Operation; Power On/Off; Volume Button - Lippert Components OneControl Programming Manual

operation

Power On/Off

1. To power ON the tablet, hold and release the power button for 2-3 seconds (Fig. 25).
NoTe: It will take a few moments to start up and load the system.
2.
To enter or exit sleep mode, press and release power button.
3. To power OFF the tablet, press and hold the power button until a utility screen appears.
4.
Select "Power off".
5.
Press "OK" when confirmation box displays: "Your tablet will shut down." (Fig. 27).

Volume Button

1.
Volume control is located on the side of the tablet (Fig. 25). There is also a volume icon on the menu
screen.
Microphone
Power Button
Headphone Jack
Micro USB
Charging Port
Volume Control
Rev: 08.06.18
Fig. 25
TF/Micro SD
Card Port
Reset
Fig. 27
Page 9
Fig. 26
CCD-0001736
