2 Product Introduction

2.1 Camera Introduction
PROVISION-ISR's new series of cameras have
adopted a high performance CMOS image sensor,
which provides mega pixel resolution and supports HD
video. Moreover, it supports monitoring signals coaxial
transmission. Transmission distance can reach more
than 300M based on 75-3 coaxial cable. The series
can support all HD analog resolutions: AHD/TVI/CVI
as well as CVBS 960H output.
2.2 Product Features
● Coaxial cable with BNC connector
● DIP Switch for output selection
● Auto Day/Night (ICR)
● BLC
● 2D-DNR
● AHD/TVI/CVI/CVBS Signal Selectable
● PAL/NTSC (System Selectable by DIP switch)
4

3 Menu Setup

AHD/TVI: Click on "Iris+" button from the DVR's PTZ
interface to call the OSD Menu. Use the PTZ interface to
scroll through the menu and "Iris+" to confirm.
CVI: Click " ►" button from the DVR's PTZ interface,
then click " " and press "Enter" to call the OSD Menu.

4 Product Installation

4.1 General Notes
1. Make sure the unit is powered off before installation.
2. Check power supply voltage consistent with the
electric voltage to prevent voltage unworthy, resulting in
damage to the device.
3. Do not use in the environment beyond the boundaries
of the temperature, and maintain good ventilation to
prevent the rain in order to reduce the risk of fire or
electric shock.
4. The installation and maintenance of this product
should be professional, please do not in any way to
