Owner's Manual & Assembly Instructions
XP01
Model No.
715990111
Storage Area:
43 Sq. Ft.
4,0 m
BUILDING DIMENSIONS * Size rounded off to the nearest foot
*Approx.
Base
Size
Size
8' x 6'
97 1/2" x 68 3/4"
2,4 m x 1,7 m
247,7 cm x 174,6 cm
EDA86
271 Cu. Ft.
7,7 m
2
3
Exterior Dimensions
(Roof Edge to Roof Edge)
Width
Depth
99 3/4"
71 1/4"
253,4 cm
181,0 cm
CAUTION: SOME PARTS HAVE SHARP EDGES. CARE
MUST BE TAKEN WHEN HANDLING THE VARIOUS PIECES
TO AVOID A MISHAP. FOR SAFETY SAKE, PLEASE READ
SAFETY INFORMATION PROVIDED IN THIS MANUAL
BEFORE BEGINNING CONSTRUCTION. WEAR GLOVES
WHEN HANDLING METAL PARTS.
Interior Dimensions
(Wall to Wall)
Height
Width
79 1/8"
94 3/4"
201,0 cm
240,7 cm
Depth
Height
Width
66"
77 7/8"
43 1/2"
167,6 cm
197,8 cm 110,5 cm 175,9 cm
Door
Opening
Height
69 1/4"

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EDA86 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Arrow EDA86

Summary of Contents for Arrow EDA86

  • Page 1 Owner's Manual & Assembly Instructions XP01 Model No. EDA86 715990111 CAUTION: SOME PARTS HAVE SHARP EDGES. CARE MUST BE TAKEN WHEN HANDLING THE VARIOUS PIECES Storage Area: 43 Sq. Ft. 271 Cu. Ft. TO AVOID A MISHAP. FOR SAFETY SAKE, PLEASE READ...
  • Page 2 BEFORE YOU BEGIN..XA02 Owner's Manual Before beginning construction, check local building codes regarding footings, location and other requirements. Study and understand this owner's manual. Important information and helpful tips will make your construction easier and more enjoyable. Instructions are supplied in this manual and contain all Assembly Instructions: appropriate information for your building model.
  • Page 3 PLAN AHEAD..XA03 Be sure the day you select to install your building is dry and calm. Watch the Weather: Do not attempt to assemble your building on a windy day. Be careful on wet or muddy ground. Whenever possible, two or more people should work together to assemble Teamwork: your building.
  • Page 4 SAFETY FIRST..XA04 Safety precautions are important to follow throughout the construction of your building. •Care must be taken when handling various •Practice caution with the tools being used in the pieces of your building since some contain assembly of this building. Be familiar with the sharp edges.
  • Page 5 CARE & MAINTENANCE..XA05 For long lasting finish, periodically clean and wax the exterior surface. Touch- Finish: up scratches as soon as you notice them on your unit. Immediately clean the area with a wire brush; wash it and apply touch-up paint per manufacturer's recommendation. Keep roof clear of leaves and snow with long handled, soft-bristled broom.
  • Page 6 Base XP06 The Base For Your Building OPTION 1: Wood Platform If you decide to build your own base, be sure to select the appropriate materials. These are the recommended materials for your base: ● 2 x 4's (38 mm x 89 mm) Pressure Treated Lumber ●...
  • Page 7 Anchoring XA07 Anchoring Down The Building It is important that the entire floor frame be anchored after the building is erected. Below are recommended ways of anchoring. Anchoring into Wood/Post: Use 1/4" (6 mm) Wood Screws. There are 1/4" (6 mm) dia.
  • Page 8 (Packed with Screws) (5 sheets of 40) 66183 66769 66382 Roof Trim Cap 67468 Peak Cap (2) Door Slide (4) Lower Door Guide (4) (2 right & 2 left) (Arrow Logo) 6228 7916 Track Support (2) Roof Beam Bracket (4)

  • Page 9: Table Of Contents

    Parts List XP09 Assembly Part Part Quantity Check Key No. Number Description in Carton List 8941 Ramp 9379 Front Floor Frame 9377 Rear Floor Frame 9336 Right Rear Wall Angle 9378 Door Track 6617 Door Track Splice 9337 Left Rear Wall Angle 7907 Left Gable 7906...

  • Page 10: Key No

    Assembly by Key No. XP10...

  • Page 11: 8941 Ramp

    ● ● ● ● ● 8941 Ramp (1) ● Parts Needed For ● Step 1 ● ● ● ● ● 9379 Front Floor Frame (2) Floor Frame Assemblies ● ● ● ● ● 9377 Rear Floor Frame (2) ZB11 9379 The front floor frame is made up of 8941 three pieces.

  • Page 12: 9336 Right Rear Wall Angle

    ● Parts Needed For ● ● ● ● ● ● 9336 Right Rear Wall Angle (1) Step 2 ● ● ● ● ● 9337 Left Rear Wall Angle (1) Frame Assembly XP12 The main frame pieces reinforce the walls. This piece will later be installed at the top edge of the rear wall.
  • Page 13 ● Parts Needed For ● ● ● ● ● ● 8474 Roof Beam (1) Step 3 ● ● ● ● ● 8476 Side Wall Angle (1) Roof Beam Assembly XP13 (10) The roof beams join the two gables and support the roof panels. The main roof beam is made up of two pieces fastened together.

  • Page 14: 9378 Door Track

    ● Parts Needed For ● ● ● ● ● ● 6617 Door Track Splice (1) Step 4 ● ● ● ● ● 9378 Door Track (2) Door Track Assembly XP14 NOTE: Door Track Splice (painted part) 6617 The door track assembly supports the sliding doors and reinforces the front wall.
  • Page 15 ● ● ● ● ● Front Floor Assembly (1) ● Parts Needed For ● Step 5 ● ● ● ● ● 8946 Side Floor Frame (2) Floor Frame ● ● ● ● ● Rear Floor Assembly (1) ZB15 RIGHT REAR 8946 STEP 8946...

  • Page 16: 5288 Corner Post

    ● ● ● ● ● 5288 Corner Post (4) ● Parts Needed For ● ● ● ● ● ● Door Track Assembly (1) Step 6 ● ● ● ● ● Rear Wall Angle Assembly (1) Posts/Top Frames ● ● ● ● ● 9342 Side Wall Angle (2) XP16 (22) REAR...

  • Page 17: 5287 Splice Post

    ● Parts Needed For ● ● ● ● ● ● 5287 Splice Post (1) Step 7 ● ● ● ● ● 7311 Door Jamb (2) Splice Post/Door Jamb XP17 STEP 5287 The door jambs reinforce the door opening and provide an attractive trim.

  • Page 18: 9344 Siding Stud

    ● Parts Needed For ● ● ● ● ● ● 9344 Siding Stud (6) Step 8 Studs XP18 The studs provide a surface for at- taching the siding panels. Following dimensions, measuring from the ends of angles, place a stud between each corner and splice post at the rear of building and 2 studs between corner posts at the sides.

  • Page 19: 8719 Side Siding

    ● Parts Needed For ● Step 9 ● ● ● ● ● 8719 Side Siding (6) Side Siding XP19 (24) (28) Each screw in the wall requires a washer. STEP CORRECT INCORRECT STEP Slide side siding into channels of corner posts, flat edge upward, bottom edge down resting on floor STEP 8719...

  • Page 20: 9345 Rear Siding

    ● Parts Needed For ● Step 10 ● ● ● ● ● 9345 Rear Siding (6) Rear/Front Siding ● ● ● ● ● 9746 Front Siding (6) XP20 STEP STEP (48) (14) Fasten Top Center of Last Siding to Stud 9345 Slide rear siding into channel of corner and splice posts fastening to...
  • Page 21 ● ● ● ● ● 7906 Right Gable (2) ● Parts Needed For ● Step 11 ● ● ● ● ● 7907 Left Gable (2) Gable Assemblies ● ● ● ● ● 7916 Roof Beam Bracket (4) XP21 The gables go on top of the front and rear walls to support the roof beams.
  • Page 22 ● ● ● ● ● Left Gable Assemblies (2) ● Parts Needed For ● Step 12 ● ● ● ● ● Right Gable Assemblies (2) Gables/Braces ● ● ● ● ● 6658 Gable Brace (2) XP22 (24) Lift and fasten a right and left gable, under angle at corner, to the rear wall angle with screws.

  • Page 23: 8474 Roof Beam

    ● Parts Needed For ● Step 13 ● ● ● ● ● Main Roof Beam (1) Roof Beams ● ● ● ● ● 8474 Roof Beam (2) XP23 (12) Fasten the main roof beam to the STEP gable brace of the front gable. Fasten the other end of the main 8474 Roof Beam roof beam to the gable brace of the...

  • Page 24: 8466 Right Roof Panel

    ● Parts Needed For ● Step 14 ● ● ● ● ● 8466 Right Roof Panel (1) Right Roof Panel XP24 STEP 8466 8467 Installing the roof panels is best done with a step ladder. Begin installing 7875 7875 roof panels at the back right corner of the building.

  • Page 25: 7875 Roof Panel

    ● Parts Needed For ● ● ● ● ● ● 8467 Left Roof Panel (2) Step 15 ● ● ● ● ● 7875 Roof Panel (4) Roof Assembly ● ● ● ● ● 8466 Right Roof Panel (1) XP25 STEP STEP 8467 Left Roof Panel Weather Stripping...

  • Page 26: 8461 Ridge Cap

    ● Parts Needed For ● ● ● ● ● ● 8461 Ridge Cap (1) Step 16 ● ● ● ● ● 8482 Side Roof Trim (2) Ridge Cap/Roof Trim XP26 STEP (26) 8461 Install the ridge cap on the com- pleted roof section using bolts.

  • Page 27: 10484 Left Door

    ● Parts Needed For ● ● ● ● ● ● 10484 Right and Left Doors (2) Step 17 ● ● ● ● ● 10498 Horizontal Door Brace (4) Door Assembly ● ● ● ● ● 6301 Vertical Door Brace (2) XP27 (12) The steps on this page tell how to...
  • Page 28 ● Parts Needed For ● ● ● ● ● ● Right Door Assembly (1) Step 18 ● ● ● ● ● Left Door Assembly (1) Door Installation & Adjustment XP28 Horizontal Door Brace Gable Door Track Door Slide From inside the building, put the bottom of the right door assembly (on your left when you are inside the STEP...
  • Page 29 EDA86 XP32 Anchoring Anchor your building at this time. SOME FACTS ABOUT RUST 1. Avoid nicking or scraping the coating surface, Rusting is a natural oxidizing process that occurs inside and out. when bare metal is exposed to moisture. Problem areas include screw holes, unfinished edges, or 2.
