ClonerAlliance HDML-Cloner Box Turbo CA-988BT User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HDML-Cloner Box Turbo CA-988BT and is the answer not in the manual?

Questions and answers

Related Manuals for ClonerAlliance HDML-Cloner Box Turbo CA-988BT

Summary of Contents for ClonerAlliance HDML-Cloner Box Turbo CA-988BT

  • Page 2 ClonerAlliance Inc. Trademarks HDML® is a registered trademark of ClonerAlliance Inc.
  • Page 3 Safety Notices Before using HDML-Cloner Box Turbo, please ensure that you read and understand the safety precautions below: 1. Do not attempt to open the case of HDML-Cloner Box Turbo or modify it in any way, as this will void the warranty. 2.

  • Page 4: Table Of Contents

    Table of Contents Getting Started Box Contents Product Layout How to record videos to the USB storage device Connect Record/Capture How to record videos to PC System Requirements Install HDML-Cloner Pro Helper Connect Register HDML-Cloner Pro Helper Record/Capture Schedule Recording How to live stream videos with HDML-Cloner Box Turbo Frequently Asked Questions Supported Resolutions...

  • Page 5: Getting Started

    Getting Started Box Contents a. HDML-Cloner Box Turbo b. HDMI Cable c. Micro-USB to USB Cable d. Power Adapter e. Quick Start Guide...

  • Page 6: Product Layout

    Product Layout...
  • Page 8 ON/OFF: Press this button to switch on/switch off HDML-Cloner Box Turbo. 5V/2A: Plug the power adapter into this socket and power on HDML-Cloner Box Turbo. 3. IN: Connect an HDMI cable between the HDMI source device and HDML-Cloner Box Turbo. OUT: Connect an HDMI cable between HDML-Cloner Box Turbo and TV.

  • Page 9: How To Record Videos To The Usb Storage Device

    How to record videos to the USB storage device? Connect 1. Connect the source video player to the "IN" port on HDML-Cloner Box Turbo via an HDMI cable. 2. Connect HDML-Cloner Box Turbo from the "OUT" port to TV via an HDMI cable. 3.
  • Page 10 ② ① ③ STORAGE POWER ④ HDML-Cloner Box Turbo *The USB flash drive is not included in the product box. You need to purchase it independently.
  • Page 11 Tips on selecting a proper USB flash drive: 1. Recommended brands: Toshiba, SanDisk, Kingston 2. Interface specifications: USB 2.0, USB 3.0 3. Connector type: Type A 4. Make sure the actual reading speed is not less than 30Mbps, and the writing speed is not less than 10Mbps.

  • Page 12: Record/Capture

    Record/Capture 1. Switch on HDML-Cloner Box Turbo. The LED light will illuminate solid Blue or Green. 2. Prior to gameplay or video playback, press the REC/STOP button. Start playing game or video, then recording will start simultaneously. The LED light will blink Blue or Green.
  • Page 13 The LED light of HDML-Cloner Box Turbo will illuminate different colors/ways to indicate functions. LED Status Indication Solid Green The current video is 720p/others. Solid Blue The current video is 1080p. Blink Blue/Blink Green Recording Blink Blue/Green alternately Buffering, please wait.

  • Page 14: How To Record Videos To Pc

    How to record videos to PC System Requirements Prior to installing HDML-Cloner Pro Helper, please make sure you are using Windows 7 or later versions and your PC is equipped with USB 2.0 or USB 3.0 port. Install HDML-Cloner Pro Helper HDML-Cloner Pro Helper is a smart program to record video discs, game videos, homemade videos or anything from any video source under Windows OS working together with HDML- Cloner Box Turbo.
  • Page 15 If the following window appears during the installation process, please select "Install", otherwise HDML-Cloner Pro Helper will not work properly.

  • Page 16: Connect

    Connect 1. Connect the source video player to the "IN" port of HDML-Cloner Box Turbo via an HDMI cable.. 2. Connect the Micro-USB to USB cable between the "To PC" port of HDML-Cloner Box Turbo and the USB port of PC. 3.
  • Page 17 After all devices have been connected properly, please power on all connected devices. The Windows operating system will prompt "Found a new hardware" and install the driver automatically. Please make sure "Full HD Capture Device" is installed successfully and appears in the Device Manager (Right click My Computer –...

  • Page 19: Register Hdml-Cloner Pro Helper

    Register HDML-Cloner Pro Helper Please register HDML-Cloner Pro Helper first before using. With the trial version, you can only use it for 7 days. Run HDML-Cloner Pro Helper. Click in the main interface and then click the "Register" button. Click the "Input registration code" button to open the "Register" window. Fill in your proper Email address, name and registration code.
  • Page 20 How to get the registration code of HDML-Cloner Pro Helper? Scan the QR code below to register HDML-Cloner Box Turbo and get the registration code of HDML- Cloner Pro Helper. Scan QR code to register and get FREE bundled softwares. CEXXXXXXXX https://goo.gl/vHQelH For more details about registering HDML-Cloner Pro Helper, visit the link below to read...

  • Page 21: Record/Capture

    Record/Capture 1. Run HDML-Cloner Pro Helper on your PC and play the video. 2. Click to start recording.
  • Page 22 to stop recording. 3. Click Tips: During recording, you can click to pause at anytime. When you want to resume, please click to continue recording. Besides, you can click to take a BMP/PNG/JPG snapshot or click to capture a 30-second animated GIF image.
  • Page 24 to view the recorded video. Then you can click 4. After recording, click to play back the recorded video directly.

  • Page 25: Schedule Recording

    Schedule Recording 1. HDML-Cloner Pro Helper supports setting multiple "Schedule Recording" tasks. Please connect HDML-Cloner Box Turbo to PC, and then run HDML-Cloner Pro Helper. to enter the "Setup" window. Then click the "Schedule Recording" 2. Click...
  • Page 26 3. Please enable schedule recording first, set the recording frequency (Every day/Date), start time and duration for schedule recording and then click "OK". HDML-Cloner Pro Helper will start recording automatically at the scheduled time. Tip: You can create up to 4 schedule recording tasks at the same time.

  • Page 27: How To Live Stream Videos With Hdml-Cloner Box Turbo

    How to live stream videos with HDML- Cloner Box Turbo? HDML-Cloner Box Turbo supports three third-party live streaming applications, which are Open Broadcaster Software (OBS Studio), Open Broadcaster Software (OBS Classic) and XSplit Broadcaster. Before live streaming, please make sure HDML-Cloner Box Turbo is connected to PC and HDML- Cloner Pro Helper is installed.
  • Page 28 Connection Guide of HDML-Cloner Pro Helper and Open Broadcaster Software (OBS Studio). 1. Please install Open Broadcaster Software (OBS Studio) and run it on your computer. Tip: You can click here to download Open Broadcaster Software (OBS Studio).
  • Page 29 2. Please click "+" below "Sources" and select "Video Capture Device" from the pop-up menu, then click "OK".
  • Page 30 3. In the "Properties for Video Capture Device" window, select "HDML-Cloner Box Device" in the drop- down list of "Device", and then scroll down to the "Audio Output Mode" option. Please select "Output desktop audio (DirectSound)" in the drop-down list. Click "OK" to save the settings.
  • Page 32 4. Now you can preview the video.
  • Page 33 Connection Guide of HDML-Cloner Pro Helper and Open Broadcaster Software (OBS Classic). 1. Install Open Broadcaster Software (OBS Classic) and run it. Tip: You can click here to download Open Broadcaster Software (OBS Classic).
  • Page 34 2. Right click on the blank section under "Sources" and then select "Video Capture Device" from the drop-down menu of "Add". Click "OK" to save the settings.
  • Page 35 3. In the "Device Selection" window, please select "HDML-Cloner Box Device" in "Device", and check the "Output audio to desktop" option in "Audio". Then click "OK".
  • Page 36 4. After the setting, the "Video Capture Device" interface will appear.
  • Page 37 5. Click the "Preview Stream" button in the lower right corner to preview. For more details about adjusting the settings of live streaming, please refer to the manual of Open Broadcaster Software at: http://jp9000.github.io/OBS/...
  • Page 38 Connection Guide of HDML-Cloner Box Turbo and XSplit Broadcaster. 1. Install XSplit Broadcaster software and run it. Tip: You can click here to download XSplit Broadcaster.
  • Page 39 2. Select "HDML-Cloner Box Device" in "Sources" - "Webcam, capture card, video devices" in the main interface of XSplit Broadcaster.
  • Page 40 3. After selecting the driver, the video will be played in the interface of XSplit Broadcaster. 4. For more details about adjusting the settings of live streaming, please refer to the manual of XSplit Broadcaster at: https://www.xsplit.com/broadcaster/manual Note: Please DO NOT run HDML-Cloner Pro Helper and any Third-Party Live Streaming Software at the same time.

  • Page 41: Frequently Asked Questions

    Frequently Asked Questions 1. What should I do if the following interface appears on TV? Och, something wrong! Don't worry!... Don't worry, it's very easy to solve this problem. Please scan the QR code below to find the answer. cloner-alliance.com/hdmicloner-box-evolve-faq/technical-faq/black_screen_tips_evolve.html...
  • Page 42 2. What kinds of mobile hard disks do ClonerAlliance products support? 2TB capacity or below. Less than 500mA current (Under dependent power sources). 10MB/s read-write speed or above (You can use CrystalDiskMark to test speed.). FAT32 or NTFS file system on Windows 7 operating system or above.

  • Page 43: Supported Resolutions

    Supported Resolutions 1920x1080 (50p), 1920x1080 (60p) 1920x1080 (24p), 1920x1080 (25p), 1920x1080 (30p) 1920x1080 (50i), 1920x1080 (60i), 1280x1024 (60p) Input/Output 1280x720 (60p), 1280x768 (60p), 1280x800 (60p) 720x480 (60i), 720x480 (50i) 640x480 (60p), 720x480 (60p), 720x576 (50p) 1920x1080 (30p), 1280x720 (60p), 1280x720 (30p) Recording 640x480 (60p), 720x480 (60p), 720x576 (50p)

  • Page 44: Product Specifications

    Product Specifications Capture format MP4 (H.264) Video standards (input) NTSC, PAL Supported disk formats FAT32, NTFS Input signals HDMI Output signals HDMI (pass-through), USB Bitrate Max: 10Mbps HDML-Cloner Box Turbo will record several 2GB files if the USB is in FAT32 format. If Note: in NTFS format, HDML-Cloner Box Turbo will record only 1 file with greater size.

  • Page 45: Microphone Function

    Microphone Function Note: Please use a microphone with a plug like this.

  • Page 46: Contact Us

    ● We'll offer a satisfying discount on batch purchase and affiliate program. If you are interested, please contact us by market@cloner-alliance.com Disclaimer HDMI is a registered trademark of HDMI Licensing, LLC. HDMI® and USB® are trademarks of their respective companies. ClonerAlliance Inc. is not affiliated with those companies.

  • Page 47: Index

    Index ON/OFF Power adapter Connect Record HDML-Cloner Pro Helper Register Schedule recording Live stream Resolutions Specifications Email...
  • Page 48 https://www.cloner-alliance.com...
