Pakedge WA-2200-C User Manual

Pakedge WA-2200-C User Manual

802.11ac 2x2 wave 2 access point
Hide thumbs Also See for WA-2200-C:

Advertisement

WA-2200 Series
WA-2200, WA-2200-1,
WA-2200-C, WA-2200-C-1
802.11ac 2x2 Wave 2 Access Point
User Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WA-2200-C and is the answer not in the manual?

Questions and answers

Summary of Contents for Pakedge WA-2200-C

  • Page 1 WA-2200 Series WA-2200, WA-2200-1, WA-2200-C, WA-2200-C-1 802.11ac 2x2 Wave 2 Access Point User Guide...
  • Page 2: Table Of Contents

    WA-2200 Series User Guide Contents Regulatory notices ..................................1 Introduction ....................................3 System requirements ................................3 Hardware installation ................................3 Default settings and credentials ..........................3 First-time login ..................................... 3 Configure ......................................4 Overview ......................................5 Connections ....................................6 Backup/Restore ................................... 6 Logs ........................................
  • Page 3: Regulatory Notices

    WA-2200 Series User Guide Regulatory notices FCC notice: Any changes or modifications not expressly approved by the party responsible for compliance could void your authority to operate the equipment. FCC Class B: Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
  • Page 4 WA-2200 Series User Guide ISED (IC) 5G caution Operations in the 5.15-5.25 Ghz band are restricted to indoor usage only. Le fonctionnement sur la bande 5,15–5,25 Ghz est limité à une utilisation intérieure uniquement. FCC/ISED (IC) RF Radiation Exposure Statement: (For MPE report) This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment.
  • Page 5: Introduction

    WA-2200 Series User Guide Introduction As the central component of your wireless network, the WA-2200 802.11ac 2x2 Wave 2 Access Point provides you with high-speed, high-range wireless 8012.11ac networking. The AP broadcasts on both the 2.4 GHz and 5 GHz bands so that select devices can choose their preferred source of wireless connectivity, improving the overall stability, reliability, and performance of the wireless network.
  • Page 6: Configure

    WA-2200 Series User Guide Configure The Configure tab allows you to change the most common AP settings in one screen. This is the default tab that displays after login. • Username and Password: The first time you log in, you should change these from the defaults (“admin”...
  • Page 7: Overview

    WA-2200 Series User Guide • DNS Settings: • DNS Server (server’s IP address): For a static IP network, enter up to two DNS server IP addresses here. For a DHCP network, these fields are read-only. • 5 GHz Networks and 2.4 GHz Networks, and guest networks: Enter an SSID (wireless network name), the authentication type to use, the WiFi password, and the VLAN this wireless network is associated with.
  • Page 8: Connections

    WA-2200 Series User Guide Connections The Connections tab displays a list of connected wireless devices. Click any column head to sort the list by that field. Available fields are: • Hostname • IP Address • MAC Address • Manufacturer • Connected To •...
  • Page 9: Logs

    WA-2200 Series User Guide • Save Configuration: Click to save a file that contains all of this AP’s settings. • Choose File: Click to select a saved configuration backup file to use for restoring settings. • Restore: Click to restore AP settings using the selected configuration backup file. Logs The Logs tab displays a record of system events effected by the AP.
  • Page 10: Lan Settings

    WA-2200 Series User Guide • Diagnostic Tools • Ping: Select to ping a device at the indicated address. • Traceroute: Select to run a traceroute to the indicated address. LAN Settings Click this tile to configure the advanced LAN port settings, such as management VLAN and STP.
  • Page 11 WA-2200 Series User Guide • Wireless Settings • Band Steering: Band steering steers 5 GHz-capable clients to that frequency. By enabling this function, the 2.4 GHz SSID and settings will be copied to the 5 GHz band. • RF Scan: Click to perform an automatic site survey of RF signals. The AP will scan the channels for connected devices and will then display them in a table.
  • Page 12 WA-2200 Series User Guide • Auto: This setting adjusts the power of the AP based on the distance to the furthest client device. • 11 dBm (13mW) – 24 dBm (252mW): These are static power settings. The AP will broadcast at the selected power level. •...
  • Page 13: Access Control

    WA-2200 Series User Guide Access Control Click this tile to set up access control for connected clients. To add a client for access control, click Add, then select the client and click Apply. The client and its identifying information are added to the Access Control list. Click any column head to sort the list by that field.
  • Page 14: Bakpak Lite

    WA-2200 Series User Guide If your firmware is up to date, this screen shows your current firmware version and provides a link for that firmware’s release notes. If a firmware update is available, this screen also shows the update version and the update’s release notes.
  • Page 15: Reset To Factory Default Settings

    WA-2200 Series User Guide Reset to factory default settings While setting up or troubleshooting, you may need to reboot the AP or restore it to its factory default settings. Caution: Do not power off the AP during a factory reset. Reset using the interface To only restart the AP, maintaining all settings: In the Overview or Connections tab, click Software Reset.
  • Page 16 Visit Us At: www.pakedge.com Copyright ©2018, Control4 Corporation. All rights reserved. Control4, Pakedge, Triad, and their logos are registered trademarks or trademarks of Control4 Corporation in the United States and/or other countries. 4Store, 4Sight, Control4 My Home, Mockupancy, and BakPak are also registered trademarks or trademarks of Control4 Corporation.
