Kramer K-NET RC-53D User Manual

Auxiliary control panel
Hide thumbs Also See for K-NET RC-53D:

Advertisement

Quick Links

Kramer Electronics, Ltd.
USER MANUAL
Model:
RC-53D
K-NET™ Auxiliary Control Panel

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the K-NET RC-53D and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Kramer K-NET RC-53D

  • Page 1 Kramer Electronics, Ltd. USER MANUAL Model: RC-53D K-NET™ Auxiliary Control Panel...
  • Page 2: Table Of Contents

    Contents Contents Introduction Getting Started Overview Defining the RC-53D Using the RC-53D K-NET Auxiliary Control Panel Installing the RC-53D Faceplate, Button Caps and Labels Operating the RC-53D K-NET Auxiliary Control Panel Technical Specifications Figures Figure 1: RC-53D K-NET Auxiliary Control Panel – Front Panel Figure 2: RC-53D K-NET Auxiliary Control Panel –...
  • Page 3: Introduction

    Converters and Scalers; GROUP 8: Cables and Connectors; GROUP 9: Room Connectivity; GROUP 10: Accessories and Rack Adapters; GROUP 11: Sierra Products 2 K-NET is a proprietary Kramer protocol for communication between Kramer products 3 Download up-to-date Kramer user manuals from...
  • Page 4: Overview

    • Avoid interference from neighboring electrical appliances and position your Kramer RC-53D away from moisture, excessive sunlight and dust 1 Such as the Kramer SummitView System or the SL-1 Master Room Controller 2 Available in two height sizes: 8 6cm and 8cm...
  • Page 5: Defining The Rc-53D

    Defining the RC-53D Defining the RC-53D Figure 1 Table 1 define the RC-53D front panel. Version for the US Version for Europe Figure 1: RC-53D K-NET Auxiliary Control Panel – Front Panel Table 1: RC-53D K-NET Auxiliary Control Panel – Front Panel Features Feature Function SOURCE Buttons...
  • Page 6: Figure 2: Rc-53D K-Net Auxiliary Control Panel - Rear Panel

    1 When the unit is connected via K-NET to a Master Room Controller, you can upgrade the firmware via the USB or ETH ports of the Master Room Controller 2 The ground connection is sometimes connected to the shield of the RS-485 cable (in most applications, it is not connected) KRAMER: SIMPLE CREATIVE TECHNOLOGY...
  • Page 7: Using The Rc-53D K-Net Auxiliary Control Panel

    Green = A = +12V Figure 3: RC-53D connected to the SV-551 SummitView™ Processor / Switcher 1 By authorized Kramer technical personnel or by an external system integrator 2 Power supplies are sold separately Consult your Kramer dealer for details...
  • Page 8: Installing The Rc-53D Faceplate, Button Caps And Labels

    6. Place the faceplate on the RC-53D so that the four screw mounting holes are aligned. 7. Insert the four mounting screws and tighten with a screwdriver. 8. Install the volume control knob. Figure 5: Button Cap Orientation KRAMER: SIMPLE CREATIVE TECHNOLOGY...
  • Page 9: Operating The Rc-53D K-Net Auxiliary Control Panel

    Operating the RC-53D K-NET Auxiliary Control Panel Operating the RC-53D K-NET Auxiliary Control Panel In the following example (illustrated in Figure 6 ), the auxiliary control panel is labeled with specific functions and each button is programmed to perform several tasks as defined in Table 3...
  • Page 10: Technical Specifications

    For Europe: 15.2cm x 1.9cm x 8.6cm (5.98" x 0.75" x 3.39", W, D, H) or 15.2cm x 1.9cm x 8cm (5.98" x 0.75" x 3.15", W, D, H) WEIGHT: 0.14kg (0.31lbs.) approx. ACCESSORIES: Screwdriver 1 Specifications are subject to change without notice KRAMER: SIMPLE CREATIVE TECHNOLOGY...
  • Page 11 EXCLUSION OF DAMAGES The liability of Kramer for any effective products is limited to the repair or replacement of the product at our option Kramer shall not be liable for: Damage to other property caused by defects in this product, damages based upon inconvenience, loss of use of the product, loss of time, commercial loss;...
  • Page 12 For the latest information on our products and a list of Kramer distributors, visit our Web site www.kramerelectronics.com where updates to this user manual may be found. We welcome your questions, comments and feedback. Safety Warning: Disconnect the unit from the power supply before opening/servicing.
