Tait TM8260 Getting Started Manual

This guide contains a summary of important tasks when setting up a TM8260 radio
system. You must read this information before attempting to install and program
TM8260 radios. This guide, and all other technical documentation, is available from
the Technical Support web site: http://support.taitworld.com
Figure 1: TM8260 installation overview
Antenna
Power supply
Speaker
C
E
F
H
I J
1)
1!
For more information: refer to the TM8260 installation and programming
guide (MMA-00041-xx).
MMA-00047-01
B
D
G
1@
Microphone
Getting Started Guide
B External speaker (x2)
(TMAA10-03)
C Cross-band linking, GPS, and
Antenna
external interface cable
(TMAA04-06)
Power supply
D Primary radio body
(e.g. TMAB22-B100B)
B
Speaker
E Second radio body
1#
External I/F
(e.g. TMAB22-H600B)
F Body remote interface
1$
GPS
(TMAC31-0T)
G Body remote interface with
link J4 removed
H Connector seal
I Radio connecting cable,
maximum length 1.5m
(TMAA04-03)
J Radio/control head
connecting cable, maximum
length 6m (TMAA04-01)
1) Control head remote
interface (TMAA03-03A)
1! Control head (TMAC40-1T)
1@ Any supported microphone
Optional
(e.g. keypad microphone
Required
TMAA02-08)
1# External auxiliary interface
(e.g. external alert)
1$ GPS antenna/receiver
(TMAA05-01) with plate
mount (TMAA05-03) or mag-
netic mount (TMAA05-04)
TM8260 mobiles
