Audio Frequency Response
80 to 15,000 Hz 3 dB
NOTE: Overall system response depends on microphone element used.
Operating Temperature Range
EC1: –18 to 50 C (0 to 122 F)
T1: –20 to 50 C (–4 to 122 F)
NOTE: Battery characteristics may limit these ranges.
T1 a n d E C 1 B ODY-PAC K T RANSMITTER S A N D T2 a n d E C 2
HAND-HEL D M ICROPHONE-TRANSMITTERS
RF Power Output
50 mW maximum
Input Impedance (T1, EC1, only)
Actual: 17 kΩ, pin 4 wired to pin 3 for condenser microphones
Gain Adjustment Range
T1, T2, EC1: 40 dB (0 dB counterclockwise, 20 dB mid, 40 dB clockwise);
EC2: 15 dB (2–position switch)
Power Requirements
EC1, EC2 Battery Life: 7.5 hours typical (alkaline); 1.5 hours typical (8.4 V nicad, per
charge)
T1, T2/58 Battery Life: 18 hours typical (alkaline); 2 hours typical (8.4 V nicad, per
charge)
Overall Dimensions
EC1*: 82.6 mm H x 63.5 mm W x 26.2 mm D (3
T1: 64 mm H x 106 mm W x 24 mm D (2
T2/58,EC2/58**: 237 mm L x 50.8 mm D (9
*Excluding antenna and belt clip.
**Excluding antenna.
Weight
Model Without Battery
T1,EC1 96.4 g (3.4 oz)
T2/58 296 g (10.4 oz)
EC2/58 454 g (16 oz)
Certifications
T1, T2: FCC Type Accepted, Parts 74 and 90 (U.S.A.); IC Certified TRC-78
(Canada)
EC1; EC2: FCC Type Accepted, Parts 74 and 90 (U.S.A.); IC Certified TRC-78
(Canada): MPT 1345, MPT 1350 (UK); BZT Certified (Germany)
VP3 RECEIVER
RF Sensitivity
–109 dBm (0.8 µV for 12 dB SINAD typical)
Image Rejection
50 dB typical
Spurious Rejection
65 dB typical
Signal to Noise Ratio
87 dB (1 mV RF input, 1 kHz modulation, 15 kHz deviation)
Squelch Quieting
87 dB, A–weighted
Ultimate Quieting
87 dB (–40 dBm RF input)
1 1 1
/ x 2 / x 1 / in.)
4 2 32
17 3 31
/ x 4 / x / in.)
32 16 32
5
/ x 2 in.)
16
With Battery
142 g (5.0 oz)
338 g (11.9 oz)
496 g (17.5 oz)
8
Mic Level Audio Output
5 dBV typical, 600 Ω, (fixed level, 15 kHz deviation input, 1 kHz test tone).
–36
Monitor (Headphones) Output
80 mW at 100 mA, 3% THD
Power Requirements
9 V alkaline battery or 12 Vdc (at 100 mA load) through external coaxial jack.
Battery Life: 7 hours (typical)
Dimensions (not including antenna)
4.9" H x 2.375" W x 0.875" D
Weight (including battery)
170.2 grams (8 oz .)
Certification
FCC Type Accepted, Part 15; IC (Canada) Certified RSS–121

FURNISHED ACCESSORIES

Screwdriver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
TA3F to 3.5 mm Stereo Mini Phone Plug Cable
Shoe Adapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

OPTIONAL ACCESSORIES

Microphone Adapter Cable (T1/EC1)*
In-Line Audio Switch (T1/EC1)
TA3F to 3-Pin XLR (Balanced) Cable
System Carrying/Storage Bag
AC Adapter (120 VAC)
AC Adapter (230 VAC)

REPLACEMENT PARTS

Body-Pack Belt Clip (EC1)
Miniature 4-Pin Connector (T1/EC1)
Hook-and-Loop (VELCRO-type)
Shoe Adapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
*3–pin female XLR to 4–pin TA4F.
Changes or modifications not expressly approved by Shure Brothers Inc. could
void your authority to operate the equipment.
.
Shure Model T1, T2, EC1, and EC2 Transmitters are Type-Accepted under FCC
Parts 90 and 74. The Model VP3 Receiver is approved under FCC Part 15.
IMPORTANT: Licensing of Shure wireless microphone equipment is the
user's responsibility, and licensability depends on the user's classification
and application, and on the selected frequency. Shure strongly urges the user
to contact the appropriate telecommunications authority concerning proper
licensing.
www.audiovias.com
. . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fastener Strips . . . . . . . . . . . . . . .
CAUTION

FCC LICENSING INFORMATION

9
65A1659
WA460
65A8188
WA310
WA360
WA450
WA395
PS20
PS20E
53A8247A
WA330
90KX2600
65A8188
