IQ box KNX
EN
Commissioning manual
166560-00

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IQ box KNX and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for GEZE IQ box KNX

Summary of Contents for GEZE IQ box KNX

  • Page 1 IQ box KNX Commissioning manual 166560-00...

  • Page 2: Table Of Contents

    Load ETS product database IQ box KNX ..............................7 5.2.2 Assign physical address of the IQ box KNX .............................7 Overview of the KNX communication objects of the IQ box KNX ............8 Set parameters of the IQ box KNX functions using the ETS ..............9 Description of the functions ..................................9 IQ box KNX set parameters –...

  • Page 3: About This Document

    Product description and compatibility The IQ box KNX makes the control and monitoring of the GEZE IQ windowdrives (Slimchain, Powerchain, E 250 NT, Power lock, etc.) via the KNX-bus system possible. The drives can be moved to the required positions and the cur- rent drive position and various drive states can be requested.

  • Page 4: Safety Notices

    The IQ box KNX must be protected from building dirt and water. The IQ box KNX is a product of the KNX systems and detailed specialist know-how gained through KNX train- ing is required for the product to be understood.

  • Page 5: Designs And Installation Possibilities

    GEZE IQ Box KNX Designs and installation possibilities Two versions of the IQ box KNX are available UP (flush mount) and HS (top hat rail). The overall cable length between IQ box KNX and window must not exceed max. 15 m.

  • Page 6: Electrical Connection

    GEZE IQ Box KNX Electrical connection IQ box KNX flush mounting wiring diagram Fenster/ window max. 6 A 24 V DC 230V AC IQ box KNX + - - + - - IQ box KNX top hat rail wiring diagram Fenster/ window...

  • Page 7: Test Operation And Commissioning Of The Iq Windowdrives

    Following connection of the drives and the 24 V supply voltage, the key “Window OPEN” (9) and the key “Window CLOSED” (8) (see fig. IQ box KNX top hat rail + flush mounting) can be use to carry out a test run, even if the KNX system has not been programmed at this point.

  • Page 8: Overview Of The Knx Communication Objects Of The Iq Box Knx

    GEZE IQ Box KNX Overview of the KNX communication objects of the IQ box KNX Object no. Object name Function Flags Length Direction Operation and automatic Window - Drive command Open/Close 1.019 1 Bit Window - Drive command Step/Stop 1.007...

  • Page 9: Set Parameters Of The Iq Box Knx Functions Using The Ets

    GEZE IQ Box KNX Set parameters of the IQ box KNX functions using the ETS Use the ETS software to set parameters of the IQ box KNX. Description of the functions ETS parameters Function Description menu item General informa- Energy-saving mode...
  • Page 10 External push Push button The IQ box KNX has 2 button inputs (terminal 32, 33). The button inputs can be parametrised as local push buttons or KNX but- tons. Both button inputs can be parametrised individually.

  • Page 11: Iq Box Knx Set Parameters - Ets Menu

    GEZE IQ Box KNX IQ box KNX set parameters – ETS menu 7.2.1 Common Parameters Values Linked object 30 digits (IQ box) Device name Disabled Energy saving Enabled Delay time [min] 1 … 20 (1) Reaction on No reaction busvolt reset...

  • Page 12: Movement

    GEZE IQ Box KNX 7.2.2 Movement Parameters Values Linked object Speed hand control - 0, 10, 20, …, 100 open [%] (50) Speed hand control - 0, 10, 20, …, 100 (50) close [%] Step ventilation Disabled 2 Window - Drive command...

  • Page 13: Automatic

    GEZE IQ Box KNX 7.2.3 Automatic Parameters Values Linked object Speed automatic 0 … 100 (100) control [%] Disabled Automatic lock Locked to open Unlock Via object 9 Automatic - Lock Switch Until timeout Locking time [min] 9 Automatic - Lock 1 …...

  • Page 14: State

    GEZE IQ Box KNX 7.2.4 State Parameters Values Linked object Send actual position Disabled 11 Window - Actual position State value [%] On change Position change [%] 1 … 20 (10) Send state Disabled On change Window - Position between...

  • Page 15: Alert

    GEZE IQ Box KNX 7.2.5 Alert Parameters Values Linked object Reaction on safety alert Close window Open window Type wind alert Binary 23 Alert - Wind alert Switch Threshold Threshold windspeed 2 … 30 (4) 22 Alert - Wind speed...

  • Page 16: External Button

    GEZE IQ Box KNX 7.2.6 External button Parameters Values Linked object Disabled Button 1 (Cl.33) Lokal Drive type Tip op- Direction Open eration with Close self locking Toggle 2 … 50 (10) Step width [%] Tip opera- Direction Open tion without...

  • Page 17: Service

    GEZE IQ Box KNX 7.2.7 Service Parameters Values Linked object Performance infor- Disabled mation On change 41 Service - Check unit State Disabled Error information On change Error unit Send condition 42 Service - Error unit State Cyclic Cycle time [min] 1 …...

  • Page 18: Application Examples

    GEZE IQ Box KNX Application examples The application examples shown should provide an overview of the application possibilities of the IQ box KNX. The application examples can be combined and expanded as desired. Assembly example: Push button (local/KNX) Basic functions + Easy ventilation controls Manual open/close/stop à...
  • Page 19 GEZE IQ Box KNX Assembly example: Expansion through weather station (rain/wind/temperature) Expanded function examples KNX Automatic closing in the event of rain à If rain is detected by the weather station, the win- dow or window group closes automatically. Automatic closing in the event of wind weather à...
  • Page 20 GEZE IQ Box KNX Assembly example: Intelligent ventilation controls Expanded function examples, intelligent KNX venti- lation controls Night cooling à In summer, intelligent ventilation is applied above certain temperature differences (between inside and Presence air-conditioning outside) to lower the indoor temperature.

  • Page 21: Troubleshooting

    LED 10 flashes slowly. Check length of the connection à cable to the drive. The overall cable length between IQ box KNX and window must not exceed max. 15 m. Check software version of the à drives on the identification plate.
  • Page 22 GEZE IQ Box KNX...
  • Page 23 GEZE IQ Box KNX...
  • Page 24 E-Mail: danmark.se@geze.com Tel. +49 (0) 7152 203 594 www.geze.at www.geze.hu www.geze.dk E-Mail: leonberg.de@geze.com Baltic States Iberia Singapore GEZE GmbH Baltic States office GEZE Iberia S.R.L. GEZE (Asia Pacific) Pte, Ltd. GEZE GmbH E-Mail: office-latvia@geze.com E-Mail: info@geze.es E-Mail: gezesea@geze.com.sg Niederlassung Süd-Ost www.geze.com www.geze.es...
