUL TO THE SKIN, EYES, MUCOUS MEMBRANES AND CLOTHING. PRECAUTIONS SHOULD BE TAKEN TO WEAR RUBBER GLOVES, GOGGLES OR FACE CAUTION SHIELD AND PROTECTIVE CLOTHING. -
Page 10: Hood Stop Adjustment
ADJUSTMENT HOOD STOP ADJUSTMENT Units with an Adjustable Hood Stop Installed have the capablity to adjust between a 40° to 45° degree settings. These simple steps will assist you in accomplishing this. If you have diffi culty accomplishing this, please call a qualifi ed service agent or Star Manufacturing Technical Service Department. 1. - Page 11 Parts List Parts List ETL File 68964 Rev.A2007...
- Page 12 Parts List December 5, 2007, Rev. C Model: CSE12-208VCD, CSE12A-1-208V, CSE12A-2-208V Item Part Description Application CSE12-208VCD, A-1-208, A-2-208, 2N-11160-32-2 STLHTR208VXLH1600W42.5WSI A-3-208, A-4-208, A-5-208, A-6-208 CSE12A-1-240, A-2-240, A-3-240, 2N-11160-32-4 STLHTR240VXLH1600W42.5WSI A-4-240, A-5-240, A-6-240 2E-30500-02 TRM STRP 4 POLE 30A 600V 2E-30501-03 TERM STRP 4 POLE W/PUSH 2E-30705-01 CONTC 2-SPD MTR-COIL 240VA...
-
Page 13: Cse12A-1G Thru Cse12A-6G Exploded View & Parts List
Purchase these items together Model: CSE12A-1G thru CSE12A-6G CLAMSHELL HOOD GLASS SK2522, Rev. -, 6/15/2011... -
Page 14: Parts List
HANDLE ASSY. CSE12 K9-XLH-707 FOREWARD HOODWRAP ASSY 2M-60301-W2 LANG CLAMSHELL LOGO IMPORTANT: WHEN ORDERING, SPECIFY VOLTAGE OR TYPE GAS DESIRED PAGE INCLUDE MODEL AND SERIAL NUMBER Some items are included for illustrative purposes only and in certain instances may not be available. -
Page 15: Wiring Diagram
Wiring Diagram Wiring Diagram ETL File 68964 Rev.A2007... - Page 16 STAR INTERNATIONAL HOLDINGS INC. COMPANY Star - Holman - Lang - Wells - Bloomfield - Toastmaster 10 Sunnen Drive, St. Louis, MO 63143 U.S.A. (314) 781-2777 www.star-mfg.com...
