- Page 1 Drawing No. :- TPC252 Issue :- 1 Date :- 13/10/03 EBAC MODEL CD425 (1018110) INDUSTRIAL DEHUMIDIFIER OWNER’S MANUAL CD425 OWNERS MANUAL...
- Page 2 :- 13/10/03 UNPACKING Carefully remove the CD425 dehumidifier unit from its packing and visually check for signs of transit damage. If there is evidence of damage DO NOT attempt to operate the unit, call your supplier for advice. Do not discard the packing, as it will be useful when transporting the dehumidifier unit in the future.
-
Page 3: Specifications
SPECIFICATIONS CD425 ODEL 1190 mm EIGHT 1100 mm IDTH 460 mm EPTH 160 kg EIGHT 1750 CFM IRFLOW (3000M/Hr) 6.0Kw (MAX) OTAL OWER AXIMUM PERATING 35ºC (95ºF) EMPERATURE 220V 3PH 60hz OWER UPPLY R407c EFRIGERANT 2.5Kg HARGE CD425 OWNERS MANUAL... -
Page 4: Operation
:- 13/10/03 OPERATION The CD425 is a self contained low temperature dehumidifier. All electrical contactors, overloads, etc are housed in an electrical box built inside the unit. The unit is equipped with a defrost valve which energized every 42 minutes to clear any ice formation on the evaporator coils. - Page 5 SYSTEM INSALLATION POSITIONING Position the CD425 in the area leaving enough room either end of the unit to allow for easy servicing. Using a spirit level ensure the level in both direction. Failure to do so may result in the drain tray overflowing and flooding of the chamber.
- Page 6 F ANY OF THE PRECEDING PROBLEMS OCCUR CONTACT THE ERVICE ENTER PRIOR TO CONTINUED OPERATION OF THE UNIT TO PREVENT PERMANENT DAMAGE CD425 OWNERS MANUAL...
- Page 7 An open circuit indicates that the compressor should be replaced. c. Check that the compressor is not grounded by establishing that a circuit does not exist between the compressor terminals and the shell of the compressor. CD425 OWNERS MANUAL...
-
Page 8: Troubleshooting
1. Clear the obstruction, straighten or Water flooding inside the 1. Drain pipe blocked/frozen replace machine 2. Drain pipe too high 2. No section of the drainage pipe Ebac Industrial Products, Inc. 700 Thimble Shoals Blvd, Suite 109 Newport News, VA. 23606-2575 CD425 OWNERS MANUAL... -
Page 9: Spare Parts List
Solenoid Coil 3030402 Humidistat 1132200 Momentary Switch 3030634 Indicator Lamp Holder 3034513 12V 100ma Lamp 3034522 Humidistat Control Knob 2017707 Contactor 037H0021 3030355 Contactor 037H0041 3030362 Relay 3030270 Overload 3032646 Transformer 3031129 Delay Timer 1602400 Defrost Timer 1601200 CD425 OWNERS MANUAL... -
Page 10: Limited Warranty
Our products carry a one-year unconditional warranty against any defects in workmanship or material. This warranty will cover all parts and labor required to repair your Ebac product. This warranty is invalid if the unit has been abused, damaged, whether intentional or accidental, or if any modifications have been made to the unit.
