- Page 1 Shezhen WFLY Technology Development Co.,Ld V1.04 10 Channels Digital Proportional R/C System ET07 Instruction Manual More product information, please follow the WeChat official account above...
- Page 2 Thank you for using WFLY products! ● Please read this product manual carefully before using this product! ● Please use this product properly! The R/C model is not a toy, for safety, please do not fly in crowded places!
- Page 3 Function Catalogue Please read the following instructions carefully before use to ensure safely use of the product Safety Caution Symbols Definition Flying Notices Battery Trainer USB Interface Before Use Product Features Basic Configuration Each Parts Name Of Transmitter Switch Configuration And Types The Travel Of Antenna Direction Adjustment Basic Operation Home Interface Operation...
- Page 4 Function Catalogue System Setting Model Select Save multiple sets of set parameters and switch freely when needed Model Name Name a group of model parameters Model Type Select helicopter,airplane or multicopter Model Copy Copy one group of model parameters to another group of model parameters Model Reset Reset a group of model parameters to initial value Low Voltage...
- Page 5 Function Catalogue Model Menu\Airplane Hold the throttle output status Throttle Hold Adjust the differential of AIL1 and AIL2 AIL Differential Assign another AIL channel Aileron 2 Motion mode assignment Fly Mode To make instant throttle cut after flying Throttle Cut Adjust the linear relation of throttle Throttle Curve Adjust flap end point,change flap channel seperately,control mix will synchronize...
- Page 6 Safety Caution Symbols Definition Pay special attention to the safety information of the following symbols WARNING Prohibitions If without a proper operation,it may cause dangerous accident or seriously injury or may even cause death. Compulsory Items DANGER If without a proper operation,it may cause dangerous accident or seriously injury or may even cause death,and it may cause slight hurt or probability cause bodily injure!
- Page 7 After flying, turn off the receiver primarily and a crash. When you begin your flying session, reset then turn off the transmitter for protecting people your ET07 built-in timer, and during the session pay from the fail-safe function. attention to the duration of usage.
- Page 8 1.Do not attempt to disassemble LiFe packs or machine! cells. The USB interface of the ET07 can be charged. 2.Do not allow LiFe cells to come in contact with Please charge the battery with a USB output charge moisture or water at any time.
- Page 9 Basic Configuration Transmitter:ET07 remote controller x1 Receiver:RF207S Receiver x1(External power inspection wire x1) Accessary : Receiver Lanyard x1 Others : Summary manual file x1 Warranty card x1 *WFLY will not notify further if any configuration Lanyard changes. Summary manual x1...
- Page 10 Before Use Each Parts Name of Transmitter Antenna Power LED RF Light V2(Slide Lever) V1(Rotary Knob) Stick Hook Trim T3 Trim T2 Trim T4 Trim T1 Power switch Function key Navigate Key Resistance touch screen Trainer port USB Interface Carry handle Battery compartment Battery Interface...
- Page 11 Before Use Switch Configuration And Types Power switch:Click and hold for about 2 seconds to open/shut down T1-T4:Trim key(User defined function) SA:Short lever 2 positions(User defined function) SB:Long lever 2 positions(User defined function) SD:Short lever 3 positions(User defined function) SD:Long lever 2 positions reset(User defined function) V1:Rotary knob(User defined) V2:Slide Lever(User defined) HOME:Function key,slightly click to return to standby interface,click and hold for...
- Page 12 Basic Operation Home Interface Introduction ET07 N O R 4. 2 V U s e r N a me 00 00 0 00 00 0 Rx :5. 0V E x t : 1 2 V M od e l 1...
- Page 13 Basic Operation Touch Screen Operation ET07 uses 3.5 inches resistance touch screen, 2 Switch, function type setting: Click to switch. which makes ET07 operation more flexible and efficient. Throttle Hold NORM 4.2V Throttle Hold NORM 4 . 2 V NOTICE...
- Page 14 Stick Adjustment Stick head height adjustment Stick feel and function adjustment Tools : 1.5mm socket screwdriver: ET07 uses the newly developed four-bearing Steps: assembly to trim the feel! 1. Loosen the upper section head Uncover the silicone sheet on the back and adjust counterclockwise the feel directly.
- Page 15 If you need components such as bracket 5 (such as the parts needed for assembling double circuit structure!), you can e-mail to WFLY overseas seller to order the spare parts at sales@wflysz.com...
- Page 16 Basic Operation Receiver Instructions Receiver LED STATUS LIST Mode Action State Green Never W.BUS normal work mode Blue Never PWM normal work mode Work Never No signal Slow flash Low voltage Signal Orange Slow flash Linking Positive Negtive Green Slow flash W.BUS mode Blue Slow flash...
- Page 17 Basic Operation Receiver and servo Link example - Airplane The figure below shows an example of airplane Link. Please use the actual wing type and tail type for servo Link. AILERON ELEVATOR THROTTLE RUDDER UNDERCARRIAGE FLAP AILERON 2/AUX 1 Servo connection position (Airplane) The table below shows examples of the servo connection positions for the different wing types and tail types.
- Page 18 Basic Operation Receiver and servo Link example -Glider The table below shows examples of the servo link positions for the different wing types and tail types. 1AIL(A-1) 2AIL(A-2) 2A+1F(AF1) 2A+2F(AF2) Aileron Aileron Aileron Aileron Elevator Elevator Elevator Elevator Motor Motor Motor Motor Rudder...
- Page 19 Basic Operation Receiver and servo link example -Helicopter The figure below shows an example of helicopter link. Please use the actual wing type and tail type for servo link. AILERON ELEVATOR THROTTLE RUDDER GYRO PITCH AUX/GOVERNOR Servo link position (Helicopter) The table below shows examples of the servo link positions for different swashes.
- Page 20 Basic Operation Receiver and servo Link example -Multicopter The figure below shows the four-rotor multicopter. Please refer to the model manual for specific applications. Motor,electronic speed controller, flight controller, battery, etc. are sold separately. Use 5CH-9CH when using accessories such as camera shutters.
- Page 21 Models Basic Setting Sequence Basic setting sequence of airplane and glider Taking a conventional F3A as an example, the ● [Dual Rate] adjust The rate adjustment after flight is performed by steps of setting a airplane will be described. In the the [Dual Rate] function.
- Page 22 Models Basic Setting Sequence Basic setting sequence of helicopter Here, a conventional helicopter is taken as an +5 0% RATE + 50% +125 example to explain the setting sequence steps of the +100 helicopter. In the actual setting process, set the appropriate value according to the body to be used.
- Page 23 Models Basic Setting Sequence From the menu, call the [Pitch Curve] interface and 6. Setting Idle 2 Next, set the " Idle 2". select the "Advanced" curve. Idle 2 is mostly used for scrolling. When landing, the maximum pitch is used for both The Idle 2 status is when the Idle switch is in the the high and low positions.
- Page 24 System Setting Model Select Model Name The ET07 can store up to 20 groups of model The model names stored in ET07 can be changed. data, which is used to load the saved model data. The currently selected model name will always be displayed on the standby screen.
- Page 25 Also want to save the original settings, please use the [Model Copy] function to back up the model data in advance. Enter the interface: WFLY → System Setting → Model Type Model Type NO R M 4.2V...
- Page 26 At the same time, this function can also Enter the interface: WFLY → System Setting→ be used as a function of data backup. Model Reset Notice:...
- Page 27 WFLY → System Setting → Notice: Sound The ET07 has three voltage detection alarms. In addition to the transmitter voltage, the receiver and Setting method: the receiver's external battery, the two voltage Press the key - press the plus or minus key or the values will only take effect if the "telemetry"...
- Page 28 "8 channels", and after a few seconds, the mode detection and switching can be completed. 3 Verification: WFT08/09 toggles the coach switch to position 2 and operates the ET07 related stick or other switch. Check if the servo of the corresponding channel is working normally.
- Page 29 Setting method: Press the key-press the confirmation key to perform the calibration function. According to the yellow point of the operation prompt, perform the ET07 NO R M 4 . 2 V User Name NOR M 4 . 2 V corresponding stick operation;...
- Page 30 Stick Mode Users can choose familiar operating modes Reset all the parameter settings of the transmitter. according to their own operating habits, and ET07 NOTICE offers a choice of 4 operating modes. Note: The switch saves immediately for the stick...
- Page 31 → System Setting→ (Download the upgrade package at Screen Cal en.wflysz.com) Setting method: If you have any questions, please contact WFLY Touch screen-Click the center of the circle after-sales customer service consultation : according to the prompt circle displayed on the service@wflysz.com screen;...
- Page 32 → [Trainer] to set); synchronous action output, that is link successful; 3. There is no other WFLY 2.4GHz system in progress. 4. In the process of linking, if you need to exit the link, click the "Cancel"...
- Page 33 Linkage Setting Telemetry The telemetry interface displays the collected Interface path: Method 1: WFLY →Linkage Setting→ Telemetry telemetry data. Method 2:Click the telemetry information box in Note: the standby interface. Inhibiting "Telemetry" when link will affect the use of [Range Check] [Low Battery] [W.BUS Servo] [Telemetry].
- Page 34 (The receiver receives the strength of the Interface path: transmitter signal) and the receiver checks to see if WFLY → Linkage Setting → Range Check the status light and servo are moving smoothly. This comprehensive evaluation of the working distance!
- Page 35 DANGER Additional protection features: For your safety, be sure to set up fail safe The ET07 provides active protection. As protection.Especially the Fail Safe of the throttle long as the telemetry function is turned on, as channel.In that way,the airplane flight speed is...
- Page 36 The S.BUS servo can memorize its own channel Switching the output mode of receiver and different settings. the servo channel could be PPM/W,BUS(the 8th slot) set through connecting servo on Et07. Notice: PPM mode(RF207S). The 8th slot outputs Notice: a standard 2048 resolution, 8 channel PPM signal.
- Page 37 Interface path: WFLY → General Menu→ Monitor When starting the [Sub-Trim] setting, you must firstly sub trim each channel (checked by the monitor) to the center position.
- Page 38 General Menu Timer The ET07 has two separate timers available. Timer 模拟器 混控 NORM 4 . 2 V The timer can be used for a variety of timings, Throttle, Status such as the running time of the engine or power...
- Page 39 A and the rate B are both 100% and the switch the EXPA EXPB is -60%. Interface path: WFLY →General Menu→Dual Rate 6 Both the rate A and the rate B are 50% and the EXPA EXPB is 0%. In this case, the servo needs to be...
- Page 40 135% Gyrm CH10 Home Interface relative position symbols 0 0: 06 : 5 9 0 0 : 0 6 : 5 9 Trim Step NORM 4.2 V ET07 NORM 4 . 2 V 100% 100% Step Comb Switch Green cursor:...
- Page 41 The mixing rate can be adjusted freely so that the Interface path: WFLY →Model Menu→Program aircraft's wrong tendency can be effectively Mix 1,2,3 corrected. You can set the mixing switch to manually control the activation and deactivation of the mixing.
- Page 42 Interface path: WFLY →Model Menu→Throttle Click on the function name in the upper left corner to Hold exit the interface and save the settings.
- Page 43 After the throttle cut function is enabled, the throttle channel 5 or a channel 7. cut or the ESC's fully flameout position can be Enter the interface: WFLY → Model Menu → adjusted. After the function is activated, regardless Aileron 2...
- Page 44 [Aux Channel]. The control switch needs to be set in [Model Menu] → [Fly Mode]. Enter the interface: WFLY → Model Menu→ The curve control switch for throttle hold needs Flap Trim to be set in [Model Menu] → [Throttle Hold].
- Page 45 Enter the interface: WFLY → Model Menu → Connect the right aileron servo to CH1 (aileron) ELE to Flap and the left aileron servo to CH6 (flaps).
- Page 46 When other mixing controls are enabled, the mixing will pop up on the interface. For function conflict prompts, please firstly set other mixed function to be inhibited. Enter the interface: WFLY → Model Menu → Elevon Ele von NO R M 4.2V...
- Page 47 Model Menu Air Brake (Airplane) This function is used for landing or in-flight Enter the interface: WFLY → Model Menu→ Air descent actions. brake ● Generally, the aileron opens upward when used Setting method: as a brake. Press the - arrow keys to select the setting item, ●...
- Page 48 Model Menu Ailvator (Airplane) This function makes the elevator gets the function Interface Path: WFLY →Model Menu→Ailvator of an aileron, and the performance of the aircraft snap roll is improved. The aileron elevator is to Setting method: make the two rudder surfaces on the normal layout...
- Page 49 Click on the function name in the upper left corner to Interface Path: WFLY → Model Menu→ Throttle exit the interface and save the settings. Hold Throttle Hold NORM 4.2 V...
- Page 50 Idle 2 (under gear). in each of the above swash types, the swash rate Enter the interface: WFLY → Model Menu → Fly may not operate correctly. Please adjust the Mode .
- Page 51 (the value throttle, the normal throttle output can be restored! 0 0 : 0 6 : 5 9 on the right indicates the current Enter the interface: WFLY → Model Menu→ throttle stick position.) Throttle Cut Pitch Cur ve (Helicopter)
- Page 52 [Gyro]. ● When the idle speed is reduced, the throttle trim switch is used to adjust the amount of Enter the interface: WFLY → Model Menu → descent reduction. Gyro ● The operation switch can be selected from Setting method: the switches SA, SB, SC, and SD.
- Page 53 Setting method: 0%, the default value!). Press the - arrow keys to select the setting item, Interface Path:WFLY→Model Menu→Throttle and press the plus or minus key to adjust the value. Hold Click the Back button to exit the interface and save the settings.
- Page 54 Note:When starting the engine, be sure to start position, the functions are only: normal (Gear up) the engine at normal idle speed in normal mode. and stunt 2 (Gear down). Enter the interface: WFLY → Model Menu → Throttle Curve. Interface Path: WFLY →Model Menu→Fly Mode...
- Page 55 ET07 WFLY Shenzhen WFLY Technology Development Co., LTD Address: 4th Floor,C2 Buliding,Xiangli Industry Park,Heping Haoye Road,Fuyog Town,Baoan District,Shenzhen,Guangdong Province,China. Tel:+86-755-29792496 Tel:service@wflysz.com Website:www.wflysz.com WFLY WeChat Official Account...
