Shure SCM810 Manual

IMPORTANT SAFETY INSTRUCTIONS
1. READ these instructions.
2. KEEP these instructions.
3. HEED all warnings.
4. FOLLOW all instructions.
5. DO NOT use this apparatus near water.
6. CLEAN ONLY with dry cloth.
7. DO NOT block any ventilation openings. Allow sufficient distances for
adequate ventilation and install in accordance with the manufacturer's
instructions.
8. DO NOT install near any heat sources such as open flames, radiators,
heat registers, stoves, or other apparatus (including amplifiers) that pro-
duce heat. Do not place any open flame sources on the product.
9. DO NOT defeat the safety purpose of the polarized or grounding type
plug. A polarized plug has two blades with one wider than the other. A
grounding type plug has two blades and a third grounding prong. The
wider blade or the third prong are provided for your safety. If the provided
plug does not fit into your outlet, consult an electrician for replacement
of the obsolete outlet.
10. PROTECT the power cord from being walked on or pinched, particularly
at plugs, convenience receptacles, and the point where they exit from
the apparatus.
11. ONLY USE attachments/accessories specified by the manufacturer.
12. USE only with a cart, stand, tripod, bracket, or table specified by the
manufacturer, or sold with the apparatus. When a cart is used, use caution
when moving the cart/apparatus combination to avoid injury from tip-over.
General Description
The Shure Model SCM810/E is an eight-channel automatic microphone
mixer designed for use in sound reinforcement, audio recording, and broad-
cast applications. The SCM810 dramatically improves audio quality in any
application where multiple microphones are required. Any low-impedance
dynamic or condenser microphone (including wireless) can be used with the
SCM810/E. Multiple SCM810 mixers can be linked to other SCM810/E mixers,
as well as to Shure Models FP410, SCM410 and SCM800 mixers.
Each input channel has a two-band equalizer and three logic terminals. The
equalizer reduces unwanted low-frequency audio pickup and makes different
microphone types-lavaliers, boundary and handheld-sound similar. The logic
terminals can be used to control external devices. The SCM810 operates on
120 Vac power; the SCM810E operates on 230 Vac power. Each mixer is
supplied with a power cord, rack-mounting hardware, and a link cable.
Operating Principles
©2017 Shure Incorporated
13. UNPLUG this apparatus during lightning storms or when unused for long
periods of time.
14. REFER all servicing to qualified service personnel. Servicing is required
when the apparatus has been damaged in any way, such as power
supply cord or plug is damaged, liquid has been spilled or objects have
fallen into the apparatus, the apparatus has been exposed to rain or
moisture, does not operate normally, or has been dropped.
15. DO NOT expose the apparatus to dripping and splashing. DO NOT put
objects filled with liquids, such as vases, on the apparatus.
16. The MAINS plug or an appliance coupler shall remain readily operable.
17. The airborne noise of the Apparatus does not exceed 70dB (A).
18. Apparatus with CLASS I construction shall be connected to a MAINS
socket outlet with a protective earthing connection.
19. To reduce the risk of fire or electric shock, do not expose this apparatus
to rain or moisture.
20. Do not attempt to modify this product. Doing so could result in personal
injury and/or product failure.
21. Operate this product within its specified operating temperature range.
This symbol indicates that dangerous voltage constituting a risk of
electric shock is present within this unit.
This symbol indicates that there are important operating and
maintenance instructions in the literature accompanying this unit.
WARNING: This product contains a chemical known to the State of California
to cause cancer and birth defects or other reproductive harm.
WARNING: Voltages in this equipment are hazardous to life. No user-ser-
viceable parts inside. Refer all servicing to qualified service personnel. The
safety certifications do not apply when the operating voltage is changed from
the factory setting.
System Features
• Fast-acting, noise-free microphone selection that automatically adjusts
to changes in background room noise
• Automatic gain adjustment as additional microphones are activated
• Last Mic Lock-On circuit that maintains ambient sound
• Adjustable low-frequency rolloff and high-frequency shelving for each
channel
• Channel activation and clipping indicators
• Peak-responding output limiter with selectable thresholds and LED indi-
cator
• Active balanced mic/line inputs and line/level output
• Aux-level input with manual level control
• Front-panel headphones output with level control
• Linking capability for up to 400 microphones
SCM810
Eight-Channel Microphone Mixer
1/13
