TROUBLESHOOTING
The following items are the most common tool symptoms if problems occur. For symptoms or
remedies not shown, contact your Signode service representative for additional information and
details. The following tool symptoms are shown in this manual:
#1 - Tool runs sluggishly.
#2 - Filter-regulator-lubricator is maintained but still runs sluggishly
#3 - Motor does not pick up speed when oiled.
#4 - Air motor continues to run after sealing/cut-off cycle is completed.
#5 - Low joint strength.
#6 - Sealer valve sticks or leaks.
#7 - Tool will not cut off strap.
#8 - Feedwheel milling on strap.
#9 - Seal pulls open during tensioning.
#1 SYMPTOM: The tool runs sluggishly.
CAUSE
1. The air filter-regulator -lubricator is malfunctioning
and is not properly maintained.
#2 SYMPTOM: The filter-regulator lubricator is properly maintained but the tool still runs
sluggishly.
CAUSE
The motor is dry, hindering it from providing maximum
performance.
#3 SYMPTOM: The motor does not pick up speed with the addition of oil.
CAUSE
The tool may run sluggishly due to clogged or dirty
motor filter screen due to a lack of properly filtered air
supply.
#4 SYMPTOM: Air motor continues to run after sealing/cut-off cycle is completed.
CAUSE
Excessive air line pressure.
REMEDY
1.
Check the regulator to see that the correct air
pressure is getting to the tool.
2.
Check to see the filter unit is clean and
functioning properly.
3.
Examine the lubricator to see there is oil
in the bowl and that the oil is seen
dripping from the sight dome as the tool
operates. This assures the air motor is
being properly lubricated.
REMEDY
Pour a teaspoon of oil into the motor through the air
inlet, hook the tool up to air and run it. An increase of
speed indicates the motor was dry.
REMEDY
Remove the Hansen plug at the inlet to the air motor
and examine the filter screen in the air strainer and
clean it if necessary. See instructions on installing the
Hansen plug.
REMEDY
Install Filter-Regulator-Lubricator near tool. Reduce air
pressure to 90 psi (6.2 bar) maximum.
16
