LABCYTE INC.
Echo® 650 Series Liquid Handler
(Models: 650, 655, 650T, 655T)
SITE PREP GUIDE
Server Version 3.1 | FEBRUARY 2019
This guide provides site preparation information for the Echo® 650 Series Liquid Handler. This includes models 650, 655, 650T
and 655T. The topics below describe the site preparation requirements and instrument specifications for the Echo Liquid
Handlers.
l
l
l
l
l
l
l
l
l
Junair Compressor (Optional and sold separately by Labcyte)
l
Vacuum Pump (Optional and sold separately by Labcyte)
l
Client Pc (Sold separately by Labcyte)
l
© 2019 LABCYTE INC. All rights reserved.
|
SITE PREP GUIDE
Echo® 650 Series Liquid Handler
QSG-2019-1
FEB 2019
Advertisement
Table of Contents
Related Manuals for Labcyte Echo 650 Series
Summary of Contents for Labcyte Echo 650 Series
- Page 1 Power Ratings What You Will Be Receiving Shipping Dimensions Echo Liquid Handler Components Chiller Junair Compressor (Optional and sold separately by Labcyte) Vacuum Pump (Optional and sold separately by Labcyte) Client PC (Sold separately by Labcyte) Pre-Installation Requirements Verification Form QSG-2019-1 ©...
- Page 2 Compressed air source Maximum consumption by Echo Liquid Handler does not exceed 1 cfm at 150 PSI Note: The Junair OF302-4B oil-less compressor can be purchased from Labcyte (Part #001-12164). For more information, see the Junair Compressor (Optional and sold separately by Labcyte)
- Page 3 10 64-bit; Intel® Core™ 2 Duo processor or later; 1GB of RAM or greater; 1 GB of available disk storage; display resolution of 1280 x 1024 (1920x1020 preferred); 2 x Gigabit ethernet ports Note: Client PC can be purchased directly from Labcyte (Part #ECHO-Client Computer). For information on the Client PC available from Labcyte, see the Client PC (Sold separately by Labcyte) topic.
- Page 4 Intel Core™ i5 processor or better. Note: If you are setting up an Echo 650T or 655T Liquid Handler that will be using tubes, a capper/decapper is required before Labcyte Service and Support can install or service the instrument.
- Page 5 Note: The instrument can be installed with a minimum of 2.5 cm (1 in) at the top if there is sufficient space to lift the top and slide it all the way forward. Talk to your Labcyte service representative for additional details.
- Page 6 SITE PREP GUIDE | Echo® 650 Series Liquid Handler PN | 001-16480 Figure 1: Instrument Layout (Front View, Top View, Side View) Noise Ratings The noise ratings for the Echo Liquid Handler are below: Noise Rating 64 dBA Power Ratings The power ratings for the Echo Liquid Handler are below: Power Rating 600W without the chiller...
- Page 7 SITE PREP GUIDE | Echo® 650 Series Liquid Handler PN | 001-16480 What You Will Be Receiving Shipping Dimensions The Echo Liquid Handler System is shipped in a crate with the following dimensions: Instrument shipping crate weight 278 kg (577 lbs) Instrument shipping crate 114.3 cm width x 99.1 cm depth x 124.8 cm height (45 x 39 x 49.1 inches) dimensions...
- Page 8 SITE PREP GUIDE | Echo® 650 Series Liquid Handler PN | 001-16480 Chiller The SMC chiller (P/N 001-11149) is included with your Echo system. The SMC chiller utilizes a stainless steel thermoelectric (Peltier) heat exchanger that regulates fluid temperature. The SMC chiller ships configured for operation with Echo Liquid Handlers: The SMC chiller uses an auto switching power supply capable of running any single-phase AC voltage in the range 100-240V, 50-60 Hz Power Supply...
- Page 9 The user must also provide a fitting between the compressed air supply and the Echo Liquid Handler. Labcyte provides the compressed air line and fitting with the Echo Liquid Handler, but the customer must provide a source compatible with 170 in ID/.250 in OD tubing.
- Page 10 SITE PREP GUIDE | Echo® 650 Series Liquid Handler PN | 001-16480 Figure 3: Junair OF302-4B oil-less compressor...
- Page 11 Customers must provide a fitting that connects the vacuum source and the Echo Liquid Handler vacuum line. The supplied vacuum line is HercoBraid, 9.5 mm (3/8 in) ID, 9.5 mm (5/8 in) OD (RyanHerco P/N 0512-072). A standalone Vacuubrand MZ 2S-NT vacuum system can be purchased from Labcyte (Part #001-8104). This vacuum is a dual voltage/cycle compatible system.
- Page 12 Optionally, the following Echo software applications are available for purchase: Echo Plate Reformat Echo Dose-Response Echo Cherry Pick Echo Array Maker Echo Plate Audit Echo Combination Screen Note: Echo 650 Series Liquid Handlers require Echo software applications version 1.7 or higher.
- Page 13 Representative or email support@labcyte.com. Echo® Liquid Handlers, Applications Software and Automation Systems from Labcyte Inc. are covered by one or more of the following patents: United States: 6,416,164; 6,548,308; 6,603,118; 6,612,686; 6,642,061; 6,666,541; 6,707,038; 6,710,335; 6,746,104; 6,802,593; 6,808,934; 6,809,315; 6,849,423; 6,855,925; 6,869,551;...
