Leonard TM-2020B-2P Installation Adjustment Service

INSTALLATION ADJUSTMENT SERVICE
TM-1520A-2P, TM-2020B-2P PARALLEL
IMPORTANT! Provide serial numbers for both valves when ordering parts!!
46"
LEONARD
THERMOSTATIC
ASSE
1 0 1 7
HOT
33
TM-2020B-2P
1. Type TM Parallel Systems are factory pre-assembled and
tested and include large and small thermostatic water
mixing valves which function as a system to meet both
high and low demand for tempered water.
2. System should be installed at a location where it can
easily be cleaned, adjusted or repaired.
3. System supplies must be connected as shown (Hot-left,
Cold-right). Exercise caution when soldering.
Maximum Operating Pressure 125PSI (860 KPA) for Hot and Cold Water.
All thermostatic water- mixing valves have limitations. They will not provide the desired
accuracy outside of their flow capacity range. Consult the capacity chart on page 12. Minimum
flow must be no less than as shown.
SYSTEMS
Note: Each individual valve assembly is ASSE 1017 listed.
INSTALLATION
2 0
3 0
L E O N A R D
1 0 R
4 0
0
- 1 0 5 0
° C 6 0
0 ° F
LEONARD
THERMOSTATIC
C
A S S E
1 0 1 7
L
COLD
1
"
2
CAUTION
1360 Elmwood Avenue, Cranston, RI 02910 USA
Phone: 401.461.1200 Fax: 401.941.5310
Email: info@leonardvalve.com
Web Site: http://www.leonardvalve.com
LEONARD VALVE CO.
CRANSTON RI USA
T Y P T M
US. Patents 2.970, 3,061,195 3.152,760
3"
HOT
TM-1520A-2P
4. Flush pipes thoroughly after system has been
connected.
5. Assemblies installed on a recirculated hot water system
MUST be piped
REQUIRED PIPING METHOD #5 (see page 4).
6. Refer to page 3 of this bulletin for correct Setup
Instructions.
Bulletin G10N2
February 2007
2 0 3 0
1 0
L E O N A R D 4 0
R
0
-10 5 0
6 0
° C
° F
0
39"
LEONARD VALVE CO.
CRANSTON RI USA
T Y P T M
US. Patents 2.970, 3,061,195 3.152,760
28"
COLD
according to LEONARD'S
