Dwyer Instruments THI2-10 Installation And Operating Instructions

The THI2-10 Digital Remote Sensing Thermohygrometer accurately takes
humidity, temperature, dew point and wet bulb temperatures inside of ducts and hard
to reach areas. English and metric engineering units as well as the type of
measurement displayed can be easily selected using the push buttons. The push
buttons also allow the user to freeze the current reading or retrieve the minimum and
maximum readings. A large backlit LCD digital dual display allows the user to see both
the temperature and humidity simultaneously and a low battery indicator shows the
user when to change batteries. For hands free operation, the thermohygrometer can
be mounted on a tripod. All units include 4 AAA batteries and a hard carrying case for
safe

OPERATING INSTRUCTIONS

LCD & Keypad:
Power ON/OFF:
1. Press the button to turn on the meter and enter normal mode. Unit will
automatically turn off after 20 minutes without any buttons being pressed.
2. Press the same button to turn off the meter in any mode.
Back Light:
Press the key to turn on the back light of the LCD for 10 seconds.
Unit Selection:
In normal mode, press to switch the units between °C and °F.
Hold Reading:
1. Only in normal mode, press to freeze the current reading.
2. Press again to return to normal display.
Test Equipment Depot - 800.517.8431 - 99 Washington Street Melrose, MA 02176
Model THI2-10 Digital Remote Sensing Thermohygrometer
Specifications - Installation and Operating Instructions
[219.00]
TestEquipmentDepot.com
8-5/8

SPECIFICATIONS

Service: Humidity and temperature detection in air.
Range:
Relative humidity measurement range: 0 to 100%;
Temperature range: 14 to 140°F (-10 to 60°C);
Dew point temperature range: -100 to 139.8°F (-73.4 to 59.9°C);
Wet bulb temperature range: 7.88 to 139.8°F (-13.4 to 59.9°C).
Accuracy:
Relative humidity accuracy: ±3% from 10 to 90% (at calibration
temperature); ±5% for others;
Temperature accuracy: ±1°F (±.6°C).
Display: Dual LCD display for temperature and humidity.
Temperature Limits:
Ambient: 32 to 122°F (0 to 50 C);
Storage: 68 to 140°F (-20 to 60°C).
Resolution:
Temperature resolution: 0.1°C/°F;
Humidity resolution: 0.1% RH.
Power Requirements: 4 AAA batteries included.
Weight: 5.3 oz (150 g).
Agency Approval: CE.
Bulletin TE-THI2-10
1-19/64
2-49/64
[33.05]
[70.43]
6-45/64
[170.31]
2-13/32 1-1/8
[61.07] [28.77]
