- Page 1 PRODUCT TYPE: Design Guide...
-
Page 2: Table Of Contents
7.4.6 Decorative panels layout for Fridge Column (0F) 7.4.7 Decorative panels layout for Fridge column with glass door (0F) 7.4.8 Tubolar handles 7.4.9 Maximum cabinet depth over “Integrated” refrigerator with single door panel www.fhiaba.com · info@fhiaba.com · Tel +39 (0)434 420160 · Fax +39 (0)434 420161... -
Page 3: Fhiaba Range Presentation
Brilliance units come equipped with a new repositionable glass shelf system and adjustable balconies on a unique rack design. www.fhiaba.com · info@fhiaba.com · Tel +39 (0)434 420160 · Fax +39 (0)434 420161 www.fhiaba.com · info@fhiaba.com · Tel +39 (0)434 420160 · Fax +39 (0)434 420161... -
Page 4: Space Design
(B). Appliance Wall or Appliance Wall or furniture furniture 6,5 (¼”) 6,5 (¼”) www.fhiaba.com · info@fhiaba.com · Tel +39 (0)434 420160 · Fax +39 (0)434 420161 www.fhiaba.com · info@fhiaba.com · Tel +39 (0)434 420160 · Fax +39 (0)434 420161... -
Page 5: Built-In Kit
Country) and con- sists of a connection element (A) and a aluminium frame (B). www.fhiaba.com · info@fhiaba.com · Tel +39 (0)434 420160 · Fax +39 (0)434 420161 www.fhiaba.com · info@fhiaba.com · Tel +39 (0)434 420160 · Fax +39 (0)434 420161... -
Page 6: Built-In Installation Appliances Separated By Wall Or Panel
A Connecting element A Connecting element B Aluminium frame B Aluminium frame E Anti-condensation panel www.fhiaba.com · info@fhiaba.com · Tel +39 (0)434 420160 · Fax +39 (0)434 420161 www.fhiaba.com · info@fhiaba.com · Tel +39 (0)434 420160 · Fax +39 (0)434 420161... -
Page 7: Technical Data And Niche Dimensions
Unit Width with lateral frames C 899 mm (35 1/2’’) 749 mm (29 1/2’’) 599 mm (23 5/8") www.fhiaba.com · info@fhiaba.com · Tel +39 (0)434 420160 · Fax +39 (0)434 420161 www.fhiaba.com · info@fhiaba.com · Tel +39 (0)434 420160 · Fax +39 (0)434 420161... -
Page 8: Standplus Series
Unit Width with lateral frames C 899 mm (35 1/2’’) 749 mm (29 1/2’’) 599 mm (23 5/8") www.fhiaba.com · info@fhiaba.com · Tel +39 (0)434 420160 · Fax +39 (0)434 420161 www.fhiaba.com · info@fhiaba.com · Tel +39 (0)434 420160 · Fax +39 (0)434 420161... -
Page 9: Country Series
Unit Width B 887 mm (35" in) 737 mm (29" in) 587 mm (23 1/8" in) www.fhiaba.com · info@fhiaba.com · Tel +39 (0)434 420160 · Fax +39 (0)434 420161 www.fhiaba.com · info@fhiaba.com · Tel +39 (0)434 420160 · Fax +39 (0)434 420161... -
Page 10: Classic Series
Unit Width with lateral frames C 899 mm (35 1/2’’) 749 mm (29 1/2’’) 599 mm (23 5/8") www.fhiaba.com · info@fhiaba.com · Tel +39 (0)434 420160 · Fax +39 (0)434 420161 www.fhiaba.com · info@fhiaba.com · Tel +39 (0)434 420160 · Fax +39 (0)434 420161... - Page 11 Unit Width with lateral frames C 899 mm (35 1/2’’) 749 mm (29 1/2’’) 599 mm (23 5/8") www.fhiaba.com · info@fhiaba.com · Tel +39 (0)434 420160 · Fax +39 (0)434 420161 www.fhiaba.com · info@fhiaba.com · Tel +39 (0)434 420160 · Fax +39 (0)434 420161...
-
Page 12: Integrated Series
Unit Width with lateral frames C 899 mm (35 1/2’’) 749 mm (29 1/2’’) 599 mm (23 5/8") www.fhiaba.com · info@fhiaba.com · Tel +39 (0)434 420160 · Fax +39 (0)434 420161 www.fhiaba.com · info@fhiaba.com · Tel +39 (0)434 420160 · Fax +39 (0)434 420161... - Page 13 Unit Width with lateral frames C 899 mm (35 1/2’’) 749 mm (29 1/2’’) 599 mm (23 5/8") www.fhiaba.com · info@fhiaba.com · Tel +39 (0)434 420160 · Fax +39 (0)434 420161 www.fhiaba.com · info@fhiaba.com · Tel +39 (0)434 420160 · Fax +39 (0)434 420161...
-
Page 14: Brilliance - Classic Series
Unit Width with lateral frames C 899 mm (35 1/2’’) 749 mm (29 1/2’’) 599 mm (23 5/8") www.fhiaba.com · info@fhiaba.com · Tel +39 (0)434 420160 · Fax +39 (0)434 420161 www.fhiaba.com · info@fhiaba.com · Tel +39 (0)434 420160 · Fax +39 (0)434 420161... -
Page 15: Brilliance - Integrated Series
Unit Width with lateral frames C 899 mm (35 1/2’’) 749 mm (29 1/2’’) 599 mm (23 5/8") www.fhiaba.com · info@fhiaba.com · Tel +39 (0)434 420160 · Fax +39 (0)434 420161 www.fhiaba.com · info@fhiaba.com · Tel +39 (0)434 420160 · Fax +39 (0)434 420161... -
Page 16: Accessories
22 ( ⁄ ”) 22 ( ⁄ ”) A Connecting element B Aluminium frame H Side panel www.fhiaba.com · info@fhiaba.com · Tel +39 (0)434 420160 · Fax +39 (0)434 420161 www.fhiaba.com · info@fhiaba.com · Tel +39 (0)434 420160 · Fax +39 (0)434 420161... -
Page 17: Technical Info
The appliance should be connected only to a drinkable water sup- ply system. www.fhiaba.com · info@fhiaba.com · Tel +39 (0)434 420160 · Fax +39 (0)434 420161 www.fhiaba.com · info@fhiaba.com · Tel +39 (0)434 420160 · Fax +39 (0)434 420161... -
Page 18: Anti - Tipping System
Please refer to page 5-6 to ensure correct air circulation. www.fhiaba.com · info@fhiaba.com · Tel +39 (0)434 420160 · Fax +39 (0)434 420161 www.fhiaba.com · info@fhiaba.com · Tel +39 (0)434 420160 · Fax +39 (0)434 420161... -
Page 19: Custom Panels
3 ( ⁄ ”) 115 (4 ½”) 3 ( ⁄ ”) 3 ( ⁄ ”) www.fhiaba.com · info@fhiaba.com · Tel +39 (0)434 420160 · Fax +39 (0)434 420161 www.fhiaba.com · info@fhiaba.com · Tel +39 (0)434 420160 · Fax +39 (0)434 420161... -
Page 20: Panels Dimensions Column Models (0F Models
161(6 ⁄ ”) max 258 (10 ⁄ ”) 34 (1 ⁄ ” ½” 13 ( www.fhiaba.com · info@fhiaba.com · Tel +39 (0)434 420160 · Fax +39 (0)434 420161 www.fhiaba.com · info@fhiaba.com · Tel +39 (0)434 420160 · Fax +39 (0)434 420161... -
Page 21: Decorative Panels Layout For Fridge With Glass Door And One Bottom-Drawer (1T/0T
⁄ ” 115 (4 ½” 34 (1 ⁄ ” 13 ( ½” 13 ( ½” www.fhiaba.com · info@fhiaba.com · Tel +39 (0)434 420160 · Fax +39 (0)434 420161 www.fhiaba.com · info@fhiaba.com · Tel +39 (0)434 420160 · Fax +39 (0)434 420161... -
Page 22: Decorative Panels Layout For Fridge With Glass Door Brilliance
½” 115 (4 ½” 34 (1 ⁄ ” 13 ( ½” 13 ( ½” www.fhiaba.com · info@fhiaba.com · Tel +39 (0)434 420160 · Fax +39 (0)434 420161 www.fhiaba.com · info@fhiaba.com · Tel +39 (0)434 420160 · Fax +39 (0)434 420161... -
Page 23: Decorative Panels Layout For Fridge Column (0F
¾” 599: 327 (12 ⁄ ” ⁄ ” ⁄ ” 135 (5 135 (5 www.fhiaba.com · info@fhiaba.com · Tel +39 (0)434 420160 · Fax +39 (0)434 420161 www.fhiaba.com · info@fhiaba.com · Tel +39 (0)434 420160 · Fax +39 (0)434 420161... -
Page 24: Tubolar Handles
480 mm (18 7/8” in) 490 mm (19 1/4” in) 340 mm (13 3/8” in) Series www.fhiaba.com · info@fhiaba.com · Tel +39 (0)434 420160 · Fax +39 (0)434 420161 www.fhiaba.com · info@fhiaba.com · Tel +39 (0)434 420160 · Fax +39 (0)434 420161... - Page 26 FHIABA srl Via Fiumicino, 20 33082 Azzano Decimo PN Italy tel +39 0434 420160 sales@fhiaba.com www.fhiaba.com...
